In refractory construction, productivity and precision depend on equipment that can perform under the toughest conditions. The MX-10 Mixer/Pump is engineered to meet these demands by combining an ultra-high-pressure pumping system with advanced mixing technology. Featuring optional wireless remote shotcrete pump controls and multiple diesel powered concrete mixer pump configurations, the MX-10 delivers the reliability and performance required for industrial refractory shotcrete and pump cast applications.
Since 1996, the MX-10 has been trusted by contractors worldwide for monolithic refractory installations, providing consistent material delivery, efficient mixing, and simplified maintenance.
Built for Demanding Refractory Applications
The MX-10 is designed specifically for pumping dense refractory materials used in furnaces, boilers, kilns, incinerators, and other high-temperature industrial environments. Its rugged 3-inch ultra-high-pressure swing tube pump delivers reliable material placement, even during the most challenging installations.
With production rates of up to 10 tons per hour and the ability to pump materials over 300 feet vertically, the MX-10 helps contractors complete projects faster while maintaining consistent application quality.
Wireless Remote Shotcrete Pump for Enhanced Control
The MX-10 can be equipped as a wireless remote shotcrete pump, allowing operators to control pumping functions from a safe and convenient location. Wireless operation improves efficiency by enabling better visibility of material placement while reducing unnecessary movement around the job site.
Benefits of the Wireless Remote Shotcrete Pump
Wireless control for greater operator mobility
Improved safety during shotcrete applications
Better visibility of nozzle and material flow
Faster adjustments during pumping operations
Increased productivity on large installations
Reduced operator fatigue
For projects requiring alternative control methods, the MX-10 is also available with a pendant remote control option.
Diesel Powered Concrete Mixer Pump for Reliable Job Site Performance
The MX-10 is available as a diesel powered concrete mixer pump, making it an excellent solution for remote construction sites where electrical power may be limited. Contractors can choose from two dependable diesel engine options that deliver the horsepower needed for continuous heavy-duty operation.
Available Diesel Engine Options
John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
These powerful engines provide dependable performance, fuel efficiency, and the durability required for demanding industrial environments.
High-Capacity Hydraulic Pan Mixer
The MX-10 features a 2200 lb. capacity hydraulic pan mixer capable of producing consistent refractory mixes in approximately 1.5 to 2 minutes. The high-torque hydraulic drive ensures thorough blending of dense materials before they enter the pumping system.
Mixer Advantages
2200 lb. mixing capacity
High-torque hydraulic drive
Rapid mixing cycles
Uniform refractory material consistency
Increased production efficiency
Reliable operation under continuous workloads
This efficient mixing process helps reduce material waste while maintaining consistent installation quality.
Ultra High-Pressure Pumping System
The MX-10 is equipped with a 3-inch × 24-inch ultra-high-pressure swing tube pump capable of delivering 2200 PSI pumping pressure. This robust system is specifically engineered for refractory shotcrete and pump cast applications where high pressure and consistent flow are essential.
Key pumping benefits include:
2200 PSI piston face pressure
Long-distance vertical pumping
Smooth material delivery
Reliable swing tube design
Heavy-duty industrial performance
Designed for Easy Maintenance
The MX-10 incorporates several maintenance-friendly features that help minimize downtime and simplify daily servicing.
These include:
Swing-out receiving hopper for easy pump access
Hydraulic agitator to maintain material flow
Forklift tubing for convenient flat-pack removal
Fill Rite water meter
20-gallon dousing bucket for rapid water introduction
Reliable solid-state electronics
CE Certification
The swing-out hopper allows operators to quickly access the swing tube assembly for cleaning and maintenance between pumping operations.
Optional Equipment
The MX-10 can be configured with several optional accessories to increase productivity and simplify operation:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire
Pendant remote control
Wireless remote control
Skid-mounted version with forklift tubing
These options allow contractors to tailor the machine to their specific project requirements.
MX-10 Technical Specifications
Specification Details
Pump 3" × 24" Ultra High Pressure Swing Tube
Pump Pressure 2200 PSI
Mixer 2200 lb. Capacity Hydraulic Pan Mixer
Output 0–12 Cubic Yards Per Hour
Discharge 3 inches
Hopper 2,500 lb. Swing-Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Crane Pickup Central Four-Point Pickup
Electrical Solid State Valve Control
Trailer Dual 6,000 lb. Capacity Axles with Electric Brakes and Lights
Dimensions 204" × 88" × 117"
Weight 9,000 lbs.
Why Choose the MX-10 Mixer/Pump?
The MX-10 is designed to maximize productivity while reducing maintenance and operating costs. Its combination of wireless remote shotcrete pump functionality and diesel powered concrete mixer pump options makes it a versatile solution for demanding refractory projects around the world.
Key Benefits
Proven performance since 1996
Optional wireless remote operation
Powerful diesel engine choices
High-capacity hydraulic pan mixer
Ultra-high-pressure 2200 PSI pumping system
Easy-access swing-out hopper
Heavy-duty industrial construction
Excellent return on investment
Worldwide customer support
