X-10 Piston Pump – Kiln Maintenance Concrete Pump
The X-10 Piston Pump is an ultra high pressure kiln maintenance concrete pump designed for demanding refractory, cast, and shotcrete applications. With 2,200 PSI piston face pressure and an output of up to 12 cubic yards per hour, the X-10 provides the pumping power and production capacity required for professional kiln maintenance and refractory repair projects.
Designed for reliable operation and straightforward maintenance, the X-10 features a durable swing tube piston pump, swing-out receiving hopper, hydraulic hopper agitator, and reliable solid-state electronics.
Quote Now | Download Brochure
What Is a Kiln Maintenance Concrete Pump?
A kiln maintenance concrete pump is specialized pumping equipment used to transport and place refractory and cementitious materials during kiln maintenance, repair, and lining applications.
Kilns operate under high temperatures and demanding conditions. Maintaining the refractory lining is therefore an important part of protecting kiln structures and supporting reliable operation.
The X-10 is designed to provide high-pressure material pumping for refractory repair and related applications. Its 2,200 PSI piston face pressure helps provide the force required to move material through challenging pumping configurations.
X-10 Piston Pump for Kiln Maintenance
Kiln maintenance projects can require durable pumping equipment that provides consistent material delivery while remaining easy to clean and service.
The X-10 combines high-pressure pumping capability with a maintenance-friendly design. The swing-out receiving hopper provides quick access to the swing tube section, while the hydraulic agitator helps maintain material movement inside the hopper.
The X-10 is suitable for applications including:
Kiln refractory maintenance
Kiln lining repair
Refractory cast applications
Industrial refractory repair
Shotcrete applications
High-pressure refractory material placement
Key Features of the X-10 Kiln Maintenance Concrete Pump
2,200 PSI Piston Face Pressure
The X-10 provides 2,200 PSI piston face pressure for rugged refractory pump, cast, and shotcrete applications.
This high-pressure capability is designed to help contractors transport refractory material through demanding pumping systems.
Output Up to 12 Cubic Yards Per Hour
The X-10 offers an output range of 0–12 cubic yards per hour, providing flexible material delivery for different kiln maintenance and refractory projects.
Ultra High Pressure Swing Tube
The pump uses a 3-inch x 24-inch ultra high pressure swing tube designed for demanding material pumping applications.
Swing-Out Receiving Hopper
The simple swing-out receiving hopper provides fast access to the swing tube section for cleaning and maintenance.
This user-friendly design can help simplify routine servicing and minimize unnecessary equipment downtime.
Hydraulic Hopper Agitator
The receiving hopper includes a rugged hydraulic agitator designed to support consistent material movement and reliable pumping.
Forklift Tubing
Forklift tubing is mounted to the lower hopper for easier flat pack removal and handling.
Reliable Solid-State Electronics
The X-10 includes reliable solid-state valve control electronics designed for dependable operation.
CE Certification
The X-10 is available with CE certification for applicable markets and equipment requirements.
X-10 Power Options
The kiln maintenance concrete pump is available with diesel and electric power configurations.
Kubota V3600 Diesel
66 HP
Water-cooled diesel engine
Suitable for applications requiring independent diesel power
Electric Motor
40 HP electric motor
Suitable for jobsites with an appropriate electrical supply
Optional Equipment
The X-10 can be equipped with several options to improve maintenance and jobsite flexibility.
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Mounted spare tire
Pendant or wireless remote control
Skid-mounted configuration with forklift tubing
X-10 Kiln Maintenance Concrete Pump Specifications
Specification X-10
Pump Type 3-inch x 24-inch Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Output 0–12 Cubic Yards Per Hour
Discharge 3 inches
Hopper Capacity 2,500 lbs.
Hopper Type Swing-Out Receiving Hopper
Hopper Agitator Hydraulic
Operating Platform 22 sq. ft.
Electrical Control Solid-State Valve Control
Trailer Single 6,000 lb. Capacity Axle
Braking Electric Braking
Lights Included
Dimensions 156 x 76 x 80 inches
Weight 4,500 lbs.
Kiln Maintenance and Refractory Applications
The X-10 is designed for applications where high-pressure pumping is required for refractory and cementitious materials.
Kiln Lining Repair
Kiln refractory linings help protect equipment from high temperatures and operating conditions. The X-10 provides the pumping capability required for refractory lining repair and maintenance applications.
Refractory Cast Applications
The X-10 can be used for refractory cast work requiring controlled material delivery and dependable high-pressure pumping.
Industrial Maintenance
Industrial maintenance projects may require pumping equipment that can operate reliably while allowing convenient cleaning and servicing. The X-10's swing-out hopper provides quick access to the swing tube section.
Shotcrete Applications
In addition to kiln maintenance, the X-10 is designed for shotcrete applications requiring high-pressure material pumping.
Benefits of Using the X-10 for Kiln Maintenance
Selecting suitable kiln maintenance concrete pump equipment can help improve material placement efficiency and simplify equipment maintenance.
The X-10 provides:
2,200 PSI piston face pressure
Output up to 12 cubic yards per hour
3-inch discharge
Ultra high pressure swing tube
2,500 lb. hopper capacity
Hydraulic hopper agitation
Swing-out hopper access
Easy flat pack removal
Solid-state controls
Diesel and electric power options
Optional pendant or wireless remote
Trailer or skid-mounted configurations
Designed for Easy Cleaning and Maintenance
Maintenance accessibility is an important consideration for equipment used in refractory and kiln repair projects.
The X-10's swing-out receiving hopper allows operators to access the swing tube section quickly for cleaning and maintenance. Forklift tubing on the lower hopper also helps simplify flat pack removal.
Optional equipment such as the 2,000 PSI hydraulic pressure washer and Vogel automatic lubrication system can provide additional support for equipment maintenance.
Fast Return on Investment
The X-10 is designed to provide a fast return on investment through a combination of high-pressure performance, production capacity, and user-friendly maintenance features.
With an output of up to 12 cubic yards per hour and 2,200 PSI piston face pressure, the machine is engineered for demanding refractory and kiln maintenance applications.
Its practical design can help contractors spend less time on routine equipment servicing and more time focused on project work.
Heavy-Duty Piston Pump for Kiln Projects
The X-10 Piston Pump provides a combination of ultra high pressure performance and practical operation for demanding kiln maintenance applications.
Its 2,200 PSI piston face pressure, 3-inch discharge, and maximum output of 12 cubic yards per hour make it suitable for professional refractory repair and material placement projects.
With diesel and electric power options, optional remote controls, and skid-mounted configurations, the X-10 can be adapted to different project environments.
Frequently Asked Questions
What is a kiln maintenance concrete pump?
A kiln maintenance concrete pump is specialized pumping equipment used to transport and place refractory or cementitious materials during kiln maintenance, lining repair, and related industrial applications.
What is the X-10 Piston Pump designed for?
The X-10 is designed for refractory, cast, and shotcrete applications, including demanding kiln maintenance and repair work.
How much pressure does the X-10 provide?
The X-10 provides 2,200 PSI piston face pressure.
What is the maximum output?
The X-10 has an output range of 0–12 cubic yards per hour.
What is the hopper capacity?
The machine features a 2,500 lb. capacity swing-out receiving hopper with a hydraulic agitator.
What power options are available?
The X-10 is available with a 66 HP Kubota V3600 water-cooled diesel engine or a 40 HP electric motor.
Does the X-10 have remote control options?
Yes. Pendant or wireless remote control is available as an option.
Can the X-10 be skid mounted?
Yes. A skid-mounted configuration with forklift tubing is available.
Get the X-10 Kiln Maintenance Concrete Pump
If you need reliable kiln maintenance concrete pump equipment for refractory lining repair, cast applications, or shotcrete work, the X-10 Piston Pump provides ultra high pressure performance and a practical maintenance-friendly design.
With 2,200 PSI piston face pressure and output of up to 12 cubic yards per hour, the X-10 is engineered to handle demanding professional refractory applications.
