Boiler Refractory Gunning – AA 020 Overview
The Boiler Refractory Gunning AA 020 Genuine Piccola is a compact, durable, and high-efficiency solution designed specifically for boiler maintenance and refractory repair applications. Built for precision, reliability, and continuous operation, this machine delivers a consistent output range of 0 to 6 tons per hour, making it ideal for industrial boilers in power plants, refineries, and heavy manufacturing facilities.
The Blastcrete Genuine Piccola is engineered with a heavy-duty gearbox system powered by a 5 HP electric motor, 16 AM Gast air motor, or optional 13 HP Honda gasoline engine, ensuring stable and efficient performance in demanding boiler environments.
Why Choose Boiler Refractory Gunning – AA 020 Genuine Piccola?
The AA 020 Genuine Piccola Boiler Refractory Gunning Machine is widely trusted in the power and industrial sectors due to its durability, precision, and cost-effective operation. It is designed for continuous refractory application in high-temperature boiler systems.
Key Advantages
Output capacity of 0–6 tons per hour
Precise material output control system
Heavy-duty industrial gearbox for long service life
Compact and portable design for boiler access
Low maintenance and operating costs
Forklift pickup for easy transport and handling
Recommended by major refractory material manufacturers
These features make it a reliable solution for boiler refractory gunning applications.
Standard Features
The AA 020 Genuine Piccola includes industrial-grade features designed for boiler environments:
Simple Piccola single-point clamping system
Precise and adjustable material output control
Heavy-duty rotor assembly for continuous operation
Rugged steel construction for high-temperature environments
Forklift pickup for easy mobility
Quick maintenance access to reduce downtime
These features ensure smooth and reliable operation during boiler maintenance work.
Power Options
The Boiler Refractory Gunning Machine is available with multiple power configurations:
5 HP Electric Motor (240V or 480V, 3-Phase)
16 AM Gast Air Motor
13 HP Honda Gasoline Engine
This flexibility allows operation in power plants, industrial boiler rooms, and remote maintenance sites.
Optional Equipment
The AA 020 Genuine Piccola can be customized with several optional accessories:
Skid-mounted frame with forklift pickup
12 Hole Round Half Rotor
12 Hole Round Full Rotor
9 Hole Round Full Rotor
12 Hole Sector Full Rotor
Hydrostatic Predampener
Water Booster Pump
These options allow adaptation to different boiler refractory materials and repair requirements.
Technical Specifications
Specification Details
Model AA 020 Genuine Piccola
Machine Type Boiler Refractory Gunning Equipment
Material Output 0–6 Tons per Hour
Air Requirement 250–600 CFM (Depending on Power Option)
Outlet Connection 1.5-Inch Connection Cup
Maximum Aggregate Size 3/4 Inch
Mounting Solid Rubber Tires
Estimated Wear Pad Life Approximately 200 Tons
Dimensions 50 × 34 × 52 Inches
Weight 1,250 lbs
Applications in Boiler Systems
The AA 020 Genuine Piccola Boiler Refractory Gunning Equipment is widely used across industrial sectors, including:
Power plant boiler refractory maintenance
Industrial steam boiler lining repair
Heat recovery steam generator (HRSG) maintenance
Waste heat boiler gunning applications
Petrochemical boiler repair
Furnace and combustion chamber lining
Shutdown boiler maintenance projects
High-temperature refractory patching
Its compact design ensures efficient operation even in tight boiler spaces.
Precision Material Control
A key advantage of the AA 020 Genuine Piccola is its precise material output control system, which allows operators to regulate flow for optimal boiler repair results. This ensures:
Uniform refractory application
Reduced material waste and rebound
Improved lining durability
Higher operational efficiency
This precision is critical for maintaining boiler efficiency and safety.
Built for High-Temperature Industrial Use
The AA 020 Genuine Piccola is engineered with heavy-duty components designed for continuous operation in harsh boiler environments. Its robust gearbox and rotor system ensure long-lasting performance under extreme heat conditions.
With an estimated wear pad life of approximately 200 tons, the machine offers excellent durability and reduced maintenance costs.
Why Choose AA 020 Boiler Refractory Gunning Equipment?
Professionals prefer this machine because it delivers:
Reliable industrial performance
Easy operation and maintenance
Flexible power options
Strong and durable construction
Consistent material output
Cost-effective operation
Proven long-term reliability
These advantages make it a trusted solution for boiler refractory gunning applications worldwide.
Boiler Refractory Gunning AA 020 Genuine Piccola for Industrial Boiler Maintenance
