For construction projects that require controlled material placement, equipment size and performance can both play an important role. The Blastcrete Model H 020 is a compact gunite machine for construction applications, offering hydraulic rotary operation, variable-speed production, and precise material output control.
Designed as a versatile Gunite Machine Attachment, the H 020 provides variable output from 0 to 5 cubic yards per hour. Its hydraulic requirement is 10 GPM at 1,500 PSI, making it compatible with any hydraulic power unit capable of supplying the required capacity.
Because the H 020 is hydraulically powered, its minimum air requirement is only 225 CFM, providing a practical equipment configuration for suitable construction applications.
Compact Design for Construction Applications
The H 020 combines a compact skid-mounted design with adjustable material production. Measuring 34" × 34" × 50" and weighing approximately 1,250 pounds, the machine is designed to provide practical handling and positioning on construction jobsites.
Forklift pickup tubing helps facilitate transportation, while the universal mounting plate provides flexibility when installing or positioning the equipment.
Variable-Speed Gunite Production
The H 020 operates at variable speeds, providing output from 0 to 5 cubic yards per hour. This allows operators to adjust material delivery according to project requirements rather than relying on a single fixed production rate.
Precise material output control is one of the machine's key features, making it suitable for applications where controlled and consistent material placement is important.
Proven Piccola Clamping System
The H 020 is equipped with the proven Genuine Piccola single-point clamping system. This straightforward design provides reliable rotor clamping and supports consistent operation.
The machine also offers the option of selecting the rotor configuration according to application requirements, providing additional flexibility for contractors using the Gunite Machine Attachment.
Key Features
The Blastcrete H 020 includes:
Genuine Piccola Single-Point Clamping System
Precise Material Output Control
Universal Mounting Plate
Forklift Pickup Tubing
Rotor of Your Choice
Variable output from 0–5 cubic yards per hour
Hydraulic requirement of 10 GPM @ 1,500 PSI
Minimum air requirement of 225 CFM
H 020 Specifications
Specification Details
Air Requirement 225 CFM minimum
Output 0–5 cubic yards per hour
Hydraulic Requirement 10 GPM @ 1,500 PSI
Outlet 1.5"
Maximum Aggregate ¾"
Mounting Skid Mount
Estimated Wear Pad Life 200 tons
Dimensions 34" × 34" × 50"
Weight 1,250 lbs.
Hydraulic Operation with Reduced Air Requirements
The H 020 requires 10 GPM at 1,500 PSI hydraulic power and is universal with compatible hydraulic power units that meet these specifications. This allows contractors to integrate the machine into an existing hydraulic equipment setup when capacity requirements are satisfied.
Since the H 020 operates hydraulically, it requires only 225 CFM minimum air capacity. Contractors should ensure the complete equipment system meets the required hydraulic and air specifications before operation.
Material and Output Specifications
The H 020 features a 1.5-inch outlet and can accommodate aggregate up to ¾ inch. Its output range of zero to five cubic yards per hour provides operators with flexibility when managing production for different construction applications.
The estimated wear pad life is approximately 200 tons, providing a useful reference for maintenance planning. Actual component life may vary depending on materials, operating conditions, and usage.
Practical Jobsite Handling
A compact equipment footprint can be beneficial on construction sites where space and equipment movement are important considerations. The H 020's skid-mounted configuration, forklift pickup tubing, and universal mounting plate are designed to make handling and setup more convenient.
At 34" × 34" × 50", the machine provides a compact package while maintaining the output control and hydraulic capabilities needed for suitable gunite applications.
Choosing a Gunite Machine Attachment
When selecting a Gunite Machine Attachment, contractors should consider production requirements, aggregate size, outlet dimensions, hydraulic power availability, air capacity, and jobsite conditions.
The H 020 provides a combination of compact construction, variable-speed operation, precise material control, and proven clamping technology, making it a practical option for suitable construction projects.
Quote Now or Download the Brochure
Looking for a compact gunite machine for construction with variable-speed hydraulic operation? The Blastcrete H 020 offers precise material output control and practical jobsite features in a compact skid-mounted design.
