RD6536 Skid Steer Concrete Pump: A Versatile Concrete Pump Attachment for Modern Construction

A dependable skid steer concrete pump can significantly improve efficiency on construction sites by combining mobility, consistent pumping performance, and easy operation. The RD6536 Skid Steer Pump is a high-performance concrete pump attachment designed to help contractors place grout, shotcrete, and structural concrete with greater precision and productivity.

Built for demanding construction environments, the RD6536 transforms a compatible skid steer loader into a compact and capable concrete pumping system. Its hydraulic squeeze pump technology, variable-speed output, and durable design make it an excellent choice for residential, commercial, and infrastructure projects.

Efficient Concrete Pumping for Multiple Applications

The RD6536 is equipped with a 3-inch hydraulic squeeze pump that provides adjustable pumping speeds from 0 to 25 cubic yards per hour. This variable-speed capability allows operators to match material flow to the specific requirements of each job, improving placement accuracy while reducing waste.

The pump is designed to handle several types of materials, including:

Grout
3/8-inch shotcrete mixes
3/4-inch structural concrete mixes

This versatility enables contractors to use a single attachment across a wide range of concrete placement applications.

A Durable Concrete Pump Attachment

As a dedicated concrete pump attachment, the RD6536 features a universal skid steer mounting plate for fast installation on compatible skid steer loaders. This design allows crews to move quickly between tasks while taking advantage of the maneuverability and accessibility that skid steers provide.

Additional forklift pick-up points simplify transportation, loading, and storage, making the RD6536 easy to deploy on projects of all sizes.

Low-Maintenance Hydraulic Squeeze Pump

The RD6536 uses squeeze pump technology that keeps concrete inside a replaceable 3-inch rubber pumping tube, preventing abrasive materials from contacting the pump's moving mechanical components.

This design offers several important advantages:

Reduced wear on internal components
Longer equipment life
Simple cleaning after each project
Lower maintenance requirements
Reliable day-to-day operation

The pumping tube is the primary wear component and can be replaced in approximately 20 minutes in the field, minimizing downtime and helping contractors maintain productivity.

Reliable Hydraulic Performance

The RD6536 operates with a hydraulic oil requirement of 18 GPM at 3000 PSI, delivering the power needed for demanding concrete pumping applications.

Performance specifications include:

Maximum output: 25 cubic yards per hour
Pump pressure: 400 PSI
Vertical pumping distance: 100 feet
Horizontal pumping distance: 250 feet

These capabilities allow operators to pump concrete efficiently into elevated forms, foundations, retaining walls, and other hard-to-reach locations.

Key Features

The RD6536 is designed with features that support efficient operation and dependable performance:

Universal skid steer mounting plate
3-inch hydraulic squeeze pump
Variable pumping speed from 0–25 cubic yards per hour
Manual hydraulic controls
Hydraulic remixer in the receiving hopper
Forklift pick-up points for convenient transport
Pumps concrete mixes containing up to 3/4-inch aggregate

The integrated hydraulic remixer helps maintain a consistent concrete mix before pumping, promoting smooth material flow and dependable results.

RD6536 Skid Steer Pump Specifications
Specification Details
Pump Type 3" Hydraulic Squeeze Pump
Output Up to 25 Cubic Yards Per Hour
Pump Outlet 3"
Pump Pressure 400 PSI
Hydraulic Oil Requirement 18 GPM @ 3000 PSI
Vertical Pumping Distance 100 ft.
Horizontal Pumping Distance 250 ft.
Length 76"
Length with Receiving Hopper 89"
Width 48"
Width with Receiving Hopper 55"
Height 48.25"
Charging Height 40.25"
Weight 2,700 lbs.
Ideal Applications

The RD6536 skid steer concrete pump is suitable for numerous construction and repair projects, including:

Building foundations
Structural concrete placement
Sidewalks and driveways
Retaining walls
Commercial construction
Residential developments
Utility and infrastructure work
Shotcrete applications
Grouting projects

Its compact attachment design allows contractors to bring concrete pumping capability directly to the work area, reducing manual handling and improving overall job site efficiency.

Why Choose the RD6536?

The RD6536 combines the convenience of a concrete pump attachment with the dependable performance of a hydraulic squeeze pump. Its universal skid steer mounting plate, variable-speed operation, and straightforward maintenance help contractors maximize productivity while minimizing equipment downtime.

If you're looking for a reliable skid steer concrete pump that can pump grout, shotcrete, and structural concrete, the RD6536 delivers the durability, flexibility, and pumping capacity needed to handle a wide variety of construction projects with confidence.
