Efficient material preparation is essential for successful refractory and industrial applications. The Hydraulic Discharge Mixer is designed to provide powerful mixing performance, reliable operation, and controlled material unloading for demanding job sites.
Built with a heavy-duty hydrostatic drive system and advanced planetary gearbox technology, this mixer delivers exceptional torque and consistent mixing results. The High Torque Pan Mixer is engineered to process up to 1 metric ton of refractory castable, making it an ideal solution for monolithic refractory installation, furnace repairs, kiln maintenance, and industrial construction projects.
The 2200 LB Pan Mixer combines large-capacity mixing performance with a user-friendly design, helping contractors improve productivity while maintaining excellent material consistency.
Powerful Hydraulic Discharge Mixer for Industrial Applications
The Hydraulic Discharge Mixer provides a dependable solution for preparing dense refractory materials. Its hydraulic-powered discharge system allows operators to transfer mixed materials quickly and efficiently, reducing downtime during installation work.
This mixer is suitable for applications including:
Refractory castable preparation
Furnace lining repairs
Monolithic refractory installation
Cement kiln maintenance
Steel plant applications
Foundry operations
Industrial construction projects
The durable design ensures reliable performance in demanding environments.
High Torque Pan Mixer Technology
The High Torque Pan Mixer is designed to handle heavy and dense materials with ease. Its powerful planetary gearbox provides the torque required for consistent mixing while maintaining smooth operation.
Key Features of the High Torque Pan Mixer
High torque mixing performance
Heavy-duty planetary gearbox
Consistent material blending
Fast 1.5 to 2 minute mixing cycles
Designed for industrial applications
Reliable long-term operation
The advanced mixing system helps operators achieve uniform refractory material quality from every batch.
2200 LB Pan Mixer for Large-Volume Mixing
The 2200 LB Pan Mixer provides the capacity needed for large-scale refractory projects. Capable of mixing up to 1 metric ton of refractory castable, it reduces the number of batches required and improves overall job site efficiency.
Advantages of the 2200 LB Pan Mixer
2200-pound mixing capacity
Up to 1 metric ton material preparation
Faster production cycles
Reduced labor requirements
Consistent mix quality
Durable industrial construction
This high-capacity design makes the mixer ideal for contractors handling demanding refractory applications.
Advanced Planetary Gearbox Drive System
The Hydraulic Discharge Mixer uses a heavy-duty planetary gearbox to deliver powerful and dependable mixing performance.
The gearbox system provides:
High torque output
Smooth mixer operation
Improved material processing
Reduced maintenance needs
Extended equipment service life
This technology allows the mixer to handle dense refractory materials while maintaining consistent performance.
Efficient Hydraulic Discharge System
The hydraulic discharge design improves material handling by providing controlled and efficient unloading.
Hydraulic Discharge Benefits
Quick material release
Better discharge control
Reduced manual handling
Improved workflow efficiency
Cleaner operation
This feature helps contractors move mixed materials efficiently from preparation to placement.
Precision Water Addition System
Accurate water measurement is important for producing quality refractory mixes. The 2200 LB Pan Mixer includes a Fill-Rite Water Meter and 20-gallon dousing tank for precise water control.
Water Management Advantages
Accurate water measurement
Consistent batch quality
Improved refractory performance
Reduced material variations
Simple operator adjustment
Proper water control helps maintain the correct material consistency required for high-performance applications.
Operator-Friendly Mixer Design
The High Torque Pan Mixer includes a 15 sq. ft. operator platform with easy-to-use controls for efficient operation.
The control panel includes:
Forward/Stop/Reverse mixer rotation
Bottom slide door Open/Close operation
Fill-Rite Water Meter controls
Manual hydraulic mixer tilt controls for cleanout
Additional operator features include:
Guard rails and ladder
Forklift pickup points
Telescoping adjustable legs
Stable operating platform
These features improve safety, convenience, and maintenance efficiency.
Power Options
The Hydraulic Discharge Mixer is powered by:
40 HP electric motor with starter and disconnect
This power configuration provides reliable performance for industrial facilities requiring consistent mixing capability.
Optional Equipment
The 2200 LB Pan Mixer can be customized with additional options:
Hydraulic discharge chute
Separately mounted power supply
Hydraulic leg adjustment
2,000 PSI hydraulic pressure washer
Three adjustable discharge height settings
These options allow users to configure the mixer for specific project requirements.
2200 LB Pan Mixer Specifications
Specification Details
Mixer Capacity 2200 lbs.
Material Capacity Up to 1 Metric Ton of Refractory Castable
Mixing Time 1.5–2 Minutes
Drive System Heavy-Duty Planetary Gearbox
Power 40 HP Electric Motor
Weight 4,500 lbs.
Length 120 inches
Width 72 inches
Height (Down Position) 82 inches
Height (Raised Position) 103 inches
Material Discharge Height (Down Position) 52 inches
Material Discharge Height (Raised Position) 72 inches
Why Choose the 2200 LB Pan Mixer?
The 2200 LB Pan Mixer offers the strength, capacity, and reliability required for professional refractory mixing applications. Its high torque system, hydraulic discharge capability, and durable construction make it a valuable solution for industrial contractors.
Main Benefits
High-capacity refractory mixing
Powerful hydraulic discharge operation
Heavy-duty planetary gearbox
Fast mixing cycles
Accurate water control
Easy operation and maintenance
Reliable industrial performance
Designed for demanding applications
Hydraulic Discharge Mixer: High Torque Pan Mixer with 2200 LB Pan Mixer Capacity
