D3522 Diesel Powered Concrete Mixer Pump: Advanced Concrete Mixing and Pumping Solution

D3522 Diesel Powered Concrete Mixer Pump for Reliable Construction Performance

The D3522 Diesel powered concrete mixer pump is a high-performance construction machine designed to provide efficient mixing and pumping of concrete, mortar, grout, and other cement-based materials. Combining a powerful hydraulic squeeze pump with a durable spiral mixer, the D3522 Mixer/Pump delivers consistent material handling, reduced maintenance, and excellent productivity for demanding job sites.

Built for contractors who need dependable equipment in challenging environments, the D3522 provides the flexibility and power required for commercial construction, infrastructure projects, repair work, and industrial applications.

Powerful Diesel Engine for Heavy-Duty Applications

The D3522 is powered by a reliable 29 HP Kubota V1505 water-cooled diesel engine, providing strong and consistent performance for extended construction operations.

The diesel-powered system offers several advantages:

Reliable operation in remote job sites
Excellent fuel efficiency
Long engine service life
Consistent power delivery
Reduced downtime during demanding projects

For applications where electric operation is preferred, the D3522 is also available with a 20 HP electric motor with starter and disconnect.

Concrete Mixer Pump with Hydraulic Dump System

The D3522 features a 9 cubic foot hydraulic spiral mixer with hydraulic dump, allowing operators to efficiently mix and transfer concrete, grout, and mortar materials.

The hydraulic dump system improves workflow by allowing quick discharge of mixed material into the receiving hopper. The mixer also includes a clean-out door, making maintenance and cleaning faster and easier.

The integrated mixing system provides:

Uniform material blending
Faster material transfer
Reduced manual handling
Improved job-site productivity
Efficient Hydraulic Pumping Technology

At the core of the D3522 is a 2-inch hydraulic squeeze pump designed for smooth and reliable material delivery. The pump provides an infinitely variable output from 0 to 6 cubic yards per hour (YPH), allowing operators to adjust flow rates based on project requirements.

The squeeze pump system uses a durable rubber pumping tube as the primary wear component. This design simplifies maintenance and allows tube replacement in approximately 20 minutes.

Benefits include:

Low maintenance operation
Reduced replacement costs
Smooth pumping performance
Reliable handling of abrasive materials
Minimal equipment downtime
Receiving Hopper with Hydraulic Agitation

The D3522 includes a 12 cubic foot receiving hopper equipped with a hydraulic agitator. This feature keeps material moving continuously and helps prevent separation before pumping.

The hopper system ensures:

Consistent material flow
Improved pumping efficiency
Reduced clogging risk
Better mix quality throughout operation
Trailer Mounted Design for Job-Site Mobility

Designed for flexibility, the D3522 Mixer/Pump is mounted on a high-speed single-axle trailer with lights and an electric braking package.

The mobile design allows contractors to:

Transport equipment easily between projects
Reduce setup time
Operate in multiple locations
Improve overall job-site efficiency

A dual axle option is available for additional transportation stability.

Key Features of the D3522 Mixer/Pump

The D3522 includes advanced features for reliable construction performance:

2-inch hydraulic squeeze pump
0–6 cubic yards per hour variable output
9 cu. ft. hydraulic spiral mixer
Hydraulic dump mixer system
Clean-out door for easy maintenance
12 cu. ft. receiving hopper
Hydraulic hopper agitator
Heavy-duty planetary gearbox
Long-lasting rubber pumping tube
29 HP Kubota water-cooled diesel engine
Trailer-mounted design
Electric braking package
Technical Specifications
Specification Details
Length 204 inches
Width 88 inches
Water Tank Height 89 inches
Mixer Dump Position Height 86 inches
Charging Height 48 inches
Output Capacity 0–6 YPH
Mixer Capacity 9 cu. ft.
Receiving Hopper Capacity 12 cu. ft.
Optional Equipment

The D3522 can be customized with additional accessories to meet different project requirements:

Pendant remote control
Wireless remote control
150-gallon water tank with 2-inch flow meter
Spare tire mounted package
Hydraulic pressure washer
Dual axle trailer
Mounted air compressor

These options increase machine versatility and allow contractors to configure the equipment for specific construction applications.

Applications of the D3522 Diesel Powered Concrete Mixer Pump

The D3522 is suitable for a wide variety of construction and industrial uses, including:

Concrete pumping
Mortar applications
Grout injection
Foundation repair
Structural reinforcement
Masonry construction
Bridge rehabilitation
Tunnel construction
Industrial flooring
Infrastructure projects
Commercial building construction
Civil engineering applications

Its combination of mixing and pumping capabilities makes it an efficient solution for projects requiring reliable material placement.

Why Choose the D3522 Mixer/Pump?

The D3522 combines powerful diesel performance, efficient hydraulic pumping, and integrated mixing technology into one compact machine. Contractors benefit from reduced equipment needs, faster operation, and lower maintenance costs.

Key advantages include:

Diesel-powered reliability
Hydraulic dump mixer system
Efficient squeeze pump operation
Portable trailer-mounted design
Easy maintenance
Durable construction
Consistent concrete and grout delivery
