Modern construction, refractory installation, and industrial repair projects require advanced concrete placement equipment that can deliver consistent performance under demanding conditions. The MX-10 Mixer / Pump is a powerful pumping solution designed for dense refractory shotcrete, pump cast concrete, and specialized material placement applications.
Combining an ultra high-pressure swing tube piston pump with a high-torque hydraulic mixer, the MX-10 provides efficient mixing and precise pumping for projects where reliability and productivity are essential.
MX-10 Pump Cast Concrete Equipment for Industrial Applications
The MX-10 Mixer / Pump is engineered for professional contractors who require dependable pump cast concrete equipment for challenging environments. It is widely suited for refractory installations, industrial maintenance, furnace repairs, kiln lining projects, and other applications requiring controlled concrete placement.
The machine features a 3-inch x 24-inch ultra high-pressure swing tube piston pump capable of generating 2200 PSI piston face pressure, allowing operators to handle demanding materials while maintaining consistent output.
With a powerful hydraulic pan mixer and efficient pumping system, the MX-10 helps reduce manual labor, improve application speed, and support continuous operation on large-scale projects.
Efficient Mixing and Concrete Placement Performance
The MX-10 integrates mixing and pumping functions into one compact and durable machine. Its high-torque mixer ensures uniform material consistency before pumping, helping achieve reliable placement results.
Key performance advantages include:
High-pressure pumping for dense concrete and refractory materials
Consistent material mixing with rapid cycle times
Long-distance and vertical pumping capability
Easy cleaning and maintenance access
Heavy-duty construction for industrial environments
The 2200 lb. capacity hydraulic pan mixer provides an efficient mixing cycle of approximately 1.5 to 2 minutes, allowing operators to maintain a steady material supply during demanding applications.
Key Features of MX-10 Mixer / Pump
Designed for pump cast concrete and refractory applications
Ultra high-pressure 3" x 24" swing tube piston pump
2200 PSI piston face pressure
2200 lb. high-torque hydraulic pan mixer
Output capacity up to 12 cubic yards per hour
Capable of pumping materials over 300 ft. vertically
Swing-out receiving hopper for simple cleaning and maintenance
Forklift tubing mounted lower hopper for easy flat-pack removal
Fill Rite water meter for precise water control
20-gauge dousing bucket for rapid water introduction
Reliable solid-state electronics
CE-certified design
Power Options
The MX-10 is available with multiple power configurations to meet different jobsite requirements:
John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
Dual 40 HP electric motors
Optional Equipment
The MX-10 can be customized with additional features to improve efficiency and operator convenience:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire mounted configuration
Pendant or wireless remote control
Skid-mounted design with forklift tubing
MX-10 Technical Specifications
Specification Details
Pump 3" x 24" Ultra High Pressure Swing Tube
Pump Pressure 2200 PSI
Mixer 2200 lb. Capacity Hydraulic Pan Mixer
Output 0-12 Cubic Yards Per Hour
Discharge 3"
Hopper 2,500 lb. Capacity Swing-Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Crane Pickup Central Four Point Pickup – No Spreader Bar Needed
Electrical System Solid State Valve Control
Trailer Dual 6,000 lb. Capacity Axles with Electric Braking and Lights
Dimensions 204" x 88" x 117"
Weight 9,000 lbs.
Choose MX-10 for Dependable Concrete Placement Solutions
The MX-10 Mixer / Pump delivers the strength, precision, and reliability required for demanding concrete placement operations. Its combination of high-pressure pumping technology, efficient mixing capability, and rugged construction makes it an ideal choice for contractors handling pump cast concrete, refractory work, and industrial applications.
High-Performance Pump Cast Concrete Equipment for Reliable Material Placement
