The Blastcrete Model H 020 is a simple hydraulic rotary Gunite Machine Attachment designed for controlled material delivery in suitable professional applications. With variable-speed output from 0 to 5 cubic yards per hour, the H 020 provides precise material output control for contractors evaluating Gunite Equipment for Concrete Repair projects.
Its hydraulic requirement is 10 GPM at 1,500 PSI, and it is universal with any hydraulic power unit capable of supplying this capacity. Because the machine is hydraulically powered, its minimum air requirement is only 225 CFM.
Skid Mounted Gunite Machine for Concrete Repair
Concrete repair applications can require equipment that provides adjustable and controlled material delivery. The H 020 combines hydraulic rotary operation with variable-speed production, allowing operators to adjust output according to project requirements.
The skid mounted gunite machine configuration also provides a compact equipment format for suitable construction and repair environments.
The appropriate gunite material, application method, and equipment setup should always be determined according to project specifications and the requirements of the repair system.
Variable-Speed Material Output
The H 020 operates at a variable output of 0–5 cubic yards per hour. This allows operators to control material delivery rather than operating at a single fixed production rate.
The machine's precise material output control provides additional flexibility for suitable concrete repair and gunite applications.
Genuine Piccola Single-Point Clamping System
The H 020 is equipped with the proven Genuine Piccola single-point clamping system. The system supports rotor clamping and the machine's controlled operation.
A rotor of your choice is also available, giving contractors flexibility when configuring the Gunite Machine Attachment.
Key Features
The Blastcrete H 020 includes:
Genuine Piccola Single-Point Clamping System
Precise Material Output Control
Universal Mounting Plate
Forklift Pickup Tubing
Rotor of Your Choice
Variable output from 0–5 cubic yards per hour
Hydraulic requirement of 10 GPM @ 1,500 PSI
Minimum air requirement of 225 CFM
Blastcrete H 020 Specifications
Specification Details
Air Requirement 225 CFM minimum
Output 0–5 cubic yards per hour
Hydraulic Requirement 10 GPM @ 1,500 PSI
Outlet 1.5"
Maximum Aggregate ¾"
Mounting Skid Mount
Estimated Wear Pad Life 200 tons
Dimensions 34" × 34" × 50"
Weight 1,250 lbs.
Hydraulic Power Requirements
The H 020 requires 10 GPM at 1,500 PSI hydraulic power. It is universal with any hydraulic power unit capable of meeting these requirements.
Contractors should verify the available hydraulic power unit's flow and pressure before operating the machine and ensure the complete equipment configuration is appropriate for the intended application.
225 CFM Air Requirement
The hydraulic design of the H 020 results in a minimum air requirement of 225 CFM.
This specification provides contractors with a clear reference when selecting supporting compressed-air equipment. Both the hydraulic and air systems should meet the specified requirements before operation.
1.5-Inch Outlet and ¾-Inch Aggregate
The H 020 features a 1.5-inch outlet and accommodates aggregate up to ¾ inch. These specifications should be considered when evaluating material compatibility for concrete repair applications.
The estimated wear pad life is approximately 200 tons. Actual wear life can vary depending on material properties, operating conditions, production levels, and maintenance practices.
Compact Skid-Mounted Design
The H 020 is skid mounted and measures 34" × 34" × 50", with an approximate weight of 1,250 pounds.
The universal mounting plate provides installation flexibility, while forklift pickup tubing can assist with transportation and positioning on suitable jobsites.
Why Choose the H 020 for Concrete Repair?
When selecting Gunite Equipment for Concrete Repair, contractors can evaluate output control, hydraulic requirements, air capacity, aggregate limitations, and equipment handling characteristics.
The H 020 provides:
0–5 cubic yards per hour variable output
Precise material output control
10 GPM @ 1,500 PSI hydraulic requirement
225 CFM minimum air requirement
1.5-inch outlet
¾-inch maximum aggregate
Genuine Piccola single-point clamping system
Universal mounting plate
Forklift pickup tubing
Rotor selection options
Skid-mounted construction
These characteristics make the H 020 a practical Gunite Machine Attachment for suitable professional concrete repair and material-placement applications.
