Modern flooring projects require reliable equipment that can deliver consistent material flow, efficient operation, and excellent pumping performance. The HBS-1500 Ball Seat Pump is a powerful heavy duty gypsum floor installation machine designed for professional contractors who need dependable performance for gypsum flooring, concrete pumping, and underlayment applications.
Combining a portable design with advanced hydraulic technology, the HBS-1500 works as a complete portable hydraulic concrete pump with mixer, providing contractors with an efficient solution for mixing and pumping materials over long distances.
High-Performance Gypsum Flooring Installation Equipment
The Blastcrete HBS-1500 Ball Seat Pump is engineered specifically for demanding gypsum flooring applications. Its advanced hydraulic pumping system allows contractors to move materials efficiently across large job sites while maintaining consistent quality.
The machine features a powerful 4-inch hydraulic ball seat pump capable of producing 1000 PSI line pressure. This enables the HBS-1500 to pump gypsum materials beyond 600 feet with a production capacity of up to 130 bags per hour.
The innovative ball seat pump design helps reduce maintenance costs and extends equipment service life compared with conventional pumping systems.
Portable Hydraulic Concrete Pump with Mixer System
The HBS-1500 combines mixing and pumping functions into one compact and efficient machine. The integrated design eliminates the need for separate mixing equipment and improves jobsite productivity.
The unit is equipped with a 12 cubic foot hydraulic spiral mixer featuring a fast 30-second mixing cycle. After mixing, the material is transferred into a 26 cubic foot receiving hopper with a hydraulic agitator that supports smooth and continuous material delivery.
This makes the HBS-1500 an excellent choice for contractors requiring a portable hydraulic concrete pump with mixer for demanding flooring and construction projects.
Key Features of HBS-1500 Ball Seat Pump
4-Inch Hydraulic Ball Seat Pump
Provides up to 1000 PSI pump pressure capability
Designed for long-distance material pumping
Reduces wear and maintenance requirements
Hydraulic Spiral Mixer
12 cubic foot mixer capacity
30-second mixing cycle
Hydraulic dump system for efficient operation
Large Receiving Hopper
26 cubic foot hopper capacity
Hydraulic conveying agitator
Maintains consistent material flow
Heavy-Duty Construction Design
Heavy-duty tubular frame
Dual axle trailer with two braking axles
Four manual leveling jacks for improved stability
HBS-1500 Specifications
Length: 234 inches
Width: 92 inches
Height (Water Tank): 93 inches
Height (Mixer Dump Position): 95 inches
Mixer Charging Height: 57 inches
Weight: 8,350 lbs.
Output Capacity: 0–15 cubic yards per hour
Mixer Capacity: 12 cubic feet
Receiving Hopper Capacity: 26 cubic feet
Pump Type: 4-inch Hydraulic Ball Seat Pump
Applications of Heavy Duty Gypsum Floor Installation Machine
The HBS-1500 is suitable for:
Gypsum floor installation projects
Self-leveling flooring applications
Commercial flooring construction
Industrial flooring systems
Concrete pumping applications
Underlayment installation
Concrete repair projects
The machine can also pump concrete mixes containing aggregates up to 1/2 inch, making it a versatile solution for multiple construction applications.
Powerful and Flexible Power Options
The HBS-1500 Ball Seat Pump is available with:
Diesel Power System
70 HP Kubota Water-Cooled Diesel Engine
Ideal for mobile construction sites
Provides dependable power for demanding operations
Electric Power Option
Suitable for indoor and stationary applications
Provides additional operating flexibility
Advantages of HBS-1500 Ball Seat Pump
Contractors choose the HBS-1500 because it offers:
Long-distance pumping capability
High production output
Integrated mixing and pumping operation
Lower maintenance requirements
Portable jobsite performance
Heavy-duty construction
Versatile material handling capability
Its combination of hydraulic power, mixer efficiency, and portability makes it a reliable choice for professional flooring contractors.
Optional Equipment
Available options include:
2000 PSI hydraulic pressure washer
Spare tire
Electric power configuration
Skid mount
Custom paint options
Heavy Duty Gypsum Floor Installation Machine HBS-1500 Ball Seat Pump with Portable Hydraulic Concrete Pump Technology
