Introduction to Masonry Grout Pump
A Masonry Grout Pump is essential equipment used in construction for accurately placing grout into masonry blocks, structural cavities, and reinforcement zones. The RD6536 Skid Steer Pump is a hydraulic concrete pump attachment designed to deliver consistent, efficient, and reliable grout pumping performance for masonry and structural applications.
Built for demanding construction environments, the RD6536 improves productivity while ensuring precise grout placement in both residential and commercial projects.
RD6536 Masonry Grout Pump Overview
The RD6536 Skid Steer Pump transforms a standard skid steer loader into a powerful masonry grout pumping machine. Its universal mounting system allows fast installation and easy removal, making it ideal for contractors who require mobility across multiple job sites.
This compact yet powerful system is engineered to provide smooth and controlled grout flow, even in tight or difficult-to-access areas.
Hydraulic Squeeze Pump Technology
At the core of the RD6536 is a 3-inch hydraulic squeeze pump that delivers variable output from 0 to 25 cubic yards per hour. This adjustable flow control allows operators to match grout delivery precisely to masonry construction requirements.
The squeeze pump works by compressing a flexible rubber tube, ensuring continuous and smooth material movement. Since grout does not contact internal mechanical parts, wear is minimized and reliability is improved.
Designed for Masonry Grouting Applications
As a Masonry Grout Pump, the RD6536 is ideal for:
Block wall grouting
Structural masonry reinforcement
Void filling in masonry structures
Bond beam grouting
Cavity wall applications
Repair and restoration projects
Its ability to deliver consistent grout flow makes it highly effective in both new construction and repair work.
Key Features of RD6536 Skid Steer Pump
The RD6536 includes several features designed to enhance masonry grouting performance:
3-inch hydraulic squeeze pump system
Variable output from 0–25 cubic yards per hour
Universal skid steer mounting plate
Manual hydraulic controls for precision operation
Hydraulic remixer in the receiving hopper
Capability to pump up to 3/4-inch aggregate material
Forklift pick-up design for easy transport
Heavy-duty construction for demanding job sites
These features ensure reliable and efficient grout delivery in masonry applications.
Low Maintenance and High Durability
One of the key advantages of the RD6536 Masonry Grout Pump is its simple maintenance design. The primary wear component is the 3-inch rubber pumping tube, which can typically be replaced in approximately 20 minutes in the field.
Because grout does not come into contact with internal mechanical parts, wear is significantly reduced. This results in lower maintenance costs, reduced downtime, and extended equipment lifespan.
Technical Specifications
Specification Details
Pump Type 3-Inch Hydraulic Squeeze Pump
Output Capacity Up to 25 Cubic Yards Per Hour
Pump Pressure 400 PSI
Pump Outlet 3 Inches
Hydraulic Oil Requirement 18 GPM @ 3000 PSI
Vertical Pumping Distance 100 Feet
Horizontal Pumping Distance 250 Feet
Weight 2,700 lbs
Length 76 Inches
Length with Hopper 89 Inches
Width 48 Inches
Width with Hopper 55 Inches
Height 48.25 Inches
Charging Height 40.25 Inches
Applications of Masonry Grout Pump
The RD6536 Skid Steer Pump is suitable for a wide range of masonry and construction grouting applications, including:
Concrete block wall grouting
Structural reinforcement projects
Commercial masonry construction
Residential building construction
Retrofitting and repair work
Infrastructure support systems
Industrial masonry applications
Its skid steer design allows efficient operation even in confined job sites.
Benefits of RD6536 Masonry Grout Pump System
Contractors benefit from the RD6536 in several important ways:
High pumping capacity up to 25 cubic yards per hour
Smooth and consistent grout flow
Easy skid steer compatibility
Reduced labor requirements
Low-maintenance squeeze pump system
Fast replacement of wear parts
Durable construction for harsh environments
Lower operating costs
Increased productivity
Long service life
These advantages make it a reliable and cost-effective solution for masonry grouting operations.
Why Choose RD6536 Skid Steer Pump?
The RD6536 is engineered for contractors who require precision, reliability, and mobility in masonry grouting work. Its hydraulic squeeze pump system ensures consistent material delivery, while its skid steer compatibility provides excellent flexibility across job sites.
Whether used for structural masonry, block filling, or repair work, the RD6536 delivers dependable performance.
Masonry Grout Pump: High-Performance RD6536 Skid Steer Pump Solution
