2200 LB Pan Mixer – Heavy-Duty Mixing Solution for Industrial Applications
The 2200 LB Pan Mixer is a powerful industrial mixer equipment solution designed for reliable mixing performance in demanding construction and refractory applications. This heavy-duty concrete pan mixer is engineered to mix up to 1 metric ton of refractory castable, providing consistent material quality for large-scale industrial projects.
Featuring a hydrostatic drive system and heavy-duty planetary gearbox, the 2200 LB Pan Mixer delivers strong torque and efficient mixing performance. With fast 1.5 to 2 minute mixing cycles, this equipment helps improve productivity while maintaining uniform material consistency.
Advanced Industrial Mixing Performance
Built for professional contractors and industrial users, the 2200 LB Pan Mixer provides dependable performance when handling dense materials. The heavy-duty planetary gearbox ensures smooth mixer operation and efficient power transfer, allowing the machine to achieve consistent results batch after batch.
Its robust design makes it suitable for applications requiring reliable concrete and refractory material preparation.
Features of the 2200 LB Pan Mixer
1.5 to 2 Minute Mix Time for increased production efficiency
2200-Pound Hydraulic Pan Mixer with Bottom Discharge
Capacity to mix up to 1 metric ton of refractory castable
Heavy-duty planetary gearbox for powerful mixing action
Fill-Rite Water Meter for accurate water measurement
20-gallon dousing tank for fast water introduction
Forklift pickup points for easy handling and transportation
Operator platform with guard rails and ladder for safe operation
Telescoping adjustable legs for flexible installation
Reliable Concrete Pan Mixer Design
The 2200 LB Pan Mixer is designed to provide excellent mixing performance for industrial applications. Its hydraulic operation allows smooth control, while the bottom discharge system enables quick unloading of mixed materials.
This design helps reduce downtime and supports efficient material handling in construction, refractory, and industrial environments.
Power Options
The standard power configuration includes:
40 HP electric motor with starter and disconnect
This electric-powered system provides reliable and efficient operation for industrial mixing requirements.
Available Options
Additional features can be added to improve flexibility and performance:
Hydraulic discharge chute
Separately mounted power supply
Hydraulic leg adjustment
2,000 PSI hydraulic pressure washer
Three height discharge adjustment settings
Technical Specifications
Specification Details
Equipment Type Industrial Mixer Equipment
Mixer Type Concrete Pan Mixer
Capacity 2200 LB
Application Refractory Castable and Industrial Materials
Mixing Capacity Up to 1 Metric Ton
Mix Time 1.5–2 Minutes
Weight 4,500 lbs.
Length 120 inches
Width 72 inches
Height (Down Position) 82 inches
Height (Raised Position) 103 inches
Material Discharge Height (Down Position) 52 inches
Material Discharge Height (Raised Position) 72 inches
Applications of the 2200 LB Pan Mixer
The 2200 LB Pan Mixer is ideal for:
Industrial concrete mixing
Refractory castable preparation
Monolithic refractory installation
Furnace lining projects
Kiln repair applications
Steel plant maintenance
Cement plant operations
Thermal processing equipment projects
Efficient Mixing Equipment for Industrial Projects
The 2200 LB Pan Mixer combines heavy-duty construction, hydraulic performance, and advanced mixing technology to provide a dependable solution for industrial material preparation. With fast mixing cycles, precise water control, and a durable design, this concrete pan mixer supports efficient operations in demanding working environments.
