Industrial mixing applications require equipment that delivers strength, consistency, and reliable performance under demanding conditions. The Industrial Pan Mixer is designed to provide efficient and uniform mixing for refractory castables and other heavy-duty materials. With advanced hydrostatic operation and a powerful planetary gearbox system, this mixer delivers dependable results for large-scale industrial projects.
The Heavy Duty Pan Mixer is engineered for professionals who need high-capacity mixing performance, fast production cycles, and durable construction. The 2200 LB Pan Mixer is capable of mixing up to 1 metric ton of refractory castable, making it an excellent choice for monolithic refractory installations, furnace repairs, kiln maintenance, and industrial construction applications.
High-Performance Industrial Pan Mixer for Demanding Applications
The Industrial Pan Mixer is built to handle challenging mixing requirements where consistency and efficiency are essential. Its heavy-duty design allows it to process dense refractory materials while maintaining reliable operation throughout long working cycles.
Common applications include:
Refractory castable mixing
Steel plant maintenance
Cement kiln repairs
Furnace lining projects
Foundry applications
Industrial construction work
High-temperature material preparation
The mixer provides the performance required for preparing quality materials used in demanding industrial environments.
Heavy Duty Pan Mixer with Advanced Mixing Technology
The Heavy Duty Pan Mixer features a hydrostatic mixing system powered by a heavy-duty planetary gearbox. This design delivers strong torque and consistent mixing action, ensuring materials are thoroughly blended before application.
Key Features of the Heavy Duty Pan Mixer
Mixes up to 1 metric ton of refractory castable
Fast 1.5 to 2 minute mixing cycles
Heavy-duty planetary gearbox drive
Reliable hydrostatic mixing operation
Designed for continuous industrial use
Consistent material quality
The powerful gearbox system helps maintain excellent mixing performance even with dense and demanding materials.
2200 LB Pan Mixer for Large-Scale Production
The 2200 LB Pan Mixer is designed to increase productivity by providing a large mixing capacity in a single batch. This reduces the number of mixing cycles required and helps improve overall job site efficiency.
Benefits of the 2200 LB Pan Mixer
Large 2200-pound mixing capacity
Reduced material preparation time
Improved workflow efficiency
Uniform refractory castable mixing
Lower labor requirements
Reliable performance in harsh environments
Its high-capacity design makes it suitable for contractors handling large refractory installation projects.
Efficient Bottom Discharge System
The mixer features a bottom discharge design that allows quick and controlled unloading of mixed materials. This improves handling efficiency and helps operators move prepared material directly to the installation area.
Bottom Discharge Advantages
Faster material discharge
Cleaner operation
Reduced manual handling
Improved productivity
Better control during placement
The discharge system helps streamline the mixing and installation process.
Precision Water Addition System
Accurate water measurement is essential for maintaining the correct consistency of refractory materials. The 2200 LB Pan Mixer includes a Fill-Rite Water Meter and a 20-gallon dousing tank to provide precise water control.
Water Control Benefits
Accurate water measurement
Consistent batch quality
Improved material performance
Reduced mixing variations
This feature helps operators achieve repeatable results with every batch.
Operator-Friendly Design and Safety Features
The Heavy Duty Pan Mixer includes a 15 sq. ft. operator platform designed for safe and convenient operation. The integrated control panel provides easy access to essential functions.
The control system includes:
Forward/Stop/Reverse mixer rotation
Bottom slide door Open/Close controls
Fill-Rite Water Meter operation
Manual hydraulic mixer tilt controls for cleanout
Additional operator features include:
Guard rails and ladder
Forklift pickup points
Telescoping adjustable legs
Stable operating platform
These features improve safety, accessibility, and ease of use on industrial job sites.
Reliable Power Configuration
The Industrial Pan Mixer is equipped with a powerful electric drive system:
40 HP electric motor with starter and disconnect
This configuration provides dependable operation for facilities requiring consistent industrial mixing performance.
Optional Equipment
The mixer can be customized with additional features to improve flexibility and efficiency:
Hydraulic discharge chute
Separately mounted power supply
Hydraulic leg adjustment
2,000 PSI hydraulic pressure washer
Three adjustable discharge height settings
These options allow users to configure the equipment according to specific project requirements.
2200 LB Pan Mixer Specifications
Specification Details
Mixer Capacity 2200 lbs.
Material Capacity Up to 1 Metric Ton of Refractory Castable
Mixing Time 1.5–2 Minutes
Drive System Heavy-Duty Planetary Gearbox
Power 40 HP Electric Motor
Weight 4,500 lbs.
Length 120 inches
Width 72 inches
Height (Down Position) 82 inches
Height (Raised Position) 103 inches
Material Discharge Height (Down Position) 52 inches
Material Discharge Height (Raised Position) 72 inches
Why Choose the 2200 LB Pan Mixer?
The 2200 LB Pan Mixer combines industrial strength, advanced mixing technology, and operator-friendly features to provide dependable performance for refractory and construction applications.
Main Advantages
Heavy-duty industrial construction
High-capacity mixing performance
Fast 1.5–2 minute mixing cycles
Planetary gearbox reliability
Accurate water control system
Easy transportation with forklift pickup points
Adjustable operating height
Designed for refractory castable materials
Industrial Pan Mixer: Heavy Duty Pan Mixer with 2200 LB Pan Mixer Technology for Refractory Applications
