The HBS-1500 Ball Seat Pump is an advanced Diesel Powered Concrete Pump designed for contractors who require powerful pumping performance, long-distance material delivery, and reliable operation on demanding construction sites. Developed for gypsum flooring applications, concrete pumping, and repair projects, the Blastcrete HBS-1500 combines a high-performance hydraulic pump system with an efficient mixing unit.
With its powerful diesel engine configuration and optional electric power setup, the HBS-1500 provides flexibility for different jobsite requirements while maintaining consistent pumping performance.
High-Performance Diesel Powered Concrete Pump System
The Blastcrete HBS-1500 Ball Seat Pump is engineered for professional contractors who need dependable pumping capability over extended distances. The machine features a 4-inch hydraulic ball seat pump capable of producing 1000 PSI line pressure, allowing it to pump gypsum materials beyond 600 feet efficiently.
The durable diesel-powered system provides excellent mobility and power for remote construction locations where consistent performance is required. For indoor or stationary applications, contractors can also select the Electric Concrete Pump Option for convenient operation and reduced emissions.
Efficient Mixing and Pumping Performance
The HBS-1500 is equipped with a 12 cubic foot hydraulic spiral mixer designed for fast and consistent material preparation. With a 30-second mixing cycle, the system helps improve productivity by maintaining a steady supply of properly mixed material.
The integrated 26 cubic foot receiving hopper includes a hydraulic agitator that supports smooth material flow and minimizes interruptions during pumping operations.
Key Features of HBS-1500 Ball Seat Pump
4-Inch Hydraulic Ball Seat Pump
Produces up to 1000 PSI pump pressure capability
Designed for long-distance pumping applications
Reduces maintenance requirements with durable ball seat technology
Hydraulic Spiral Mixer System
12 cubic foot mixer capacity
30-second mixing cycle
Hydraulic dump operation for improved workflow
Large Receiving Hopper
26 cubic foot hopper capacity
Hydraulic conveying agitator
Supports continuous material pumping
Heavy-Duty Construction
Strong tubular frame design
Dual axle trailer with two braking axles
Four manual leveling jacks for jobsite stability
Specifications of HBS-1500 Diesel Powered Concrete Pump
Length: 234 inches
Width: 92 inches
Height (Water Tank): 93 inches
Height (Mixer Dump Position): 95 inches
Mixer Charging Height: 57 inches
Weight: 8,350 lbs.
Output Capacity: 0–15 cubic yards per hour
Mixer Capacity: 12 cubic feet
Receiving Hopper Capacity: 26 cubic feet
Pump Type: 4-inch Hydraulic Ball Seat Pump
Power Options for Flexible Jobsite Performance
The HBS-1500 is available with:
Diesel Power Configuration
70 HP Kubota Water-Cooled Diesel Engine
Ideal for mobile construction applications
Provides reliable operation in demanding environments
Electric Concrete Pump Option
Suitable for indoor projects and stationary applications
Helps reduce jobsite emissions
Provides an alternative power solution for contractors with electrical access
Applications of HBS-1500 Ball Seat Pump
The HBS-1500 is suitable for:
Gypsum flooring installation
Concrete pumping applications
Self-leveling floor systems
Commercial flooring projects
Industrial construction work
Concrete repair applications
Underlayment pumping
Its versatile design allows contractors to handle both gypsum materials and concrete mixes containing up to 1/2-inch aggregate.
Advantages of Choosing HBS-1500
The Diesel Powered Concrete Pump design of the HBS-1500 provides contractors with:
High-pressure pumping capability
Long-distance material delivery
Efficient mixing performance
Low-maintenance operation
Heavy-duty construction
Multiple power options
The ball seat pumping system helps reduce wear costs while providing dependable performance for professional construction teams.
Optional Equipment
Available options include:
2000 PSI hydraulic pressure washer
Spare tire
Electric power configuration
Skid mount
Custom paint options
Diesel Powered Concrete Pump HBS-1500 Ball Seat Pump with Electric Concrete Pump Option
