Pneumatic Gunning Machine AA 020 Genuine Piccola

Pneumatic Gunning Machine – AA 020 Genuine Piccola

A reliable Pneumatic Gunning Machine is an important solution for industrial gunning applications where controlled material delivery and dependable performance are required. The AA 020 Genuine Piccola Gunning Machine offers a practical and economical solution with an output capacity of 0–6 tons per hour.

The Genuine Piccola can be powered by a 16 AM Gast air motor, making it suitable for applications where compressed air is available. Its heavy-duty gearbox rotates the rotor section, while the machine provides precise material output control for compatible gunning applications.

AA 020 Genuine Piccola Pneumatic Gunning Machine

The Blastcrete Genuine Piccola is designed as a simple solution for industrial gunning applications. The 16 AM air motor drives the heavy-duty gearbox, which rotates the rotor section to support controlled material delivery.

The machine can also be configured with a 5 HP electric motor or 13 HP Honda gasoline engine, providing flexibility when different power sources are required.

For users looking for a Pneumatic Gunning Machine, the air-powered configuration provides an option for work environments where compressed air is readily available.

Key Features

The AA 020 Genuine Piccola provides several features designed for efficient gunning applications:

16 AM Gast air motor option

Simple Piccola single-point clamping system

Precise material output control

Heavy-duty gearbox and rotor system

Recommended by major refractory material manufacturers

Forklift pickup capability

Output range of 0–6 tons per hour

Solid rubber tire mounting

Power Options

The Genuine Piccola offers three power configurations.

16 AM Gast Air Motor

The 16 AM Gast air motor is the pneumatic power option for the machine. It provides an air-powered configuration for applications where a suitable compressed-air supply is available.

5 HP Electric Motor

The 5 HP electric motor is available in 240 V or 480 V, 3-phase configurations and provides an alternative for facilities with suitable electrical power.

13 HP Honda Gasoline Engine

The 13 HP Honda gasoline engine provides an independent power option for applications where electricity or compressed air may not be readily available.

Available Rotor Options

The pneumatic configuration can be supplied with different rotor options:

12-hole round half rotor

12-hole round full rotor

9-hole round full rotor

12-hole sector full rotor

The appropriate rotor should be selected based on the material and application requirements.

Other Available Options

The AA 020 Genuine Piccola can also be configured with:

Skid mounted with forklift pickup

Hydrostatic predampener

Water booster pump

These options provide additional flexibility for suitable industrial gunning applications.

Pneumatic Gunning Machine Specifications
Specification Details
Air Requirement 250–600 CFM, depending on power option
Output 0–6 tons per hour
Outlet 1.5-inch connection cup
Maximum Aggregate 3/4 inch
Mounting Solid rubber tires
Estimated Wear Pad Life 200 tons
Dimensions 50 × 34 × 52 inches
Weight 1,250 lbs
Applications of a Pneumatic Gunning Machine

A Pneumatic Gunning Machine can be used for suitable industrial gunning applications where compressed air is available as a power source.

The AA 020 Genuine Piccola is designed to provide precise material output control while the air motor drives the heavy-duty gearbox and rotor section. This configuration can provide flexibility for appropriate refractory and material gunning operations.

Its solid rubber tires make the equipment practical to move around industrial work areas, while the optional forklift pickup configuration can assist with handling and positioning.

Benefits of the AA 020 Genuine Piccola

The AA 020 Genuine Piccola is designed around a simple and economical operating concept. Its single-point clamping system helps keep the equipment straightforward, while the heavy-duty gearbox supports reliable rotor operation.

The pneumatic power configuration is particularly useful for sites that already have a suitable compressed-air supply. Users can alternatively choose an electric motor or gasoline engine configuration when those power sources better match their operating environment.

With an output capacity of 0–6 tons per hour, the Genuine Piccola provides flexibility for different compatible gunning requirements.

Choosing the Right Pneumatic Gunning Machine

When selecting a Pneumatic Gunning Machine, important considerations include air availability, air requirements, output capacity, maximum aggregate size, rotor configuration, outlet size, and application conditions.

The Genuine Piccola requires approximately 250–600 CFM, depending on the power configuration, and has an output range of 0–6 tons per hour. It can handle a maximum aggregate size of 3/4 inch and features a 1.5-inch connection cup outlet.

Optional equipment such as a hydrostatic predampener and water booster pump can provide additional configuration possibilities.

Get a Quote for AA 020 Genuine Piccola

If you need a dependable Pneumatic Gunning Machine, the AA 020 Genuine Piccola provides an air-powered option combined with precise material output control, flexible rotor configurations, and an economical design.

Quote Now to request pricing and configuration information, or Download Brochure to review the complete specifications and available options.

Frequently Asked Questions

What makes the Genuine Piccola a pneumatic gunning machine?
The machine can be equipped with a 16 AM Gast air motor, which drives the heavy-duty gearbox and rotor section.

What is the output capacity?
The AA 020 Genuine Piccola provides an output range of 0–6 tons per hour.

What air supply is required?
The specified air requirement is approximately 250–600 CFM, depending on the power configuration.

What is the maximum aggregate size?
The maximum aggregate size is 3/4 inch.

What power options are available?
Options include a 16 AM Gast air motor, 5 HP electric motor, and 13 HP Honda gasoline engine.

What rotor configurations are available?
Available rotor options include 12-hole round half, 12-hole round full, 9-hole round full, and 12-hole sector full rotors.

What accessories are available?
Options include skid mounting with forklift pickup, a hydrostatic predampener, and a water booster pump.
