Professional construction, repair, and industrial projects require dependable machinery that can deliver accurate material placement and consistent performance. The Blastcrete Dampcon Rig is advanced concrete spraying equipment designed for dry-process shotcrete applications, refractory installations, and concrete repair projects. Combining a powerful mixer, material handling system, and proven gunite technology, the Dampcon Rig provides contractors with a complete solution for demanding shotcrete operations.
Designed as a reliable gunite machine with mixer, the Dampcon Rig helps improve productivity, simplify operation, and deliver high-quality results across multiple industries.
Advanced Concrete Spraying Equipment for Professional Applications
The Blastcrete Dampcon Rig is a predampening and gunning system engineered to predampen and install dry-process shotcrete materials. The unit integrates a 9 cubic foot paddle-style mixer, material elevator, and the proven Blastcrete 020 "Piccola" rotary gunite machine with a single-bolt clamping system.
This integrated design allows operators to efficiently mix, transport, and spray materials while maintaining consistent application quality.
The Benefits of a Gunite Machine with Mixer
A gunite machine with mixer provides contractors with a complete shotcrete solution by combining material preparation and spraying capabilities into one system. The Blastcrete Dampcon Rig offers several advantages:
Improved material consistency
Efficient shotcrete application
Reduced equipment handling
Faster project completion
Easy cleaning and maintenance
Reliable performance in demanding environments
By combining mixing and gunning functions, the Dampcon Rig helps simplify job site operations and improves overall productivity.
Key Features of the Blastcrete Dampcon Rig
The Blastcrete Dampcon Rig is designed with features that enhance efficiency and reliability:
9 Cubic Foot Capacity Paddle Mixer
The heavy-duty paddle mixer includes rubber wipers to ensure consistent material blending and reliable operation during continuous use.
Swing-Out Mixer for Easy Cleaning
The swing-out mixer design provides quick access for cleaning and maintenance, reducing downtime between projects.
Variable Speed Controls
Variable speed operation for the mixer, conveyor, and gunite machine allows operators to adjust material flow according to project requirements.
Blastcrete 020 Rotary Gunite Machine
The integrated Blastcrete 020 "Piccola" rotary gunite machine features a single-bolt clamping system and provides dependable shotcrete delivery.
Production Capacity
The Dampcon Rig offers a production range of 0 to 6 cubic yards per hour, making it suitable for both repair applications and larger construction projects.
Technical Specifications
The Blastcrete Dampcon Rig is engineered for demanding job site conditions:
Length: 205 inches
Width: 75 inches
Charging Height: 51 inches
Weight: 5,500 lbs
Air Requirements: 250 CFM at 80 PSI
Its compact design supports easier transportation and setup while maintaining strong operational performance.
Power Options
The Dampcon Rig is available with flexible power configurations:
Kubota V1505 29 HP water-cooled diesel engine
20 HP electric motor with starter and disconnect
These power options allow contractors to select the best configuration for their specific operating environment.
Mounting Options
To provide maximum job site flexibility, the Blastcrete Dampcon Rig is available with:
Dual axle trailer configuration for easy transportation
Skid mount with forklift pockets for convenient handling
An optional hydraulic water booster pump is available for applications requiring additional water pressure support.
Applications of the Blastcrete Dampcon Rig
The Dampcon Rig is versatile concrete spraying equipment suitable for many industries and applications, including:
Concrete Repair and Restoration
Structural concrete repairs
Bridge rehabilitation
Highway maintenance
Commercial restoration projects
Underground and Infrastructure Projects
Tunnel construction
Mining support
Rock stabilization
Underground repairs
Industrial Applications
Refractory gunning installations
Furnace and kiln repairs
Industrial facility maintenance
Heat-resistant lining applications
Its combination of mobility, efficiency, and reliable performance makes the Dampcon Rig a valuable solution for contractors across different sectors.
Why Choose the Blastcrete Dampcon Rig?
The Blastcrete Dampcon Rig delivers the performance contractors need from modern concrete spraying equipment. Its integrated design provides:
Consistent dry-process shotcrete application
Reliable mixing and material delivery
Reduced maintenance requirements
Faster cleanup and setup
Durable construction for harsh environments
Flexible power and mounting options
Whether used for concrete rehabilitation, refractory work, or underground construction, the Dampcon Rig provides dependable results for professional shotcrete applications.
Concrete Spraying Equipment for Efficient Shotcrete Applications: The Blastcrete Dampcon Rig
