RMX-5000 Refractory Spraying Machine for Professional Material Application
A Refractory Spraying Machine is an essential piece of equipment for industries that require accurate, efficient, and durable refractory material installation. The RMX-5000 Mixer/Pump is designed to handle demanding refractory spraying applications by combining ultra high-pressure pumping technology with powerful hydraulic mixing capabilities.
Built for refractory contractors, industrial maintenance teams, and construction professionals, the RMX-5000 delivers consistent material flow, high-pressure performance, and reliable operation for furnace linings, kiln repairs, industrial insulation, and high-temperature environments.
Advanced Refractory Spraying Technology
The RMX-5000 is engineered as a complete refractory spraying machine solution capable of processing and pumping dense refractory materials over extended distances.
The machine provides:
2,200 PSI piston face pressure for refractory shotcrete applications
High-pressure material delivery
Consistent refractory mixture output
Heavy-duty hydraulic mixing performance
Reliable operation in demanding industrial conditions
Its advanced design allows operators to achieve efficient refractory placement while maintaining material consistency.
Ultra High Pressure Swing Tube Pump System
The RMX-5000 features a 3-inch x 18-inch ultra high-pressure swing tube pump designed specifically for challenging refractory applications.
Pump Specifications
Pump type: 3" x 18" Ultra High Pressure Swing Tube
Pump pressure: 2,200 PSI
Output capacity: 0–5 cubic yards per hour
Discharge: 3-inch side discharge
Designed for refractory shotcrete and dense conventional shotcrete
The swing tube pumping system provides smooth material movement and dependable performance for industrial spraying operations.
Hydraulic Mixing System for Refractory Materials
Proper mixing is critical for refractory applications. The RMX-5000 includes powerful hydraulic mixing options to ensure consistent material preparation.
Hydraulic Paddle Mixer
The 1,000 lb. capacity hydraulic paddle mixer with planetary gearbox drive is designed for:
Refractory applications
High-density shotcrete materials
Furnace and kiln repair
Industrial lining installation
The paddle mixer provides strong mixing action to maintain uniform refractory material quality.
Hydraulic Spiral Mixer
The 1,000 lb. capacity hydraulic spiral mixer is suitable for:
Conventional shotcrete
Plaster applications
Cement-based materials
General construction mixtures
This flexible mixing option allows the RMX-5000 to support different project requirements.
Refractory Spraying Machine Applications
The RMX-5000 is designed for industries where reliable refractory material placement is required.
Common applications include:
Furnace refractory repair
Kiln lining installation
Steel plant maintenance
Foundry applications
Power plant repairs
Industrial insulation projects
Mining operations
Tunnel construction
High-temperature equipment maintenance
Concrete and shotcrete restoration
The RMX-5000 provides a dependable solution for contractors working in harsh industrial environments.
RMX-5000 Refractory Spraying Machine Features
The RMX-5000 includes advanced features designed for productivity, durability, and easy maintenance.
Main Features
Ultra high-pressure 3-inch swing tube pump
2,200 PSI piston face pressure
1,000 lb. hydraulic paddle mixer with planetary gearbox drive
1,000 lb. hydraulic spiral mixer option
Hydraulic receiving hopper lift
Easy access to swing tube section for cleaning and maintenance
Fill Rite water meter
Convenient 3-inch HD side discharge
Reliable solid-state electronics
CE Certification
RMX-5000 Technical Details
Specification Details
Pump Type 3" x 18" Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Mixer Type Hydraulic Paddle Mixer / Hydraulic Spiral Mixer
Mixer Capacity 1,000 lb.
Output Capacity 0–5 Cubic Yards Per Hour
Discharge 3" Side Discharge
Hopper Capacity 1,200 lb. Receiving Hopper with Hydraulic Agitator
Trailer Single 6,000 lb. Capacity Axle with Electric Braking and Lights
Dimensions 165" x 76" x 63"
Weight 5,000 lbs
Power Options for RMX-5000
The RMX-5000 refractory spraying machine is available with flexible power configurations.
Available Power Systems
Kubota Diesel Engine Option
Kubota V3600 66 HP water-cooled diesel engine
Suitable for remote construction and industrial locations
Electric Motor Option
50 HP electric motor
Ideal for facilities with electrical power availability
These options allow contractors to select the best power source for their working environment.
Optional Accessories
The RMX-5000 can be equipped with additional accessories to improve efficiency and convenience.
Available options include:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
150-gallon water tank with 2-inch flow meter
Spare tire mounted
Pendant remote control
Wireless remote control
Skid-mounted design with forklift tubing
Benefits of Using RMX-5000 Refractory Spraying Machine
A reliable refractory spraying machine helps improve productivity and material application quality.
Key benefits include:
High-pressure refractory pumping capability
Consistent material mixing
Improved installation efficiency
Reduced manual labor
Durable industrial construction
Easy maintenance access
Suitable for demanding environments
Why Choose RMX-5000 Refractory Spraying Machine?
The RMX-5000 Mixer/Pump is designed for professionals who need dependable equipment for refractory spraying and shotcrete applications. Its combination of high-pressure pumping technology, hydraulic mixing systems, and durable construction makes it an effective solution for industrial refractory projects.
For furnace repair, kiln maintenance, industrial construction, and high-temperature applications, the RMX-5000 delivers the performance and reliability required for professional refractory installation.
Refractory Spraying Machine RMX-5000 High Performance Mixer Pump for Industrial Applications
