RMX-5000 Refractory Shotcrete Pump for High-Performance Material Placement
The RMX-5000 Refractory Shotcrete Pump is engineered for contractors and industrial maintenance teams that require reliable, high-pressure pumping of refractory shotcrete and other cementitious materials. Designed with a 3-inch ultra high-pressure swing tube pump and a powerful hydraulic mixing system, the RMX-5000 delivers exceptional performance for steel mills, cement plants, power stations, petrochemical facilities, foundries, and mining operations.
With its ability to pump dense refractory materials over extended distances, the RMX-5000 helps improve productivity while maintaining consistent material flow and application quality.
Designed for Demanding Refractory Applications
Refractory shotcrete is commonly used to repair and protect high-temperature structures such as furnaces, kilns, boilers, incinerators, and ladles. These applications require equipment capable of handling abrasive, dense materials while maintaining reliable pressure and consistent output.
The RMX-5000 Refractory Shotcrete Pump is specifically designed for these demanding conditions. Its heavy-duty construction and advanced hydraulic system allow operators to complete refractory installations efficiently while minimizing downtime.
Ultra High-Pressure Pumping Performance
The RMX-5000 features a 3" × 18" ultra high-pressure swing tube pump that delivers 2,200 PSI piston face pressure, making it suitable for dense refractory shotcrete and conventional shotcrete applications.
Pumping Advantages
2,200 PSI ultra high-pressure performance
Long-distance pumping capability
Smooth and continuous material flow
Heavy-duty swing tube technology
Reliable operation with abrasive refractory materials
This pumping system ensures accurate material placement and consistent performance throughout demanding industrial projects.
High-Capacity Hydraulic Mixing System
Proper mixing is essential for high-quality refractory installation. The RMX-5000 offers two hydraulic mixer configurations to meet different project requirements.
Hydraulic Paddle Mixer
The 1,000 lb. hydraulic paddle mixer is specifically designed for refractory applications and features:
Heavy-duty planetary gearbox drive
Uniform mixing of dense refractory materials
Excellent batch consistency
Reliable hydraulic performance
Hydraulic Spiral Mixer
For conventional construction applications, the machine is also available with a 1,000 lb. hydraulic spiral mixer suitable for:
Conventional shotcrete
Stucco
Plaster
Cement-based materials
This versatility allows contractors to use one machine for multiple material types and project requirements.
Standard Features
The RMX-5000 includes a range of features designed to improve efficiency, safety, and ease of maintenance.
Hydraulic receiving hopper lift for quick access to the swing tube assembly
1,200 lb. receiving hopper with hydraulic agitator
3-inch heavy-duty side discharge
Fill Rite water meter
Reliable solid-state electronics
CE Certified construction
These features help reduce maintenance time while improving equipment reliability during continuous operation.
Technical Specifications
Specification Details
Pump Type 3" × 18" Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Mixer Capacity 1,000 lb Hydraulic Paddle or Spiral Mixer
Output Capacity 0–5 Cubic Yards Per Hour
Hopper Capacity 1,200 lb Hydraulic Receiving Hopper
Discharge 3" Side Discharge
Trailer Single 6,000 lb Capacity Axle with Electric Brakes
Dimensions 165" × 76" × 63"
Weight 5,000 lbs
Available Power Options
The RMX-5000 Refractory Shotcrete Pump is available with two dependable power configurations.
Kubota Diesel Engine
Kubota V3600
66 HP
Water-cooled diesel engine
Excellent for outdoor and remote industrial sites
Electric Motor
50 HP electric motor
Ideal for indoor plants and manufacturing facilities
Quiet, efficient operation with consistent performance
Optional Equipment
Expand the capabilities of the RMX-5000 with optional accessories, including:
2,000 PSI Hydraulic Pressure Washer
Vogel Automatic Lubrication System
150-Gallon Water Tank with 2" Flow Meter
Spare Tire
Pendant Remote Control
Wireless Remote Control
Skid-Mounted Configuration with Forklift Tubing
These options help improve maintenance efficiency, mobility, and operator convenience.
Industrial Applications
The RMX-5000 Refractory Shotcrete Pump is designed for a wide range of industrial applications, including:
Steel mills
Cement manufacturing plants
Power generation facilities
Petrochemical plants
Aluminum smelters
Glass manufacturing plants
Foundries
Incinerators
Industrial furnace relining
Kiln maintenance
Boiler repairs
Tunnel construction
Mining operations
Conventional shotcrete projects
Benefits of the RMX-5000 Refractory Shotcrete Pump
The RMX-5000 delivers the performance required for demanding refractory applications while helping contractors improve efficiency and reduce maintenance time.
Key Benefits
Ultra high-pressure pumping up to 2,200 PSI
High-capacity 1,000 lb. hydraulic mixing system
Heavy-duty 3-inch swing tube pump
Long-distance pumping capability
Excellent performance with dense refractory materials
Hydraulic hopper lift for easy maintenance
Diesel and electric power options
CE Certified construction
Built for continuous industrial operation
Why Choose the RMX-5000?
The RMX-5000 Refractory Shotcrete Pump combines advanced pumping technology, dependable hydraulic mixing, and durable construction in one versatile machine. Whether you are repairing industrial furnaces, installing refractory linings, or completing high-volume shotcrete projects, the RMX-5000 is engineered to provide reliable performance and long service life.
Its flexibility to handle refractory materials, conventional shotcrete, stucco, and plaster makes it a valuable investment for contractors serving multiple industries.
