Efficient mixing is a critical part of successful refractory installation projects. The Metric Ton Refractory Mixer is designed to provide consistent, high-quality mixing of dense refractory castable materials while delivering reliable performance in demanding industrial environments.
Featuring a heavy-duty hydrostatic drive system and planetary gearbox technology, this mixer is engineered to mix up to 1 metric ton of refractory castable with excellent consistency. The Bottom Discharge Pan Mixer design allows fast and controlled material unloading, improving productivity and reducing handling time.
The 2200 LB Pan Mixer provides contractors with a dependable solution for monolithic refractory installation, furnace repairs, kiln maintenance, and other high-temperature industrial applications.
High-Performance Metric Ton Refractory Mixer
The Metric Ton Refractory Mixer is built specifically for industrial users who require powerful mixing capability and consistent material preparation. Its robust construction allows it to handle dense refractory materials while maintaining efficient production cycles.
Common applications include:
Refractory castable mixing
Monolithic refractory installation
Furnace lining repairs
Cement kiln maintenance
Steel plant applications
Foundry projects
Industrial construction
The mixer ensures uniform material blending, helping contractors achieve reliable installation results.
Advanced Bottom Discharge Pan Mixer Technology
The Bottom Discharge Pan Mixer is designed to improve material handling efficiency after the mixing process. The bottom discharge system provides a convenient way to transfer mixed refractory materials directly to the application area.
Benefits of Bottom Discharge Design
Faster material unloading
Cleaner discharge operation
Reduced manual handling
Improved workflow efficiency
Better control during material placement
This design helps increase productivity on large-scale industrial projects.
2200 LB Pan Mixer for Heavy-Duty Applications
The 2200 LB Pan Mixer delivers high-capacity performance for contractors who need to prepare large amounts of refractory material efficiently. With the ability to mix up to 1 metric ton of castable, it reduces the number of batches required for major projects.
Key Advantages of the 2200 LB Pan Mixer
2200-pound mixing capacity
Up to 1 metric ton refractory castable mixing
Fast 1.5 to 2 minute mixing cycles
Heavy-duty industrial construction
Consistent material quality
Designed for continuous operation
The large capacity and efficient operation make this mixer suitable for demanding refractory applications.
Powerful Planetary Gearbox Mixing System
The Metric Ton Refractory Mixer uses a heavy-duty planetary gearbox designed to provide strong torque and dependable performance.
The gearbox system delivers:
High mixing power
Smooth operation
Reliable performance with dense materials
Long service life
Reduced maintenance requirements
This technology allows the mixer to maintain consistent results even with challenging refractory materials.
Precision Water Addition System
Proper water measurement is essential for achieving the correct refractory mix consistency. The 2200 LB Pan Mixer includes a Fill-Rite Water Meter and a 20-gallon dousing tank for accurate water control.
Water Control Features
Precise water measurement
Improved batch consistency
Better refractory performance
Reduced material variation
Easy operator adjustment
Accurate water addition helps ensure that each batch meets application requirements.
Easy Operation and Operator Controls
The mixer includes a 15 sq. ft. operator platform with a simple control panel designed for convenient operation.
The control system provides:
Forward/Stop/Reverse mixer rotation
Bottom slide door Open/Close operation
Fill-Rite Water Meter controls
Manual hydraulic mixer tilt controls for cleanout
These features allow operators to manage mixing functions efficiently while simplifying maintenance.
Safety and Mobility Features
The 2200 LB Pan Mixer is designed with practical features to improve operator safety and equipment handling.
Features include:
Forklift pickup points
Operator platform with guard rails
Access ladder
Telescoping adjustable legs
Stable operating structure
These features make transportation, setup, and daily operation easier on industrial job sites.
Power Configuration
The Metric Ton Refractory Mixer is equipped with a reliable electric power system:
40 HP electric motor with starter and disconnect
This configuration provides dependable performance for industrial facilities with suitable electrical power availability.
Optional Equipment
The Bottom Discharge Pan Mixer can be customized with additional options:
Hydraulic discharge chute
Separately mounted power supply
Hydraulic leg adjustment
2,000 PSI hydraulic pressure washer
Three adjustable discharge height settings
These options allow users to configure the mixer based on project requirements.
2200 LB Pan Mixer Specifications
Specification Details
Mixer Capacity 2200 lbs.
Material Capacity Up to 1 Metric Ton of Refractory Castable
Mixing Time 1.5–2 Minutes
Drive System Heavy-Duty Planetary Gearbox
Power 40 HP Electric Motor
Weight 4,500 lbs.
Length 120 inches
Width 72 inches
Height (Down Position) 82 inches
Height (Raised Position) 103 inches
Material Discharge Height (Down Position) 52 inches
Material Discharge Height (Raised Position) 72 inches
Why Choose the 2200 LB Pan Mixer?
The 2200 LB Pan Mixer combines high-capacity mixing, durable construction, and efficient material discharge to support demanding industrial applications.
Main Benefits
Designed for refractory castable materials
Large 1 metric ton mixing capability
Fast mixing cycles
Heavy-duty planetary gearbox
Efficient bottom discharge system
Accurate water measurement
Easy operation and maintenance
Reliable industrial performance
Metric Ton Refractory Mixer: Advanced Bottom Discharge Pan Mixer with 2200 LB Pan Mixer Capacity
