RMX-5000 Electric Shotcrete Mixer Pump for Professional Applications
The Electric Shotcrete Mixer Pump is a reliable solution for contractors who need efficient mixing and pumping performance for shotcrete, concrete, stucco, plaster, and refractory applications. The RMX-5000 Mixer/Pump combines a powerful electric motor option with advanced hydraulic mixing technology and an ultra high-pressure 3-inch swing tube pump system.
Designed for demanding construction and industrial environments, the RMX-5000 delivers consistent material flow, high-pressure pumping capability, and dependable operation for a wide range of applications.
High-Performance Electric Shotcrete Pumping System
A modern Electric Shotcrete Mixer Pump provides an efficient alternative for job sites where electrical power is available. The RMX-5000 is engineered to provide reliable performance while reducing dependence on diesel fuel and supporting indoor or stationary applications.
Key advantages include:
50 HP electric motor power option
Ultra high-pressure pumping performance
Hydraulic mixing capability
Consistent shotcrete material delivery
Reduced maintenance requirements
Suitable for industrial and construction environments
The RMX-5000 provides contractors with an effective solution for projects requiring precision material mixing and pumping.
Advanced 3-Inch Swing Tube Pump Technology
The RMX-5000 features a 3" x 18" ultra high-pressure swing tube pump designed for challenging shotcrete and concrete applications.
Pump Performance Features
Pump pressure up to 2,200 PSI
High piston face pressure for refractory shotcrete
3-inch side discharge outlet
Output capacity of 0–5 cubic yards per hour
Designed for long-distance material pumping
This powerful pumping system ensures smooth delivery of shotcrete and concrete materials while maintaining consistent application performance.
Hydraulic Mixing System for Electric Shotcrete Applications
The RMX-5000 offers flexible hydraulic mixer options to handle different construction materials.
Hydraulic Paddle Mixer
The 1,000 lb. capacity hydraulic paddle mixer with planetary gearbox drive is designed for:
Refractory applications
Dense shotcrete materials
Industrial repair work
Specialty construction mixtures
Benefits include:
Strong mixing performance
Uniform material consistency
Reliable hydraulic operation
Improved productivity
Hydraulic Spiral Mixer
The 1,000 lb. capacity hydraulic spiral mixer is ideal for:
Conventional shotcrete
Plaster applications
Stucco materials
Cement-based mixtures
The spiral mixer provides efficient material blending and supports consistent pumping performance.
Applications of RMX-5000 Electric Shotcrete Mixer Pump
The RMX-5000 is designed for multiple industries requiring dependable electric-powered mixing and pumping equipment.
Common applications include:
Shotcrete construction
Concrete spraying
Tunnel construction
Mining support
Refractory installation
Concrete repair
Structural reinforcement
Industrial maintenance
Stucco application
Plaster spraying
Infrastructure projects
The electric configuration makes the RMX-5000 suitable for facilities, workshops, and construction locations with access to electrical power.
Features of RMX-5000 Electric Shotcrete Mixer Pump
The RMX-5000 includes advanced features designed for performance, durability, and ease of maintenance.
Standard Features
3" x 18" ultra high-pressure swing tube pump
2,200 PSI piston face pressure
1,000 lb. hydraulic paddle mixer
Planetary gearbox drive for refractory applications
1,000 lb. hydraulic spiral mixer option
Hydraulic receiving hopper lift
Easy access to swing tube section for cleaning and maintenance
Fill Rite water meter
Convenient 3" HD side discharge
Reliable solid-state electronics
CE Certification
RMX-5000 Technical Specifications
Specification Details
Pump Type 3" x 18" Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Mixer Capacity 1,000 lb
Output Capacity 0–5 Cubic Yards Per Hour
Discharge 3" Side Discharge
Hopper Capacity 1,200 lb Receiving Hopper with Hydraulic Agitator
Trailer Single 6,000 lb Capacity Axle with Electric Braking and Lights
Dimensions 165" x 76" x 63"
Weight 5,000 lbs
Electric Power Option for RMX-5000
The RMX-5000 can be configured with a 50 HP electric motor for applications where electrical power is preferred.
Benefits of Electric Operation
Suitable for indoor and stationary applications
Reduced fuel dependency
Efficient operation
Lower exhaust emissions compared with diesel-powered equipment
Ideal for industrial facilities and controlled work environments
Optional Equipment
The RMX-5000 can be equipped with additional accessories to improve productivity and convenience.
Available options include:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
150-gallon water tank with 2-inch flow meter
Spare tire mounted
Pendant remote control
Wireless remote control
Skid-mounted frame with forklift tubing
Benefits of Using an Electric Shotcrete Mixer Pump
The RMX-5000 provides professional contractors with a dependable electric-powered pumping solution.
Key benefits include:
Powerful 2,200 PSI pumping capability
Reliable electric operation
Consistent shotcrete and concrete mixing
High-capacity hydraulic mixing system
Improved job-site efficiency
Reduced manual material handling
Durable industrial design
Easy cleaning and maintenance
Why Choose RMX-5000 Electric Shotcrete Mixer Pump?
The RMX-5000 Electric Shotcrete Mixer Pump is engineered for contractors and industries that require reliable performance, precise material control, and efficient pumping capability. Its combination of electric power, hydraulic mixing, and high-pressure pumping technology makes it suitable for demanding shotcrete, refractory, concrete, and construction applications.
Whether used for tunnels, industrial repairs, structural projects, or specialty construction work, the RMX-5000 provides a complete mixing and pumping solution.
Electric Shotcrete Mixer Pump RMX-5000 Advanced Concrete Mixing and Pumping Equipment
