Advanced Refractory Pump for Furnace Lining and Industrial Applications
Furnace lining projects require reliable equipment capable of handling dense refractory materials with precision, consistency, and high pumping pressure. The MX-10 Mixer / Pump is a heavy-duty refractory installation machine designed for demanding furnace lining, refractory shotcrete, and pump cast applications.
Combining an ultra high-pressure 3-inch swing tube piston pump with a high-torque hydraulic pan mixer, the MX-10 provides efficient mixing and pumping of refractory materials. Since 1996, this equipment has been recognized as a dependable solution for monolithic refractory installations where performance and durability are essential.
MX-10 Mixer / Pump for Furnace Lining Applications
The MX-10 is engineered to support industrial furnace repair and installation operations by delivering consistent refractory material placement. Its 2200 PSI piston face pressure allows the machine to handle tough refractory mixes used in furnace linings, kiln repairs, heat-resistant structures, and other high-temperature industrial environments.
The integrated 2200 lb. capacity high torque pan mixer ensures uniform material preparation with a mixing cycle of approximately 1.5 to 2 minutes. Combined with the ultra high-pressure piston pump, the MX-10 can deliver up to 10 tons per hour and pump refractory materials more than 300 feet vertically.
Features of the MX-10 Refractory Installation Machine
High return on investment through reliable operation and productivity
3-inch x 24-inch ultra high-pressure swing tube piston pump
2200 PSI pumping pressure for demanding refractory applications
2200 lb. hydraulic pan mixer capacity
Fast 1.5 to 2 minute mixing cycle
Swing-out receiving hopper for simple cleaning and maintenance access
Forklift tubing mounted lower hopper for easy flat-pack removal
Fill Rite water meter for accurate water measurement
20-gauge dousing bucket for quick water addition
Reliable solid-state electronic controls
CE certification for global applications
Power Options Available
The MX-10 Mixer / Pump can be configured with different power systems to meet project requirements:
John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
Dual 40 HP electric motors
Optional Equipment for Enhanced Performance
Available options help improve flexibility and maintenance efficiency:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire mounted setup
Pendant or wireless remote control
Skid-mounted configuration with forklift tubing
MX-10 Technical Specifications
Specification Details
Pump 3" x 24" Ultra High Pressure Swing Tube
Pump Pressure 2200 PSI
Mixer 2200 lb. Capacity Hydraulic Pan Mixer
Output 0-12 Cubic Yards Per Hour
Discharge 3"
Hopper 2,500 lb. Capacity Swing-Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Crane Pickup Central Four Point Pickup – No Spreader Bar Needed
Electrical System Solid State Valve Control
Trailer Dual 6,000 lb. Capacity Axles with Electric Braking and Lights
Dimensions 204" x 88" x 117"
Weight 9,000 lbs.
Improve Furnace Lining Projects with MX-10 Technology
The MX-10 Mixer / Pump offers the strength and precision needed for modern refractory installation work. Its combination of high-pressure pumping, powerful mixing capability, and rugged construction makes it an ideal choice for furnace lining applications and other industrial refractory projects.
MX-10 Mixer / Pump: High-Performance Refractory Installation Machine for Furnace Lining Applications
