The Blastcrete MasonMate is an innovative masonry construction solution designed to improve concrete placement speed, reduce labor requirements, and increase productivity on demanding construction projects. Built specifically for high-rise block fill applications, this advanced equipment combines a powerful hydraulic squeeze pump, high shear continuous mixer, and bulk bag lifting system to simplify masonry grout placement.
Traditional CMU block filling methods often require manual bucket brigades, which can increase labor costs, slow project timelines, and create unnecessary dust on job sites. The Blastcrete MasonMate replaces these inefficient processes with a reliable, automated system that delivers consistent material flow and helps contractors complete block filling operations faster.
Boost Productivity with the Blastcrete MasonMate
The Blastcrete MasonMate is engineered for contractors who need dependable performance in commercial masonry and multi-story construction applications. This labor-saving machine can reduce on-site masonry labor by up to 75% by eliminating the need for manual block fill transportation.
The compact design allows the unit to operate in challenging environments, including areas with limited access. It can fit inside a freight elevator and can also be moved using a telescoping forklift or crane, making it ideal for high-rise construction projects.
Powerful Hydraulic Squeeze Pump Technology
At the core of the MasonMate is the D3522 2-inch hydraulic squeeze pump, designed to provide dependable pumping performance while minimizing maintenance requirements. The squeeze pump technology allows material to move through the system without coming into contact with mechanical moving components, helping extend equipment life.
The pump provides:
Reliable grout and mortar pumping performance
2-inch heavy-duty discharge capability
Pumping pressure up to 400 PSI
Output from 0–6 cubic yards per hour
Long-lasting pumping tubes for reduced downtime
High Shear Continuous Mixer for Consistent Material Quality
The integrated high shear continuous mixer ensures uniform mixing and consistent material delivery throughout the application. This helps contractors maintain reliable grout placement while reducing material waste and improving construction efficiency.
The continuous mixing system is designed to:
Improve concrete and grout consistency
Increase placement speed
Reduce manual mixing requirements
Support continuous workflow on busy construction sites
1000 lb Bulk Bag Lifter for Efficient Material Handling
The built-in 1000 lb. bulk bag lifter improves job-site efficiency by simplifying material loading and reducing physical handling. This feature allows operators to load bulk materials quickly while minimizing labor-intensive processes.
The MasonMate is designed to be moved with a pallet jack, providing additional flexibility for construction environments.
Features of Blastcrete MasonMate
D3522 2-inch hydraulic squeeze pump powered by a heavy-duty planetary gearbox
High shear continuous mixer system
1000 lb capacity bulk bag lifter
Designed for pallet jack movement
Operates within an 8 ft. ceiling height
Reduces labor costs and improves construction efficiency
Low operating and maintenance costs
Long-lasting pumping tube technology
Power Options
The Blastcrete MasonMate is available with multiple power configurations to meet different job-site requirements:
Kubota water-cooled diesel engine
35 HP Briggs & Stratton gasoline engine
30 HP electric motor with starter and disconnect
Optional Equipment
To customize the system for specific applications, available options include:
Hydraulic receiving hopper agitator
Pendant or wireless remote control
Hydraulic pressure washer
Mounted air compressor
Specifications
Specification Details
Pump 2" D3522 Hydraulic Squeeze Pump
Pumping Pressure 400 PSI
Output 0–6 Cubic Yards Per Hour
Discharge 2" HD
Hopper Capacity 3 cu. ft.
Dimensions 90" x 44" x 72" (Bag Lifter in Charging Position)
Weight 2,600 lbs.
Ideal Applications for MasonMate
The Blastcrete MasonMate is suitable for:
High-rise block fill projects
Commercial masonry construction
CMU wall filling applications
Concrete masonry unit grouting
Multi-story building construction
Labor-saving construction operations
Improve Masonry Efficiency with Blastcrete MasonMate
For contractors looking to improve concrete placement speed, reduce block filling labor costs, and increase productivity, the Blastcrete MasonMate provides a dependable solution. Its combination of hydraulic pumping technology, continuous mixing capability, and efficient material handling makes it an excellent choice for modern masonry construction projects.
By replacing slow manual methods with automated equipment, the MasonMate helps construction teams complete projects faster while maintaining consistent material placement quality.
Blastcrete MasonMate: Advanced Labor-Saving Equipment for Faster CMU Block Filling and Masonry Construction
