The RMX-5000 Mixer / Pump is a powerful tunnel construction heavy equipment solution engineered for demanding underground projects, shotcrete applications, refractory installations, and industrial concrete pumping. Designed for reliability and performance, the RMX-5000 combines an ultra high-pressure pumping system with advanced mixing technology to support efficient material placement in challenging construction environments.

High-Performance Equipment for Tunnel Construction

Tunnel construction requires equipment that can deliver consistent material flow, withstand harsh working conditions, and operate efficiently in confined environments. The RMX-5000 features a 3-inch swing tube mixer/pump system designed for pumping shotcrete, stucco, plaster, and refractory materials over extreme distances.

With 2,200 PSI piston face pressure, the RMX-5000 provides the pumping power needed for dense conventional shotcrete and refractory shotcrete applications commonly used in underground construction and tunnel reinforcement projects.

Key Features of the RMX-5000 Heavy Equipment System
Ultra High-Pressure Pump Technology

The RMX-5000 is equipped with a 3" x 18" ultra high-pressure swing tube pump that delivers reliable performance for demanding tunnel and industrial applications. Its high-pressure capability supports efficient material placement while maintaining consistent pumping output.

Heavy-Duty Mixing Capability

The RMX-5000 offers flexible mixing configurations:

1,000 lb. Hydraulic Paddle Mixer

Designed for refractory applications
Features a planetary gearbox drive system
Provides uniform and reliable material mixing

1,000 lb. Hydraulic Spiral Mixer

Designed for conventional shotcrete and plaster applications
Supports multiple construction material requirements
Hydraulic Receiving Hopper Lift

The hydraulic receiving hopper lift provides easy access to the swing tube section for cleaning and maintenance. This feature helps simplify service procedures and improves equipment availability during demanding tunnel projects.

Reliable Construction Performance

The RMX-5000 includes advanced features designed for professional heavy equipment applications:

Fill Rite water meter
Convenient 3" HD side discharge
Reliable solid-state electronics
CE certification
RMX-5000 Mixer / Pump Specifications
Specification Details
Pump Type 3" x 18" Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Mixer Options 1,000 lb. Hydraulic Paddle Mixer / 1,000 lb. Hydraulic Spiral Mixer
Output 0–5 Cubic Yards Per Hour
Discharge 3" Side Discharge
Hopper Capacity 1,200 lb. Receiving Hopper with Hydraulic Agitator
Trailer Single 6,000 lb. Capacity Axle with Electric Braking and Lights
Dimensions 165" x 76" x 63"
Weight 5,000 lbs
Power Options for Tunnel Construction Applications

The RMX-5000 is available with powerful drive options to meet different jobsite requirements:

Kubota V3600 66 HP Water-Cooled Diesel Engine
50 HP Electric Motor

The diesel configuration provides mobility for remote tunnel locations, while the electric motor option is suitable for fixed construction facilities.

Optional Equipment

The RMX-5000 can be customized with additional accessories, including:

2,000 PSI Hydraulic Pressure Washer
Vogel Automatic Lubrication System
150-gallon Water Tank with 2" Flow Meter
Spare Tire Mounted
Pendant or Wireless Remote Control
Skid Mounted with Forklift Tubing
Applications of the RMX-5000 in Tunnel Construction

This heavy-duty mixer pump is suitable for various underground and infrastructure projects, including:

Tunnel shotcrete support
Underground construction reinforcement
Mining tunnel development
Rock stabilization
Concrete repair projects
Refractory installation
Industrial construction applications
Long-distance concrete pumping
Dependable Heavy Equipment for Underground Projects

The RMX-5000 Mixer / Pump provides contractors with a reliable solution for tunnel construction and heavy-duty pumping requirements. Its combination of high-pressure performance, large-capacity mixing systems, and durable design makes it an effective choice for projects requiring consistent shotcrete placement and dependable operation in demanding environments.
