Introduction to Concrete Pumping Equipment
Concrete pumping equipment plays a vital role in modern construction by enabling fast, efficient, and precise placement of concrete materials. The RD6536 Skid Steer Pump is a high-performance hydraulic concrete pump attachment designed to deliver reliable pumping capability for grout, shotcrete, and structural concrete applications.
Engineered for durability and ease of use, the RD6536 is widely used in residential, commercial, industrial, and infrastructure projects where efficient concrete placement is required.
RD6536 Concrete Pumping Equipment Overview
The RD6536 Skid Steer Pump converts a standard skid steer loader into a powerful concrete pumping machine. Its universal mounting system allows quick installation, making it ideal for contractors who need mobility and flexibility across multiple job sites.
This compact yet powerful system is designed to handle a wide range of concrete pumping tasks with consistent performance and minimal maintenance.
Hydraulic Squeeze Pump Performance
At the core of the RD6536 is a 3-inch hydraulic squeeze pump that delivers variable output from 0 to 25 cubic yards per hour. This adjustable performance allows operators to match pumping speed to specific job requirements.
The squeeze pump system works by compressing a flexible rubber tube, ensuring smooth and continuous material flow. Because concrete does not come into contact with moving mechanical parts, wear is significantly reduced and equipment lifespan is extended.
Versatile Material Handling Capability
The RD6536 Concrete Pumping Equipment is designed to handle a variety of construction materials, including:
Cement grout
Mortar
3/8-inch shotcrete
3/4-inch structural concrete mixes
This versatility allows contractors to use one machine across multiple applications, improving efficiency and reducing equipment costs.
Key Features of RD6536 Skid Steer Pump
The RD6536 is equipped with several features that improve performance and usability:
3-inch hydraulic squeeze pump system
Variable output from 0–25 cubic yards per hour
Universal skid steer mounting plate
Manual hydraulic controls for precise operation
Hydraulic remixer in the receiving hopper
Capability to pump up to 3/4-inch aggregate concrete
Forklift pick-up design for easy transport
Heavy-duty construction for demanding job sites
These features ensure reliable performance and consistent concrete placement in all conditions.
Low Maintenance and Durable Design
One of the biggest advantages of the RD6536 Concrete Pumping Equipment is its low-maintenance design. The primary wear component is the 3-inch rubber pumping tube, which can be replaced in approximately 20 minutes in the field.
Since concrete does not contact internal mechanical parts, wear is minimized, resulting in reduced downtime, lower maintenance costs, and longer equipment life.
Technical Specifications
Specification Details
Pump Type 3-Inch Hydraulic Squeeze Pump
Output Capacity Up to 25 Cubic Yards Per Hour
Pump Pressure 400 PSI
Pump Outlet 3 Inches
Hydraulic Oil Requirement 18 GPM @ 3000 PSI
Vertical Pumping Distance 100 Feet
Horizontal Pumping Distance 250 Feet
Weight 2,700 lbs
Length 76 Inches
Length with Hopper 89 Inches
Width 48 Inches
Width with Hopper 55 Inches
Height 48.25 Inches
Charging Height 40.25 Inches
Applications of Concrete Pumping Equipment
The RD6536 Skid Steer Pump is suitable for a wide range of construction applications, including:
Residential construction projects
Commercial buildings
Industrial facilities
Foundations and slabs
Driveways and sidewalks
Retaining walls
Shotcrete applications
Grouting operations
Bridge construction and repair
Tunnel and mining projects
Infrastructure development
Its compact skid steer design allows efficient operation in confined or difficult-to-access job sites.
Benefits of RD6536 Concrete Pumping Equipment
Contractors benefit from the RD6536 in several important ways:
High pumping capacity up to 25 cubic yards per hour
Smooth and consistent concrete flow
Easy skid steer compatibility
Reduced labor requirements
Low-maintenance squeeze pump system
Quick replacement of wear parts
Durable construction for tough environments
Lower operating costs
Increased productivity on job sites
Long service life
These advantages make it a reliable and cost-effective solution for modern construction needs.
Why Choose RD6536 Skid Steer Pump?
The RD6536 is designed for contractors who require dependable, efficient, and versatile concrete pumping equipment. Its hydraulic squeeze pump technology ensures consistent material flow, while its skid steer compatibility provides excellent mobility across job sites.
Whether used for structural concrete, grout, or shotcrete applications, the RD6536 delivers reliable performance and improved efficiency.
