Skid Mounted Hydraulic Gunite Machine: Blastcrete H 020 for Precise Material Control

The Blastcrete Model H 020 is a skid mounted hydraulic gunite machine designed for contractors who need reliable material delivery, variable-speed production, and precise output control. As a versatile Gunite Machine Attachment, the H 020 provides adjustable output from 0 to 5 cubic yards per hour for suitable gunite applications.

The H 020 requires 10 GPM at 1,500 PSI and is compatible with any hydraulic power unit capable of providing this capacity. Since the machine is hydraulically powered, its minimum air requirement is only 225 CFM.

Skid-Mounted Design for Practical Jobsite Use

The H 020 features a skid-mounted configuration that provides a compact and practical equipment package. Its dimensions are 34" × 34" × 50", and it weighs approximately 1,250 pounds.

The machine includes forklift pickup tubing, making it easier to transport and position on the jobsite. A universal mounting plate also provides flexibility when installing or integrating the machine into a suitable equipment setup.

Hydraulic Rotary Operation

The H 020 uses hydraulic power for variable-speed rotary operation. Its required hydraulic capacity is 10 GPM at 1,500 PSI, and the requirement is universal with any hydraulic power unit capable of supplying these specifications.

The hydraulic design also reduces the compressed-air requirement to 225 CFM minimum, which can help simplify supporting equipment requirements.

Variable-Speed Material Output

One of the key benefits of the H 020 is its adjustable production rate. The machine can provide output from 0 to 5 cubic yards per hour, allowing operators to regulate material delivery according to project requirements.

The H 020 features a 1.5-inch outlet and accommodates aggregate up to ¾ inch. Its estimated wear pad life is approximately 200 tons, providing a useful reference for maintenance planning.

Proven Piccola Single-Point Clamping System

The H 020 is equipped with the proven Genuine Piccola single-point clamping system. This straightforward system provides reliable rotor clamping while supporting consistent operation and precise material output control.

Contractors can also choose the rotor configuration that best matches their application, providing additional flexibility when configuring the Gunite Machine Attachment.

Key Features

The Blastcrete H 020 includes:

Genuine Piccola Single-Point Clamping System
Precise Material Output Control
Universal Mounting Plate
Forklift Pickup Tubing
Rotor of Your Choice
Variable output from 0–5 cubic yards per hour
Hydraulic requirement of 10 GPM @ 1,500 PSI
Minimum air requirement of 225 CFM
H 020 Specifications
Specification Details
Air Requirement 225 CFM minimum
Output 0–5 cubic yards per hour
Hydraulic Requirement 10 GPM @ 1,500 PSI
Outlet 1.5"
Maximum Aggregate ¾"
Mounting Skid Mount
Estimated Wear Pad Life 200 tons
Dimensions 34" × 34" × 50"
Weight 1,250 lbs.
Efficient Material Delivery

The H 020 is designed to give operators precise control over material output. Its variable-speed operation allows production to be adjusted between zero and five cubic yards per hour, helping contractors adapt material delivery to the application.

The 1.5-inch outlet and maximum aggregate size of ¾ inch provide defined material-handling parameters for project planning. Contractors should verify material compatibility and application requirements before operation.

Compact Hydraulic Gunite Equipment

For contractors looking for a compact hydraulic solution, the H 020 combines a skid-mounted design with practical handling features and adjustable production. The universal mounting plate and forklift pickup tubing help simplify installation and movement.

Its hydraulic power requirements also allow the machine to be paired with a compatible hydraulic power unit, while the 225 CFM minimum air requirement provides a relatively low compressed-air demand.

Why Choose the H 020 Gunite Machine Attachment?

The Blastcrete H 020 brings together hydraulic rotary technology, variable-speed operation, precise material output control, and proven Piccola clamping technology.

For suitable applications requiring a skid mounted hydraulic gunite machine, the H 020 offers a compact configuration with practical jobsite handling features and adjustable material production.

Quote Now or Download the Brochure

Looking for a skid mounted hydraulic gunite machine with variable-speed operation and precise material control? The Blastcrete H 020 is designed to provide a practical solution for professional gunite applications.
