Underground construction projects require specialized equipment that can deliver reliable concrete mixing and pumping performance in challenging environments. The MineMate is an advanced concrete mixing and pumping machine for underground construction, designed to support mine sealing, grouting, shotcrete, and concrete placement applications where traditional ready-mix concrete solutions are not practical.
By combining a high-pressure piston pump with a continuous mixer, the MineMate provides an efficient all-in-one solution for underground contractors seeking improved productivity and consistent material delivery.
Advanced Concrete Mixing and Pumping Machine for Underground Construction
The MineMate is designed as a labor-saving technology that combines Blastcrete's X-10 ultra high-pressure swing tube piston pump with a high shear continuous mixer. This integrated system allows operators to mix and pump concrete materials directly at the underground work site.
The machine is ideal for applications where concrete must be produced and delivered in confined or remote areas, including:
Underground mine seals
Concrete grouting
Underground shotcrete applications
Tunnel construction
Ground stabilization
Mining support projects
Concrete repair work
Efficient Underground Concrete Placement
Transporting ready-mix concrete underground can be difficult due to limited access, distance, and operating conditions. The MineMate solves these challenges by providing an integrated mixing and pumping system.
Key advantages include:
Reduced equipment requirements
Less manual material handling
Continuous concrete production
Reliable underground material placement
Improved project efficiency
The MineMate can mix and pump up to 12 cubic yards per hour and deliver materials over distances exceeding 500 feet, making it suitable for demanding underground construction projects.
High-Performance Pumping Technology
The MineMate is equipped with a powerful ultra high-pressure swing tube piston pump designed for reliable concrete and grout delivery.
Performance features include:
3" × 24" Ultra High Pressure Swing Tube Piston Pump
Pumping pressure up to 2,200 PSI
Output capacity of 0–12 cubic yards per hour
Heavy-duty 3-inch discharge system
Pumping capability exceeding 500 feet
This high-pressure capability allows operators to place concrete and grout materials efficiently in tunnels, mines, and other restricted-access areas.
Continuous Mixer for Consistent Material Quality
The integrated high shear continuous mixer helps ensure proper blending of concrete materials before pumping. This provides consistent material quality and dependable performance during critical underground applications.
The MineMate also includes a screw conveyor with material bin indicator for charging the continuous mixer. This reduces manual loading requirements and supports continuous operation.
Low-Profile Design for Underground Environments
Underground construction sites often have limited space and restricted ceiling heights. The MineMate features a compact, low-profile design that allows operation in areas with ceiling heights as low as 6 feet.
This makes it suitable for:
Underground mines
Tunnels
Caverns
Confined construction areas
Remote underground projects
The machine provides strong pumping performance while maintaining easy maneuverability in challenging locations.
Flexible Power Options
The MineMate is available with different power configurations to meet various job site requirements:
50 HP Electric Motor with starter and disconnect
66 HP Kubota V3600 Water-Cooled Diesel Engine
These options provide flexibility for both permanent underground facilities and remote construction locations.
Optional Features
The MineMate can be equipped with additional features to improve operation and convenience:
Hydraulic receiving hopper agitator
Pendant remote control
Wireless remote control
Hydraulic pressure washer
These options allow contractors to customize the machine based on specific project needs.
Technical Specifications
Pump: 3" × 24" Ultra High Pressure Swing Tube Piston Pump
Maximum Pumping Pressure: 2,200 PSI
Output Capacity: 0–12 Cubic Yards Per Hour
Discharge: 3" Heavy Duty
Hopper Capacity: 3 Cubic Feet
Dimensions: 120" × 60" × 48" (Bag Lifter in Charging Position)
Operating Weight: 3,500 lbs
Benefits of Using the MineMate
The MineMate provides several benefits for underground construction contractors:
Combines concrete mixing and pumping in one machine
Designed for underground applications
Supports shotcrete, grouting, and sealing projects
Delivers high-pressure pumping performance
Reduces labor and equipment requirements
Operates in low-clearance environments
Provides consistent concrete material quality
Offers flexible electric and diesel power options
MineMate: Concrete Mixing and Pumping Machine for Underground Construction
