3 Inch Swing Tube Pump RMX-5000 High-Pressure Mixer/Pump for Refractory, Shotcrete & Industrial Applications

RMX-5000 3 Inch Swing Tube Pump for Superior Material Pumping Performance

The RMX-5000 3 Inch Swing Tube Pump is a powerful, ultra high-pressure mixer and pumping system designed for demanding refractory, shotcrete, stucco, plaster, and cement-based material applications. Built with advanced swing tube technology, the RMX-5000 delivers reliable pumping performance, consistent material flow, and exceptional durability for industrial and construction projects.

Designed for extreme-distance pumping applications, this heavy-duty machine combines a 3-inch swing tube pump, high-capacity hydraulic mixing system, and rugged construction to provide dependable performance in challenging environments.

High-Performance 3 Inch Swing Tube Pump Technology

A 3 Inch Swing Tube Pump is designed to efficiently transfer dense and abrasive materials while maintaining consistent pressure and smooth operation. The RMX-5000 utilizes a 3" × 18" ultra high-pressure swing tube pump engineered for demanding applications where reliability and power are essential.

The swing tube system provides:

Efficient material transfer
Smooth pumping operation
Excellent handling of dense refractory mixes
Reduced downtime during continuous operation
Reliable performance over long pumping distances

With 2,200 PSI piston face pressure, the RMX-5000 is capable of handling demanding refractory shotcrete and conventional shotcrete applications.

RMX-5000 Designed for Refractory & Shotcrete Applications

The RMX-5000 3 Inch Swing Tube Pump is specifically developed for industries requiring high-pressure material placement and consistent mixing performance.

Common applications include:

Refractory installation
Furnace and kiln repair
Steel plant maintenance
Cement plant projects
Shotcrete construction
Tunnel construction
Mining operations
Industrial concrete repair
Stucco and plaster pumping

Its ability to pump materials over extreme distances makes it an excellent choice for large-scale industrial projects.

Powerful Hydraulic Mixing System

The RMX-5000 provides flexible mixing options to support different materials and applications.

1,000 lb. Hydraulic Paddle Mixer

The paddle mixer is designed for refractory applications and features:

1,000 lb. mixing capacity
Planetary gearbox drive
Consistent blending of dense refractory materials
Reliable hydraulic operation
1,000 lb. Hydraulic Spiral Mixer

The spiral mixer is optimized for:

Conventional shotcrete
Stucco
Plaster
Cement-based materials

These high-capacity mixing systems ensure uniform material preparation before pumping, improving application quality and productivity.

Key Features of the RMX-5000 3 Inch Swing Tube Pump

The RMX-5000 includes advanced features designed to improve performance and simplify operation.

Ultra High-Pressure Pumping
3" × 18" ultra high-pressure swing tube pump
2,200 PSI piston face pressure
Designed for refractory shotcrete and dense shotcrete materials
Long-distance pumping capability
Efficient Maintenance Design
Hydraulic receiving hopper lift
Easy access to swing tube section for cleaning and maintenance
Reduced service time and improved uptime
Additional Standard Features
1,200 lb. receiving hopper with hydraulic agitator
3-inch heavy-duty side discharge
Fill Rite water meter
Reliable solid-state electronics
CE Certification
RMX-5000 Technical Specifications
Specification Details
Pump Type 3" × 18" Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Mixer Capacity 1,000 lb Hydraulic Paddle or Spiral Mixer
Output Capacity 0–5 Cubic Yards Per Hour
Discharge 3" Side Discharge
Hopper Capacity 1,200 lb Receiving Hopper with Hydraulic Agitator
Trailer Single 6,000 lb Capacity Axle with Electric Braking and Lights
Dimensions 165" × 76" × 63"
Weight 5,000 lbs
Power Options

The RMX-5000 3 Inch Swing Tube Pump is available with reliable power configurations to meet different job site requirements.

Kubota Diesel Engine
Kubota V3600
66 HP
Water-cooled diesel engine
Ideal for remote construction and industrial locations
Electric Motor
50 HP electric motor
Suitable for indoor facilities
Efficient operation where electrical power is available
Optional Equipment

The RMX-5000 can be customized with additional accessories, including:

2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
150-gallon water tank with 2" flow meter
Spare tire mounted
Pendant remote control
Wireless remote control
Skid-mounted frame with forklift tubing
Advantages of the RMX-5000 3 Inch Swing Tube Pump

The RMX-5000 provides contractors and industrial operators with a reliable solution for high-pressure pumping applications.

Key Benefits
High-pressure pumping up to 2,200 PSI
Heavy-duty 3-inch swing tube pump design
Excellent performance with refractory and shotcrete materials
Large-capacity hydraulic mixing system
Long-distance pumping capability
Easy maintenance access
Multiple power options
Durable construction for demanding environments
Designed for continuous industrial operation
Why Choose the RMX-5000?

The RMX-5000 3 Inch Swing Tube Pump combines advanced pumping technology, powerful hydraulic mixing, and industrial-grade durability to handle challenging material placement projects. Whether used for refractory repair, shotcrete construction, stucco application, or plaster pumping, the RMX-5000 delivers consistent performance and dependable operation.

Its high-pressure capability and versatile mixer options make it a valuable solution for contractors, industrial maintenance teams, and construction professionals worldwide.
