The Blastcrete H 020 is a hydraulic rotary Gunite Machine Attachment designed for variable-speed material delivery and precise output control. Equipped with the proven Genuine Piccola single point clamping system, the H 020 provides a straightforward configuration for suitable professional gunite applications.
The machine offers variable output from 0 to 5 cubic yards per hour and requires 10 GPM at 1,500 PSI hydraulic power. Because it is hydraulically powered, the H 020 has a minimum air requirement of only 225 CFM.
Rotary Gunite Machine with Single Point Clamping
The H 020 combines hydraulic rotary operation with the Genuine Piccola single point clamping system. This design provides a practical method for securing the rotor while supporting precise material output control.
The machine also offers a rotor of your choice, giving contractors flexibility when configuring the Gunite Machine Attachment for a particular application.
Variable-Speed Material Output
The H 020 provides adjustable production from 0 to 5 cubic yards per hour. Variable-speed operation allows operators to control material delivery according to project requirements.
Its precise material output control can be useful for applications where consistent and adjustable material placement is important.
Key Features
The Blastcrete H 020 includes:
Genuine Piccola Single Point Clamping System
Precise Material Output Control
Universal Mounting Plate
Forklift Pickup Tubing
Rotor of Your Choice
Variable output from 0–5 cubic yards per hour
Hydraulic requirement of 10 GPM @ 1,500 PSI
Minimum air requirement of 225 CFM
H 020 Specifications
Specification Details
Air Requirement 225 CFM minimum
Output 0–5 cubic yards per hour
Hydraulic Requirement 10 GPM @ 1,500 PSI
Outlet 1.5"
Maximum Aggregate ¾"
Mounting Skid Mount
Estimated Wear Pad Life 200 tons
Dimensions 34" × 34" × 50"
Weight 1,250 lbs.
10 GPM at 1,500 PSI Hydraulic Requirement
The H 020 requires 10 GPM at 1,500 PSI hydraulic power and is universal with any hydraulic power unit capable of supplying this capacity.
This makes hydraulic compatibility an important consideration when planning the equipment setup. Contractors should verify that their hydraulic power unit meets the specified flow and pressure requirements before operation.
225 CFM Minimum Air Requirement
Since the H 020 is a hydraulic machine, its minimum air requirement is 225 CFM. This provides a defined air-capacity requirement when selecting supporting compressed-air equipment.
The complete equipment system should be checked to ensure both hydraulic and air requirements are satisfied.
1.5-Inch Outlet and ¾-Inch Aggregate
The H 020 features a 1.5-inch outlet and accommodates aggregate up to ¾ inch. These specifications provide important parameters when selecting compatible materials and planning suitable applications.
The estimated wear pad life is approximately 200 tons, providing a general reference for maintenance planning. Actual wear life may vary depending on material, operating conditions, production, and maintenance practices.
Compact Skid-Mounted Configuration
The H 020 is skid mounted and measures 34" × 34" × 50", with an approximate weight of 1,250 pounds.
Its universal mounting plate provides installation flexibility, while forklift pickup tubing assists with transportation and positioning on suitable jobsites.
Why Choose the H 020 Gunite Machine Attachment?
The Blastcrete H 020 combines hydraulic rotary operation, variable-speed production, and the proven Genuine Piccola single point clamping system in a compact skid-mounted design.
Key specifications include:
0–5 cubic yards per hour output
10 GPM @ 1,500 PSI hydraulic requirement
225 CFM minimum air requirement
1.5-inch outlet
¾-inch maximum aggregate
Precise material output control
Universal mounting plate
Forklift pickup tubing
Rotor selection options
For contractors looking for a rotary gunite machine with single point clamping system, the H 020 provides a practical hydraulic solution for suitable professional applications.
Quote Now or Download the Brochure
Looking for a rotary gunite machine with single point clamping system and variable-speed material output? The Blastcrete H 020 offers hydraulic operation, precise output control, and practical jobsite features.
