Reliable shotcrete installation requires equipment that can deliver consistent pumping pressure, efficient mixing, and dependable performance in challenging working conditions. The MX-10 Mixer / Pump is advanced concrete shotcrete equipment designed for dense refractory shotcrete, pump cast applications, and industrial construction projects where high performance is required.
The MX-10 combines an ultra high-pressure 3-inch swing tube piston pump with a high-torque hydraulic pan mixer to provide consistent mixing and material placement. Since 1996, this machine has been recognized as a trusted solution for monolithic refractory installations and demanding shotcrete operations.
MX-10 High Pressure Shotcrete Pump for Industrial Applications
The MX-10 is engineered as a powerful high pressure shotcrete pump capable of handling tough concrete and refractory materials. With a 2200 PSI piston face pressure, the machine provides the force required for challenging shotcrete applications, including industrial repairs, refractory lining work, and heavy-duty construction projects.
Its high-capacity hydraulic pan mixer delivers uniform material blending with a quick 1.5 to 2 minute mixing cycle. The system can produce up to 12 cubic yards per hour, helping contractors complete large-scale applications efficiently while maintaining consistent material quality.
Key Features of MX-10 Concrete Shotcrete Equipment
Designed for concrete shotcrete, refractory shotcrete, and pump cast applications
Ultra high-pressure 3" x 24" swing tube piston pump
2200 PSI pumping pressure for demanding applications
High-torque 2200 lb. hydraulic pan mixer
Fast 1.5 to 2 minute mixing cycle
Swing-out receiving hopper for easy cleaning and maintenance
Forklift tubing mounted lower hopper for convenient flat-pack removal
Fill Rite water meter for accurate water control
20-gauge dousing bucket for rapid water introduction
Reliable solid-state electronics
CE certification
Power Options
The MX-10 Mixer / Pump is available with flexible power configurations:
John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
Dual 40 HP electric motors
Optional Features
To improve jobsite efficiency and machine versatility, the MX-10 offers several optional upgrades:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire mounted configuration
Pendant or wireless remote control
Skid-mounted design with forklift tubing
MX-10 Technical Specifications
Specification Details
Pump 3" x 24" Ultra High Pressure Swing Tube
Pump Pressure 2200 PSI
Mixer 2200 lb. Capacity Hydraulic Pan Mixer
Output 0-12 Cubic Yards Per Hour
Discharge 3"
Hopper 2,500 lb. Capacity Swing-Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Crane Pickup Central Four Point Pickup – No Spreader Bar Needed
Electrical System Solid State Valve Control
Trailer Dual 6,000 lb. Capacity Axles with Electric Braking and Lights
Dimensions 204" x 88" x 117"
Weight 9,000 lbs.
Choose MX-10 for Reliable High Pressure Shotcrete Performance
The MX-10 Mixer / Pump provides the durability, power, and precision required for modern shotcrete and refractory applications. Its combination of high-pressure pumping technology, efficient mixing capability, and rugged construction makes it a dependable choice for contractors and industrial operators.
