X-10 Piston Pump – Heavy Duty Hydraulic Concrete Pump
The X-10 Piston Pump is a rugged heavy duty hydraulic concrete pump designed for demanding refractory, cast, and shotcrete applications. With 2,200 PSI piston face pressure and output of up to 12 cubic yards per hour, the X-10 delivers high-pressure pumping performance for challenging construction and industrial projects.
Designed for professional use, the X-10 combines an ultra high pressure swing tube piston pump with a practical maintenance-friendly design. The swing-out receiving hopper provides fast access to the swing tube section, while the hydraulic hopper agitator supports consistent material movement during operation.
Quote Now | Download Brochure
What Is a Heavy Duty Hydraulic Concrete Pump?
A heavy duty hydraulic concrete pump is designed to transport concrete, refractory mixes, shotcrete, and other cementitious materials under demanding operating conditions.
Hydraulic pumping systems provide the power needed for high-pressure material delivery, making them suitable for industrial construction, refractory repair, shotcrete placement, and other applications where conventional pumping equipment may not provide sufficient performance.
The X-10 combines hydraulic operation with a 2,200 PSI piston face pressure, 3-inch discharge, and output of up to 12 cubic yards per hour.
X-10 Piston Pump for Heavy-Duty Applications
The X-10 is designed for projects where durability, high pressure, and dependable material delivery are important.
Typical applications include:
Heavy-duty concrete pumping
Refractory pumping
Shotcrete applications
Refractory cast work
Industrial repair
Furnace repair
Kiln maintenance
Steel plant refractory applications
High-pressure material placement
Its rugged design and high-pressure piston system make the X-10 suitable for demanding professional applications.
Key Features of the X-10 Heavy Duty Hydraulic Concrete Pump
2,200 PSI Piston Face Pressure
The X-10 provides 2,200 PSI piston face pressure for rugged refractory pump, cast, and shotcrete applications.
The high-pressure piston system is designed to help move material through challenging pumping configurations and over demanding distances.
Output Up to 12 Cubic Yards Per Hour
The X-10 provides an output range of 0–12 cubic yards per hour, allowing operators to adjust production according to project requirements.
Ultra High Pressure Swing Tube
The pump features a 3-inch x 24-inch ultra high pressure swing tube designed for demanding pumping applications.
Hydraulic Hopper Agitator
The 2,500 lb. receiving hopper features a rugged hydraulic agitator designed to support consistent material movement during operation.
Swing-Out Receiving Hopper
The simple swing-out hopper provides quick access to the swing tube section for cleaning, inspection, and maintenance.
This practical design can help simplify routine servicing and reduce unnecessary downtime.
Forklift Tubing
Forklift tubing is mounted to the lower hopper to make flat pack removal and handling easier.
Solid-State Electronics
The X-10 includes reliable solid-state valve control electronics designed for dependable operation.
CE Certification
The X-10 includes CE certification for applicable equipment and market requirements.
Hydraulic Power and Engine Options
The X-10 heavy duty hydraulic concrete pump is available with different power configurations to suit various operating environments.
Kubota V3600 Diesel Engine
66 HP
Water-cooled diesel
Suitable for applications requiring independent power
Designed for demanding jobsite conditions
40 HP Electric Motor
40 HP electric motor
Suitable for facilities and jobsites with an appropriate electrical supply
Available X-10 Options
The X-10 can be equipped with additional options for maintenance, mobility, and operator convenience.
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Mounted spare tire
Pendant or wireless remote
Skid-mounted configuration with forklift tubing
X-10 Heavy Duty Hydraulic Concrete Pump Specifications
Specification X-10
Pump Type 3-inch x 24-inch Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Output 0–12 Cubic Yards Per Hour
Discharge 3 inches
Hopper Capacity 2,500 lbs.
Hopper Type Swing-Out Receiving Hopper
Hopper Agitator Hydraulic
Operating Platform 22 sq. ft.
Electrical Control Solid-State Valve Control
Trailer Single 6,000 lb. Capacity Axle
Braking Electric Braking
Lights Included
Dimensions 156 x 76 x 80 inches
Weight 4,500 lbs.
Applications for a Heavy Duty Hydraulic Concrete Pump
The X-10 is designed for applications where high-pressure pumping and rugged equipment performance are required.
Refractory Pumping
Industrial refractory applications require equipment capable of handling demanding materials. The X-10 provides high piston pressure for refractory pumping and placement.
Shotcrete Applications
Shotcrete projects require consistent material delivery and reliable pumping pressure. The X-10 is designed for demanding shotcrete applications.
Furnace Repair
Furnace repair projects can require refractory materials to be transported and placed in difficult areas. The X-10 provides high-pressure pumping capability for these applications.
Kiln Maintenance
The X-10 can support kiln maintenance and refractory repair projects where dependable material delivery is essential.
Steel Plant Applications
Steel plants use refractory materials to protect equipment exposed to extreme temperatures. The X-10 provides a rugged pumping solution for refractory cast and repair work.
Industrial Construction
Industrial construction projects may require concrete and cementitious materials to be pumped under demanding conditions. The X-10 is designed for professional high-pressure applications.
Benefits of the X-10 Heavy Duty Hydraulic Concrete Pump
Choosing the right heavy duty hydraulic concrete pump can improve material delivery and provide the durability needed for demanding applications.
The X-10 offers:
2,200 PSI piston face pressure
Output up to 12 cubic yards per hour
3-inch discharge
Ultra high pressure swing tube
2,500 lb. hopper capacity
Hydraulic hopper agitator
Swing-out hopper for easy access
Forklift tubing for flat pack removal
Solid-state electronic controls
Diesel and electric power options
Optional automatic lubrication
Optional hydraulic pressure washer
Pendant or wireless remote options
Trailer or skid-mounted configurations
CE certification
Built for Easy Maintenance
Heavy-duty equipment needs to be powerful while remaining practical to service.
The X-10 features a swing-out receiving hopper that provides quick access to the swing tube section for cleaning and maintenance.
Forklift tubing on the lower hopper also makes flat pack removal easier.
For additional maintenance support, operators can select the 2,000 PSI hydraulic pressure washer and Vogel automatic lubrication system as optional equipment.
High-Pressure Hydraulic Pumping Performance
The X-10 combines 2,200 PSI piston face pressure with output of up to 12 cubic yards per hour.
This high-pressure capability is designed for refractory, cast, shotcrete, and industrial repair applications where dependable material delivery is important.
The combination of a rugged swing tube, hydraulic hopper agitator, and heavy-duty components makes the X-10 a practical choice for demanding professional applications.
Fast Return on Investment
The X-10 is designed to support a fast return on investment by combining high-pressure pumping capability with practical operation and maintenance features.
Its output of up to 12 cubic yards per hour can support productive material placement, while the accessible swing-out hopper simplifies routine maintenance.
Why Choose the X-10 Piston Pump?
The X-10 Piston Pump is engineered for demanding applications where high pressure, durability, and ease of maintenance matter.
Its key capabilities include:
2,200 PSI piston face pressure
Up to 12 cubic yards per hour
3-inch discharge
Ultra high pressure swing tube
Hydraulic hopper agitator
Swing-out receiving hopper
2,500 lb. hopper capacity
Diesel or electric power
Optional remote controls
Optional automatic lubrication
CE certification
For contractors and industrial operators looking for a heavy duty hydraulic concrete pump, the X-10 provides a high-pressure pumping solution for refractory, shotcrete, cast, and industrial applications.
Frequently Asked Questions
What is a heavy duty hydraulic concrete pump?
A heavy duty hydraulic concrete pump is designed to transport concrete, refractory materials, shotcrete, and other cementitious materials under demanding operating conditions.
What is the pressure of the X-10?
The X-10 provides 2,200 PSI piston face pressure.
What is the maximum output?
The X-10 provides an output range of 0–12 cubic yards per hour.
What applications can the X-10 handle?
The X-10 is designed for refractory, cast, and shotcrete applications, including furnace repair, kiln maintenance, steel plant work, and industrial construction.
What is the hopper capacity?
The X-10 has a 2,500 lb. swing-out receiving hopper with a hydraulic agitator.
What power options are available?
The X-10 is available with a 66 HP Kubota V3600 water-cooled diesel engine or a 40 HP electric motor.
Does the X-10 have maintenance options?
Yes. Available options include a 2,000 PSI hydraulic pressure washer and Vogel automatic lubrication system.
Can the X-10 be controlled remotely?
Yes. Pendant or wireless remote control is available as an option.
Get the X-10 Heavy Duty Hydraulic Concrete Pump
If you need a dependable heavy duty hydraulic concrete pump for refractory, shotcrete, furnace, kiln, steel plant, or industrial construction applications, the X-10 Piston Pump delivers ultra high pressure performance with a rugged and maintenance-friendly design.
With 2,200 PSI piston face pressure and output of up to 12 cubic yards per hour, the X-10 is engineered for demanding professional pumping applications.
