Construction, mining, refractory, and concrete repair projects require powerful equipment that can deliver consistent material placement and dependable performance. The Blastcrete Dampcon Rig is an advanced shotcrete solution designed with a proven rotary gunite machine to efficiently install dry-process shotcrete materials. Built for demanding applications, the Dampcon Rig provides contractors with a reliable system for concrete repair, refractory installation, underground support, and infrastructure rehabilitation.
As a versatile diesel shotcrete machine, the Dampcon Rig combines mobility, power, and precision to deliver high-quality shotcrete results in challenging job site conditions.
Advanced Rotary Gunite Machine Technology
The Blastcrete Dampcon Rig features the proven Blastcrete 020 "Piccola" rotary gunite machine, engineered for reliable dry-process shotcrete application. The system includes a single-bolt clamping design that helps simplify operation and maintenance while providing consistent material delivery.
Combined with a high-capacity mixer and material elevator, the rotary gunite system creates an efficient workflow for contractors who require dependable shotcrete placement.
Powerful Diesel Shotcrete Machine for Demanding Projects
A dependable diesel shotcrete machine provides the flexibility and power required for remote construction sites, infrastructure projects, and industrial applications. The Blastcrete Dampcon Rig is powered by a Kubota V1505 29 HP water-cooled diesel engine, providing reliable performance where electric power may not be available.
The system is suitable for applications such as:
Concrete repair and restoration
Bridge rehabilitation
Tunnel construction and maintenance
Underground mining support
Rock stabilization
Refractory gunning installations
Industrial concrete repairs
Its durable design allows contractors to complete projects efficiently while maintaining consistent shotcrete quality.
Key Features of the Blastcrete Dampcon Rig
The Dampcon Rig is designed to improve productivity and simplify shotcrete operations with advanced features, including:
9 Cubic Foot Capacity Paddle Mixer
The high-performance paddle mixer features rubber wipers that provide consistent material blending and reliable operation.
Swing-Out Mixer Design
The swing-out mixer allows for quick cleaning and easier maintenance, reducing downtime between applications.
Variable Speed Controls
Operators can adjust the speed of the mixer, conveyor, and gunite machine to achieve better control over material flow and application requirements.
Blastcrete 020 Rotary Gunite Machine
The integrated rotary gunite machine delivers dependable dry-process shotcrete performance with a production capacity of 0 to 6 cubic yards per hour.
Technical Specifications
The Blastcrete Dampcon Rig is designed for professional construction and industrial environments:
Length: 205 inches
Width: 75 inches
Charging Height: 51 inches
Weight: 5,500 lbs
Air Requirements: 250 CFM at 80 PSI
Its compact design makes transportation and setup easier while maintaining excellent production capability.
Flexible Power Options
The Dampcon Rig is available with multiple power configurations:
Kubota V1505 29 HP water-cooled diesel engine
20 HP electric motor with starter and disconnect
These options allow contractors to choose the ideal power source based on job site requirements.
Mounting Options for Job Site Versatility
The Blastcrete Dampcon Rig can be configured for different operating environments with:
Dual axle trailer for easy transportation
Skid mount with forklift pockets for convenient handling
An optional hydraulic water booster pump is also available to enhance system performance for specialized applications.
Applications of the Blastcrete Dampcon Rig
The Dampcon Rig provides a versatile solution for a wide range of industries:
Construction and Infrastructure
Structural concrete restoration
Bridge repairs
Tunnel lining
Highway rehabilitation
Commercial concrete repair
Mining and Underground Projects
Mine ground support
Rock reinforcement
Underground excavation stabilization
Shaft and tunnel repairs
Industrial and Refractory Applications
Furnace repairs
Kiln maintenance
Heat-resistant lining installation
Industrial refractory restoration
The combination of a rotary gunite machine, powerful engine options, and efficient material handling makes the Dampcon Rig suitable for demanding applications.
Benefits of Choosing the Blastcrete Dampcon Rig
The Blastcrete Dampcon Rig helps contractors achieve better project results through:
Consistent dry-process shotcrete application
Reliable rotary gunite performance
Efficient material mixing and delivery
Reduced maintenance and cleanup time
Flexible power configurations
Durable construction for harsh environments
Whether operating on a remote construction site or performing specialized industrial repairs, the Dampcon Rig provides the performance and reliability needed for professional shotcrete work.
Rotary Gunite Machine for Reliable Shotcrete Applications: The Blastcrete Dampcon Rig
