Planetary Gearbox Mixer with Side Discharge Mixer Pump: RMX-5000 High-Performance Pumping System

Advanced RMX-5000 Mixer / Pump for Refractory and Shotcrete Applications

The RMX-5000 Mixer / Pump is a high-performance ultra high-pressure 3-inch swing tube mixer pump engineered for demanding refractory, shotcrete, stucco, and plaster applications. Featuring a powerful planetary gearbox mixer and a convenient 3-inch side discharge mixer pump design, the RMX-5000 delivers reliable mixing and pumping performance for challenging construction environments.

Designed for contractors requiring consistent material flow and long-distance pumping capability, the RMX-5000 combines heavy-duty hydraulic mixing technology with advanced pump engineering.

Planetary Gearbox Mixer for Superior Mixing Performance

The RMX-5000 is equipped with a 1000 lb. capacity paddle mixer with planetary gearbox drive designed specifically for refractory applications. The planetary gearbox system provides efficient power transfer and dependable mixing performance, helping ensure uniform material preparation.

Key benefits of the planetary gearbox mixer include:

Powerful and consistent mixing action
Designed for refractory materials
Heavy-duty construction for demanding applications
Improved material uniformity before pumping

For conventional shotcrete and plaster applications, the RMX-5000 can also be configured with a 1000 lb. capacity hydraulic spiral mixer.

Side Discharge Mixer Pump Design

The RMX-5000 features a convenient 3-inch HD side discharge system that allows efficient material delivery and easier equipment positioning on job sites.

Advantages of the side discharge design include:

Improved hose connection accessibility
Efficient material transfer
Flexible jobsite setup
Reduced handling challenges during operation
Ultra High-Pressure Pumping Capability

The RMX-5000 uses a 3" x 18" ultra high-pressure swing tube pump designed for extreme pumping applications. With 2,200 PSI piston face pressure, this mixer pump is suitable for:

Refractory shotcrete
Dense conventional shotcrete
Industrial construction applications
Long-distance material pumping
RMX-5000 Key Features
2200 PSI piston face pressure for refractory and shotcrete applications
1000 lb. paddle mixer with planetary gearbox drive
1000 lb. spiral mixer option for conventional shotcrete and plaster
Hydraulic receiving hopper lift for easy swing tube access
Fill Rite water meter
3" HD side discharge
Reliable solid-state electronics
CE certification
RMX-5000 Specifications
Pump System
Pump Type: 3" x 18" Ultra High Pressure Swing Tube
Pump Pressure: 2,200 PSI
Mixer System
Mixer Capacity: 1,000 lb.
Hydraulic paddle mixer with planetary gearbox drive
Hydraulic spiral mixer for shotcrete and plaster applications
Production Capacity
Output: 0–5 cubic yards per hour
Discharge: 3" side discharge
Hopper and Trailer
Hopper Capacity: 1,200 lb. receiving hopper with hydraulic agitator
Trailer: Single 6,000 lb. capacity axle with electric braking and lights
Machine Dimensions
Dimensions: 165" x 76" x 63"
Weight: 5,000 lbs
Power Options

The RMX-5000 is available with:

Kubota V3600 66 HP water-cooled diesel engine
50 HP electric motor

These power configurations provide flexibility for different construction environments and operating requirements.

Optional Equipment

Available options include:

2,000 PSI hydraulic pressure washer
Vogel auto lubrication system
150-gallon water tank with 2" flow meter
Spare tire mounted
Pendant or wireless remote control
Skid-mounted configuration with forklift tubing
Applications of the RMX-5000 Planetary Gearbox Mixer Pump

The RMX-5000 is suitable for many professional applications, including:

Refractory installation
Shotcrete spraying
Stucco pumping
Plaster applications
Tunnel construction
Mining projects
Industrial repair work
Heavy-duty concrete placement
Why Choose the RMX-5000?

The RMX-5000 planetary gearbox mixer with side discharge mixer pump capability provides contractors with a durable and versatile solution for high-pressure material pumping. Its combination of powerful mixing, reliable hydraulic operation, and efficient side discharge design makes it an excellent choice for demanding construction and industrial applications.
