Industrial refractory projects demand equipment that delivers exceptional power, reliable material flow, and easy operation. The MX-10 Mixer/Pump is engineered to meet these challenges with a robust hydraulic agitator hopper pump and optional remote controlled concrete pump functionality. Designed specifically for dense refractory shotcrete and pump cast applications, the MX-10 has been the industry standard for monolithic refractory installations since 1996.
With its ultra-high-pressure pumping system, high-capacity hydraulic pan mixer, and user-focused design, the MX-10 helps contractors maximize productivity while minimizing downtime.
Built for Demanding Refractory Installations
The MX-10 features a 3-inch ultra-high-pressure swing tube pump capable of handling dense refractory materials with ease. Delivering up to 10 tons of material per hour, the machine is designed for large industrial projects that require continuous, high-volume pumping.
Its powerful pumping system can move refractory materials more than 300 feet vertically, making it an excellent solution for furnaces, boilers, kilns, petrochemical facilities, power plants, and other heavy industrial applications.
Hydraulic Agitator Hopper Pump for Consistent Material Flow
One of the standout features of the MX-10 is its hydraulic agitator hopper pump, which helps maintain a steady and uninterrupted supply of material to the pumping system. The integrated hydraulic agitator continuously moves the refractory mix, preventing material separation and reducing the risk of blockages.
Benefits of the Hydraulic Agitator Hopper Pump
Continuous material agitation for smooth pumping
Minimizes segregation of dense refractory mixes
Reduces the chance of pump blockages
Improves pumping efficiency and consistency
Supports high-volume production on demanding job sites
Enhances overall equipment reliability
Combined with the 2,500 lb. swing-out receiving hopper, this system ensures uninterrupted operation throughout long pumping cycles.
Remote Controlled Concrete Pump for Greater Job Site Efficiency
For increased convenience and operator safety, the MX-10 can be equipped as a remote controlled concrete pump using either a pendant control or an optional wireless remote. This feature allows operators to control essential pump functions from a safe and efficient working position.
Advantages of Remote Pump Operation
Improved operator mobility
Enhanced safety during pumping operations
Faster response to changing job site conditions
Increased placement accuracy
Reduced manual intervention
Higher overall productivity
Remote operation allows crews to monitor material placement while maintaining complete control over pump performance.
High-Capacity Hydraulic Mixing System
The MX-10 includes a 2200 lb. capacity high torque hydraulic pan mixer, capable of producing thoroughly mixed refractory material in just 1.5 to 2 minutes. Fast and consistent mixing helps contractors maintain project schedules while ensuring uniform material quality.
Mixer Features
2200 lb. mixing capacity
High-torque hydraulic drive
Rapid mixing cycles
Uniform refractory blending
Increased production efficiency
Reduced labor requirements
The hydraulic mixing system works seamlessly with the pumping unit to provide continuous material flow from mixing to placement.
Easy Maintenance with Swing-Out Hopper Design
Routine maintenance is simplified thanks to the MX-10's innovative swing-out receiving hopper. Operators can quickly access the swing tube section for cleaning, inspection, and servicing, reducing downtime between pumping operations.
Additional maintenance-friendly features include:
Swing-out receiving hopper
Forklift tubing for easy flat-pack removal
Fill Rite water meter
20-gallon dousing bucket for rapid water introduction
Reliable solid-state electronics
CE Certification
These design features help maximize equipment uptime and simplify daily maintenance.
Flexible Power Options
The MX-10 is available with several engine configurations to suit different operating environments:
John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
Dual 40 HP electric motors
These options provide flexibility for indoor and outdoor refractory installation projects.
Optional Equipment
The MX-10 can be customized with several factory-installed options, including:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire
Pendant remote control
Wireless remote control
Skid-mounted configuration with forklift tubing
These optional upgrades improve equipment performance, simplify maintenance, and enhance operator convenience.
MX-10 Technical Specifications
Specification Details
Pump 3" × 24" Ultra High Pressure Swing Tube
Pump Pressure 2200 PSI
Mixer 2200 lb. Capacity Hydraulic Pan Mixer
Output 0–12 Cubic Yards Per Hour
Discharge 3 inches
Hopper 2,500 lb. Capacity Swing-Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Crane Pickup Central Four-Point Pickup
Electrical Solid State Valve Control
Trailer Dual 6,000 lb. Capacity Axles with Electric Brakes and Lights
Dimensions 204" × 88" × 117"
Weight 9,000 lbs.
Why Choose the MX-10 Mixer/Pump?
The MX-10 is engineered to deliver outstanding reliability and performance for refractory contractors worldwide. Its combination of a hydraulic agitator hopper pump and optional remote controlled concrete pump provides efficient material handling, improved operator control, and simplified maintenance.
Key Benefits
Ultra-high-pressure pumping performance
Continuous material flow with hydraulic agitator
Optional wireless or pendant remote controls
High-capacity hydraulic pan mixer
Easy-access swing-out hopper
Heavy-duty industrial construction
Proven reliability since 1996
Excellent return on investment
Worldwide customer support
MX-10 Mixer/Pump: Hydraulic Agitator Hopper Pump and Remote Controlled Concrete Pump for High-Performance Refractory Applications
