Underground mining projects often require specialized equipment that can operate in confined spaces while delivering reliable concrete mixing and pumping performance. The MineMate is a compact underground concrete equipment solution designed for low-clearance environments, including underground mines, tunnels, and restricted construction areas.
Combining a powerful ultra high-pressure piston pump with a continuous mixing system, the MineMate provides efficient concrete placement for mine seals, grouting, shotcrete, and underground construction applications where ready-mix concrete is not practical.
Compact Design for Underground Operations
The MineMate is engineered as low ceiling mining equipment to support concrete placement in areas where space is limited. Its low-profile configuration allows operation in underground environments with ceiling heights as low as 6 feet.
The compact design helps contractors:
Access confined underground areas
Reduce equipment handling challenges
Improve job site mobility
Perform concrete placement in restricted spaces
Increase operational efficiency
Complete Concrete Mixing and Pumping System
The MineMate combines Blastcrete’s X-10 ultra high-pressure swing tube piston pump with a high shear continuous mixer to provide a complete underground concrete processing system.
This integrated design allows operators to:
Mix materials directly at the work site
Pump concrete and grout efficiently
Reduce the need for additional equipment
Maintain consistent material quality
Improve underground productivity
The machine is capable of mixing and pumping up to 12 cubic yards per hour.
High-Performance Pumping Capability
The MineMate delivers dependable pumping performance for demanding underground applications.
Key pumping features include:
3" × 24" Ultra High Pressure Swing Tube Piston Pump
Pumping pressure up to 2,200 PSI
Output capacity of 0–12 cubic yards per hour
Heavy-duty 3-inch discharge system
Pumping distance exceeding 500 feet
This capability makes the MineMate suitable for transporting concrete materials through tunnels, shafts, and other challenging underground locations.
Designed for Low Ceiling Mining Applications
Low-clearance environments require equipment that can perform without sacrificing power. The MineMate is specifically designed for underground mining conditions where traditional concrete equipment may not fit.
Applications include:
Underground mine seals
Shotcrete installation
Mining grouting
Tunnel construction
Ground support projects
Concrete repair work
Its compact footprint allows contractors to complete projects in areas with limited access.
Efficient Material Charging System
The MineMate includes a material screw conveyor with a bin indicator for charging the continuous mixer. This system simplifies material loading and helps reduce manual labor during operation.
Benefits include:
Faster material preparation
Improved workflow efficiency
Reduced operator effort
Consistent mixer charging
Flexible Power Options
The MineMate offers multiple power configurations to meet different underground project requirements:
50 HP Electric Motor with Starter and Disconnect
Kubota V3600 66 HP Water-Cooled Diesel Engine
These options allow contractors to choose the best power source for their working environment.
Optional Equipment Features
The MineMate can be equipped with additional options to improve performance and convenience:
Hydraulic receiving hopper agitator
Pendant remote control
Wireless remote control
Hydraulic pressure washer
These features provide increased versatility for underground concrete placement operations.
Technical Specifications
Pump: 3" × 24" Ultra High Pressure Swing Tube Piston Pump
Pumping Pressure: 2,200 PSI
Output: 0–12 Cubic Yards Per Hour
Discharge: 3" Heavy Duty
Hopper Capacity: 3 Cubic Feet
Dimensions: 120" × 60" × 48" (Bag Lifter in Charging Position)
Weight: 3,500 lbs
Advantages of the MineMate
The MineMate provides several benefits for underground mining and construction teams:
Compact design for low ceiling applications
Combines mixing and pumping in one machine
Supports concrete pumping distances over 500 feet
Provides high-pressure material delivery
Reduces labor and equipment requirements
Improves underground project efficiency
Designed for challenging mining environments
