Shotcrete Squeeze Hose Pump Machine Overview
The shotcrete squeeze hose pump machine RD6536 is a high-performance concrete pumping solution designed for demanding construction and industrial applications. Manufactured as the Blastcrete Model RD6536 Squeeze Hose Pump, it delivers variable-speed pumping from 0 to 25 cubic yards per hour, making it ideal for shotcrete, grout, and concrete placement projects.
Built for reliability, control, and durability, the RD6536 is widely used in tunneling, mining, structural repair, and general construction applications.
High-Performance Shotcrete Squeeze Hose Pump Machine
The RD6536 shotcrete squeeze hose pump machine features a 3-inch hydraulic squeeze pump system that ensures smooth and consistent material flow. Its variable speed control allows operators to precisely adjust output depending on jobsite requirements.
Performance Capabilities:
Output range: 0–25 cubic yards per hour
Designed for shotcrete and 3/4 inch aggregate concrete
3-inch hydraulic squeeze pump system
Stable and continuous pumping performance
This makes the RD6536 suitable for both small and large-scale shotcrete applications.
Key Features of RD6536 Shotcrete Squeeze Hose Pump Machine
The RD6536 is engineered with contractor-focused features that improve efficiency and ease of use:
Variable speed hydraulic squeeze pump system
Single axle high-speed towing trailer
Electric braking system with safety lights
Manual hydraulic controls (Forward–Neutral–Reverse)
Flow control system with hydraulic pressure gauge
1,000 lb capacity receiving hopper
Hydraulic agitator for consistent mixing
Hopper splash guard and protective cover
These features ensure safe, reliable, and efficient operation in demanding jobsite conditions.
Engine Power Options
The RD6536 shotcrete squeeze hose pump machine is available with two dependable engine configurations:
29 HP Kubota water-cooled diesel engine
35 HP Briggs & Stratton air-cooled gasoline engine
Both engines are designed for durability and consistent performance in continuous construction use.
Optional Equipment
To enhance usability and control, the RD6536 can be equipped with:
Pendant remote control system
Wireless remote control system
These options improve operator flexibility and convenience during shotcrete pumping operations.
Technical Specifications
Specification Details
Model RD6536 Shotcrete Squeeze Hose Pump Machine
Pump Type 3-inch hydraulic squeeze hose pump
Output Capacity 0–25 cubic yards per hour
Pump Discharge 3 inches
Aggregate Size Up to 3/4 inch
Hopper Capacity 1,000 lb receiving hopper
Hopper Features Hydraulic agitator, splash guard, cover
Trailer Type Single axle high-speed towing trailer
Braking System Electric brakes with lights
Length 160 inches
Width 88 inches
Height 45 inches (top of hopper)
Gross Weight 3,900 lbs
Fuel Tank 10 gallons
Applications of Shotcrete Squeeze Hose Pump Machine RD6536
The RD6536 shotcrete squeeze hose pump machine is suitable for a wide range of applications, including:
Shotcrete application in tunnels and mines
Concrete pumping for construction projects
Grout filling and structural repair
Floor leveling and resurfacing
Mud jacking and slab lifting
Cellular concrete placement
Concrete block filling
General industrial and civil construction
Its versatility makes it a valuable machine for contractors in multiple sectors.
Why Choose RD6536 Shotcrete Squeeze Hose Pump Machine?
The RD6536 stands out as a reliable shotcrete squeeze hose pump machine due to its combination of power, control, and portability. Its hydraulic squeeze system ensures smooth and consistent pumping performance, while the trailer-mounted design allows easy transport between job sites.
Key advantages include:
Adjustable variable-speed control
Strong and durable construction
Easy towing and mobility
Efficient hopper with hydraulic agitator
