Industrial Mining and Construction Machinery Solution
The mining equipment and construction machinery system (AA 020) is designed for heavy-duty material application in demanding industrial environments. The Genuine Piccola provides a reliable and efficient solution for dry gunning, shotcrete, and concrete spraying applications used in mining operations and large-scale construction projects.
With an output capacity of 0–6 tons per hour, this system is widely used in mining tunnels, structural concrete repair, underground construction, and industrial infrastructure maintenance.
Quote Now | Download Brochure
Request pricing and pricing details
Download technical brochure
Explore configurations for mining and construction applications
Key Features
The AA 020 system is engineered for durability and consistent performance in harsh environments:
Simple Piccola single-point clamping system
Precise material output control for accurate spraying
Recommended by major refractory material manufacturers
Forklift pickup for easy transportation
Heavy-duty gearbox for continuous rotor operation
Low maintenance and cost-efficient design
Power Options
The Genuine Piccola mining and construction machine supports flexible power configurations:
5 HP Electric Motor (240V or 480V, 3-Phase)
16 AM Gast Air Motor
13 HP Honda Gasoline Engine
These options make it suitable for both underground mining operations and surface construction sites.
Optional Equipment
To enhance flexibility in mining and construction environments, the system can be equipped with:
Skid-mounted frame with forklift pickup
12-hole round half rotor
12-hole round full rotor
9-hole round full rotor
12-hole sector full rotor
Hydrostatic predampener
Water booster pump
Technical Specifications
Specification Details
Output Capacity 0–6 tons per hour
Air Requirement 250–600 CFM (depending on configuration)
Outlet Connection 1.5-inch connection cup
Maximum Aggregate Size 3/4 inch
Mounting Solid rubber tires
Estimated Wear Pad Life ~200 tons
Dimensions 50 in × 34 in × 52 in
Weight 1250 lbs
Applications in Mining & Construction
The AA 020 system is widely used across mining and construction sectors, including:
Underground tunnel lining and repair
Mining shaft reinforcement
Structural concrete spraying
Infrastructure maintenance projects
Refractory lining in mining furnaces
Cemented rock support applications
Industrial construction repair
Power plant and heavy civil works
Its rotor-based system ensures consistent application, reduced rebound, and strong material adhesion even in harsh working conditions.
Advantages of Genuine Piccola AA 020
Reliable performance in extreme environments
Heavy-duty construction for mining and construction use
Low maintenance requirements
Flexible power options for different job sites
Easy transport with forklift pickup
Long service life under continuous operation
