Efficient dredging operations rely heavily on hydraulic agitators, optimized hydraulic dredge design, powerful hydraulic dredge pumps, and well-managed hydraulic hose reels. The HPP 150-350 Atlantic Hydraulic Power Pack from Atlantic Hydraulic Power provides the multi-functional hydraulic power necessary to operate a complete dredging system, ensuring precision, reliability, and efficiency.
From sediment removal to complex industrial dredging, the HPP 150-350 supports all hydraulic requirements, helping dredging operators execute operations seamlessly.
Powering Hydraulic Agitators and Dredge Pumps
The Atlantic HPP 150-350 is designed to drive a wide range of hydraulic dredging equipment:
Hydraulic agitators for loosening compacted sediment or slurry
Hydraulic dredge pumps for transporting abrasive materials efficiently
Hydraulic hose reels for organized and safe hydraulic fluid delivery
Submersible water pumps, drills, saws, and other hydraulic tools used in dredging
Its versatility ensures dredging systems operate efficiently, reducing downtime and maintenance challenges.
Hydraulic Configurations for Optimized Dredge Design
The HPP 150-350 provides flexible hydraulic setups to meet different dredging requirements:
Single hydraulic circuit: Powers one hydraulic tool or pump
Dual hydraulic circuits: Operate two tools simultaneously or combine flow for high-demand applications
High-pressure piston pump: Ideal for operations requiring pressures above 210 bar
Remote control options: Improves safety and ease of operation in complex dredging layouts
These configurations enable operators to customize the hydraulic dredge design for maximum efficiency and productivity.
Technical Specifications
Specification HPP 150 - 350
Oil Flow 2 x 75 LPM = 150 LPM
Max. Pressure 350 bar
Prime Mover Deutz TCD 3.6, 4-cylinder Inline
Engine Speed Fixed Speed – 1800 rpm
Engine Power 70 kW – 100 kW
Hydraulic Circuits Double hydraulic circuit with twin piston pumps
Dimensions (L x W x H) 2,250 x 1,350 x 2,400 mm
Weight 2,000 kg
With these specifications, the HPP 150-350 provides reliable power for demanding dredging operations while maintaining consistent performance.
Applications in Hydraulic Dredging
The HPP 150-350 supports a wide range of dredging applications:
Driving hydraulic agitators for sediment and slurry handling
Powering hydraulic dredge pumps for sand, gravel, and slurry transport
Efficiently operating hydraulic hose reels to manage fluid delivery
Supporting complete dredging systems in lakes, rivers, harbors, and industrial sites
Enhancing dredging operations for civil and industrial projects requiring high-powered hydraulic tools
By integrating the HPP 150-350 into dredging setups, operators can optimize hydraulic efficiency and ensure smooth dredging operations.
Why Choose Atlantic HPP 150-350?
Multi-functional hydraulic power for all dredging components
Configurable circuits for single or multiple hydraulic tools
High-pressure and high-flow performance for demanding operations
Remote control capability for safer operation in complex dredging systems
Portable and durable for long-term industrial and marine use
For dredging professionals looking to improve hydraulic dredge design, optimize hydraulic agitators, and ensure smooth operation of hydraulic dredge pumps and hose reels, the HPP 150-350 Atlantic Hydraulic Power Pack is a reliable and versatile choice.
