Fast Mixing Refractory Pan Mixer with Water Meter for Industrial Applications

2200 LB Pan Mixer – Efficient Mixing Equipment for Refractory Castable Materials

The 2200 LB Pan Mixer is a high-performance fast mixing refractory pan mixer with water meter designed to provide consistent and reliable mixing for demanding refractory applications. Built to mix up to 1 metric ton of refractory castable, this hydraulic pan mixer delivers excellent batch quality with rapid mixing cycles and precise water control.

Powered by a heavy-duty planetary gearbox, the mixer achieves efficient 1.5 to 2 minute mix times for most refractory materials. The integrated Fill-Rite water meter ensures accurate water measurement, helping operators maintain the correct material consistency for monolithic refractory installation, furnace repair, kiln maintenance, and industrial construction projects.

High-Speed Refractory Mixing Performance

The 2200 LB Pan Mixer is engineered for professionals who need dependable mixing performance in challenging environments. Its hydraulic drive system and heavy-duty gearbox provide strong torque and smooth operation, allowing the mixer to handle dense refractory castables with ease.

The combination of fast mixing capability and precise water control improves productivity while helping achieve uniform material quality throughout every batch.

Key Features of the 2200 LB Pan Mixer
Fast 1.5 to 2 minute mixing cycle for improved job efficiency
2200-pound hydraulic pan mixer with bottom discharge
Designed for mixing up to 1 metric ton of refractory castable
Fill-Rite water meter for accurate water addition
20-gallon dousing tank for quick water introduction
Heavy-duty planetary gearbox for reliable mixing performance
Forklift pickup points for convenient transportation
Operator platform with guard rails and ladder for safe access
Telescoping adjustable legs for flexible installation
Precision Water Management System

Accurate water addition is essential when preparing refractory castable materials. The 2200 LB Pan Mixer includes a Fill-Rite water meter that allows operators to control water quantities precisely, helping achieve consistent material performance and reducing the risk of improper mixing ratios.

This feature makes the mixer suitable for applications where refractory strength, durability, and installation quality are critical.

Bottom Discharge Design for Improved Productivity

The bottom discharge system allows fast and controlled removal of mixed material, helping reduce downtime between batches. This design supports efficient material handling during large-scale refractory installation projects and industrial repair operations.

Power Options

The standard power configuration includes:

40 HP electric motor with starter and disconnect

This powerful electric drive system provides dependable operation for industrial mixing requirements.

Available Options

The 2200 LB Pan Mixer can be equipped with additional features to meet specific application needs:

Hydraulic discharge chute
Separately mounted power supply
Hydraulic leg adjustment
2,000 PSI hydraulic pressure washer
Three height discharge adjustment settings
Technical Specifications
Specification Details
Equipment Type Fast Mixing Refractory Pan Mixer
Capacity 2200 LB
Mixing Application Refractory Castable
Mix Time 1.5–2 Minutes
Discharge System Bottom Discharge
Weight 4,500 lbs.
Length 120 inches
Width 72 inches
Height (Down Position) 82 inches
Height (Raised Position) 103 inches
Material Discharge Height (Down Position) 52 inches
Material Discharge Height (Raised Position) 72 inches
Applications of the 2200 LB Pan Mixer

The 2200 LB Pan Mixer is ideal for:

Monolithic refractory installation
Furnace lining projects
Kiln repair applications
Steel plant maintenance
Cement plant refractory work
Thermal processing equipment installation
Industrial refractory castable preparation
Reliable Fast Mixing Solution for Refractory Professionals

The 2200 LB Pan Mixer combines fast mixing performance, precise water measurement, and heavy-duty hydraulic operation to deliver dependable results in demanding industrial environments. With its advanced mixing technology and durable construction, this equipment is an excellent choice for contractors and facilities requiring consistent refractory material preparation.
