Advanced Hydraulic Mixing Solution for Refractory Applications
The 2200 LB Pan Mixer is a heavy-duty hydraulic refractory mixing equipment solution designed for demanding industrial applications where consistent material preparation and reliable performance are essential. Built for mixing up to 1 metric ton of refractory castable, this industrial pan mixer delivers excellent batch consistency for refractory installation, furnace repair, kiln maintenance, and high-temperature construction projects.
Powered by a robust hydrostatic drive system and heavy-duty planetary gearbox, the mixer provides efficient mixing performance with typical cycle times of 1.5 to 2 minutes. Its durable construction makes it suitable for continuous use in challenging industrial environments.
High-Performance Heavy Duty Hydraulic Refractory Mixing Equipment
Proper mixing is critical for achieving the strength, durability, and thermal resistance required in refractory applications. The 2200 LB Pan Mixer is engineered to produce uniform refractory castable mixtures by combining powerful mechanical mixing action with precise water control.
The heavy-duty planetary gearbox ensures reliable operation while maintaining consistent mixing results across different refractory materials.
Key Features of the 2200 LB Pan Mixer
2200-Pound Hydraulic Pan Mixer with Bottom Discharge
The large-capacity hydraulic mixing system allows operators to prepare significant quantities of refractory castable efficiently. The bottom discharge design provides smooth material release and improves workflow during installation operations.
Fast 1.5 to 2 Minute Mixing Cycle
The advanced gearbox-driven mixing system helps achieve quick and consistent mixing cycles, reducing downtime and improving jobsite productivity.
Precise Water Management System
The integrated Fill-Rite water meter and 20-gallon dousing tank allow accurate water addition, helping maintain the correct consistency required for refractory castables.
Heavy-Duty Operator Platform
The 15 sq. ft. operator platform is designed for convenient operation and includes:
Forward, stop, and reverse mixer controls
Bottom slide door open/close controls
Manual hydraulic mixer tilt controls for cleaning
Guard rails for improved operator safety
Ladder access
Easy Transport and Installation
The mixer includes forklift pickup points for easier handling and positioning at industrial worksites. Telescoping adjustable legs provide flexibility for different installation conditions.
Power Option
The 2200 LB Pan Mixer is available with:
40 HP electric motor with starter and disconnect
This electric-powered system provides dependable performance for industrial facilities, workshops, and controlled construction environments.
Available Options
Additional configurations are available to support different operational requirements:
Hydraulic discharge chute
Separately mounted power supply
Hydraulic leg adjustment
2,000 PSI hydraulic pressure washer
Three-position height discharge adjustment
Technical Specifications
Specification Details
Mixer Capacity 2200 lbs.
Material Capacity Up to 1 metric ton refractory castable
Mixing Time 1.5–2 minutes
Drive System Hydrostatic drive with planetary gearbox
Weight 4,500 lbs.
Length 120 inches
Width 72 inches
Height (Down Position) 82 inches
Height (Raised Position) 103 inches
Material Discharge Height (Down Position) 52 inches
Material Discharge Height (Raised Position) 72 inches
Applications of the 2200 LB Pan Mixer
The 2200 LB Pan Mixer is designed for industries requiring reliable refractory mixing equipment, including:
Monolithic refractory installation
Furnace lining construction
Kiln repair projects
Steel plant maintenance
Cement plant refractory work
Industrial heat-processing facilities
High-temperature concrete applications
Reliable Refractory Mixing Equipment for Industrial Projects
The 2200 LB Pan Mixer combines high capacity, hydraulic operation, and precision control to meet the requirements of modern refractory contractors and industrial users. Its durable design, efficient mixing performance, and operator-friendly features make it a dependable choice for preparing refractory castables and other specialized materials.
For companies seeking heavy-duty hydraulic refractory mixing equipment, the 2200 LB Pan Mixer provides the performance, reliability, and versatility needed for demanding industrial applications.
