RMX-5000 Dense Shotcrete Pump for Reliable High-Pressure Material Placement
The RMX-5000 Dense Shotcrete Pump is an advanced mixing and pumping system designed for demanding shotcrete, refractory, stucco, plaster, and concrete applications. Engineered for handling dense materials, the RMX-5000 combines an ultra high-pressure 3-inch swing tube pump with a high-capacity hydraulic mixing system to provide consistent performance in challenging construction and industrial environments.
With powerful 2,200 PSI piston face pressure, the RMX-5000 delivers the strength required for pumping dense shotcrete materials over extreme distances while maintaining smooth material flow and reliable operation.
High-Performance Dense Shotcrete Pump Technology
Dense shotcrete applications require equipment capable of handling thick, abrasive, and heavy materials without sacrificing pumping efficiency. The RMX-5000 is designed specifically for these demanding conditions.
The RMX-5000 Dense Shotcrete Pump features:
Ultra high-pressure 3" × 18" swing tube pump
2,200 PSI piston face pressure
Heavy-duty material handling capability
Consistent shotcrete placement
Long-distance pumping performance
This advanced pump design allows contractors to complete large-scale shotcrete projects with improved efficiency and dependable results.
Designed for Dense Shotcrete Applications
Dense shotcrete is commonly used in projects requiring strong structural support, durability, and precise material placement. The RMX-5000 provides the pumping power needed for applications where conventional equipment may struggle.
Typical dense shotcrete applications include:
Tunnel construction
Mining operations
Underground support projects
Concrete rehabilitation
Structural reinforcement
Retaining wall construction
Bridge repair
Industrial concrete maintenance
Heavy-duty construction projects
The RMX-5000 helps operators achieve consistent application quality by maintaining steady pressure and uniform material delivery.
Advanced Hydraulic Mixing System
The RMX-5000 Dense Shotcrete Pump includes flexible mixing options designed to meet different project requirements.
Hydraulic Paddle Mixer for Refractory Applications
The 1,000 lb. hydraulic paddle mixer provides:
Planetary gearbox drive
Uniform mixing of dense materials
Reliable hydraulic operation
Excellent consistency for refractory mixes
Hydraulic Spiral Mixer for Shotcrete and Plaster
The 1,000 lb. hydraulic spiral mixer is ideal for:
Dense shotcrete
Conventional shotcrete
Stucco applications
Plaster materials
Cement-based mixes
These high-capacity mixing systems ensure materials are properly blended before pumping, improving productivity and application performance.
Ultra High-Pressure Pumping Performance
The RMX-5000 uses advanced swing tube technology to deliver powerful pumping performance for dense materials.
Pumping Advantages
3-inch swing tube pump design
2,200 PSI maximum pressure
Smooth material transfer
Reduced interruptions during operation
Capability for extreme-distance pumping
This makes the RMX-5000 an excellent choice for contractors requiring a dependable Dense Shotcrete Pump for demanding job sites.
Key Features of the RMX-5000 Dense Shotcrete Pump
The RMX-5000 is built with features that improve operation, maintenance, and reliability.
Standard Features
2200 PSI piston face pressure
1,000 lb. hydraulic paddle mixer
1,000 lb. hydraulic spiral mixer option
Hydraulic receiving hopper lift
Easy access to swing tube section for cleaning and maintenance
Fill Rite water meter
3-inch HD side discharge
Reliable solid-state electronics
CE Certification
These features help reduce downtime and improve overall equipment efficiency.
RMX-5000 Technical Specifications
Specification Details
Pump Type 3" × 18" Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Mixer Capacity 1,000 lb Hydraulic Paddle or Spiral Mixer
Output Capacity 0–5 Cubic Yards Per Hour
Discharge 3" Side Discharge
Hopper Capacity 1,200 lb Receiving Hopper with Hydraulic Agitator
Trailer Single 6,000 lb Capacity Axle with Electric Braking and Lights
Dimensions 165" × 76" × 63"
Weight 5,000 lbs
Power Options for the RMX-5000
The RMX-5000 Dense Shotcrete Pump is available with reliable power options for different operating conditions.
Kubota Diesel Engine
Kubota V3600
66 HP
Water-cooled diesel engine
Suitable for remote construction locations
Electric Motor
50 HP electric motor
Ideal for indoor facilities and industrial plants
Efficient operation with available electrical power
Optional Equipment
The RMX-5000 can be customized with additional accessories to increase productivity and convenience.
Available options include:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
150-gallon water tank with 2" flow meter
Spare tire mounted
Pendant remote control
Wireless remote control
Skid-mounted frame with forklift tubing
Industrial Applications of the RMX-5000 Dense Shotcrete Pump
The RMX-5000 is designed for a variety of professional applications, including:
Dense shotcrete placement
Refractory installation
Tunnel lining
Mining support
Underground construction
Concrete repair
Industrial furnace maintenance
Cement plant applications
Steel mill projects
Infrastructure rehabilitation
Commercial construction
Benefits of Using the RMX-5000 Dense Shotcrete Pump
The RMX-5000 provides contractors with the performance and reliability required for demanding shotcrete applications.
Main Benefits
Powerful 2,200 PSI pumping capability
Designed for dense and abrasive materials
High-capacity hydraulic mixing system
Long-distance material pumping
Heavy-duty swing tube technology
Easy cleaning and maintenance
Multiple power configurations
Durable industrial construction
Reliable operation in demanding environments
Why Choose the RMX-5000 Dense Shotcrete Pump?
The RMX-5000 Dense Shotcrete Pump combines high-pressure pumping technology with advanced hydraulic mixing to provide a complete solution for professional shotcrete applications. Its durable design, flexible mixer options, and powerful pumping capability make it suitable for contractors working in construction, mining, infrastructure, and industrial markets.
Whether handling dense shotcrete, refractory materials, or specialty concrete mixes, the RMX-5000 delivers the performance needed for efficient and successful project completion.
