The X-10 2500 lb hopper concrete pump is an ultra-high-pressure swing tube piston pump designed for demanding refractory, cast, and shotcrete applications. Featuring a 2,500 lb. capacity swing-out receiving hopper with hydraulic agitator, the X-10 combines high-pressure pumping performance with a practical, maintenance-friendly design.
The X-10 piston pump delivers up to 12 cubic yards per hour and provides a powerful 2,200 PSI piston face pressure, making it suitable for demanding material pumping and extended pumping distances.
X-10 Piston Pump with 2500 lb Hopper
The X-10 piston pump is engineered for contractors who need reliable high-pressure material pumping combined with convenient equipment operation and maintenance.
Its 2,500-pound-capacity receiving hopper provides substantial material capacity while the integrated hydraulic agitator helps maintain consistent material movement toward the pumping system.
The hopper is also designed to swing out, providing fast access to the swing tube section for cleaning and routine maintenance.
2,500 lb. Capacity Swing-Out Receiving Hopper
One of the key features of the X-10 is its 2,500 lb. swing-out receiving hopper.
A larger receiving hopper can help support productive pumping operations by allowing material to be loaded efficiently. The hydraulic agitator helps keep material moving inside the hopper and toward the piston pumping system.
The swing-out design provides another important advantage: convenient access to the swing tube section.
Operators can access the pumping components more easily for cleaning, inspection, and routine maintenance, helping reduce unnecessary downtime.
2,200 PSI High-Pressure Piston Pump
The X-10 provides a 2,200 PSI piston face pressure, giving it the pumping force required for demanding refractory and shotcrete applications.
High piston pressure is particularly useful when material must be transported through extended delivery lines or placed in challenging locations.
With a maximum output of 12 cubic yards per hour, the X-10 combines high-pressure capability with production capacity for professional pumping applications.
Ultra-High-Pressure Swing Tube
The X-10 features a 3-inch x 24-inch ultra-high-pressure swing tube.
The swing tube works with the piston system to transfer material from the receiving hopper through the pump and toward the 3-inch discharge.
The design is engineered for demanding pumping environments while providing convenient access through the swing-out hopper for cleaning and maintenance.
Hydraulic Hopper Agitator
The hydraulic hopper agitator is an important part of the X-10's material-feeding system.
The agitator helps maintain consistent movement of material inside the 2,500 lb. receiving hopper. This can help support steady material feeding during refractory and shotcrete applications.
Combined with the swing tube piston system, the hydraulic agitator provides a practical solution for high-pressure material pumping.
Reliable Solid-State Electronics
The X-10 includes reliable solid-state electronics designed to provide dependable pump control.
The solid-state control system complements the heavy-duty mechanical components and contributes to the machine's user-friendly operating design.
The X-10 is also CE certified, supporting applications and markets where CE-certified equipment is required.
Forklift Tubing for Easy Flat-Pack Removal
The X-10 includes forklift tubing mounted to the lower hopper.
This feature is designed to make flat-pack removal and equipment handling more convenient. It can provide additional flexibility when positioning or handling the pump on demanding construction and industrial jobsites.
A skid-mounted configuration with forklift tubing is also available.
Key Features of the X-10 2500 lb Hopper Concrete Pump
2,500 lb. capacity swing-out receiving hopper
Hydraulic hopper agitator
2,200 PSI piston face pressure
Output up to 12 cubic yards per hour
3-inch x 24-inch ultra-high-pressure swing tube
3-inch discharge
Swing-out hopper for easy swing tube access
Reliable solid-state electronics
Forklift tubing mounted to lower hopper
Easy flat-pack removal
CE certification
Diesel and electric power options
Designed for refractory, cast, and shotcrete applications
Power Options
The X-10 2500 lb hopper concrete pump is available with two primary power configurations.
Kubota V3600 Diesel Power
The diesel configuration features a Kubota V3600 66 HP water-cooled diesel engine, providing a powerful solution for demanding field applications.
40 HP Electric Motor
A 40 HP electric motor is available for applications where electric power is preferred and suitable electrical service is available.
These power options allow contractors to select a configuration that best suits their jobsite environment.
Available Options
The X-10 can be configured with several additional options:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire mount
Pendant or wireless remote
Skid-mounted configuration with forklift tubing
These options can enhance cleaning, lubrication, control, mobility, and overall jobsite convenience.
X-10 2500 lb Hopper Concrete Pump Specifications
Specification X-10
Pump Type 3-inch x 24-inch Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Output 0–12 Cubic Yards Per Hour
Discharge 3 inches
Hopper 2,500 lb. Capacity Swing-Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Electrical Control Solid-State Valve Control
Diesel Power Kubota V3600 66 HP Water-Cooled Diesel
Electric Power Option 40 HP Electric Motor
Trailer Single 6,000 lb. Capacity Axle with Electric Braking and Lights
Dimensions 156 x 76 x 80 inches
Weight 4,500 lbs.
Applications for the X-10 Concrete Pump
The X-10 is designed for demanding applications requiring reliable material pumping and high pressure.
Typical applications include:
Refractory pumping
Shotcrete placement
Castable material pumping
Industrial refractory projects
High-pressure concrete material placement
Extended-distance material pumping
Construction and industrial pumping applications
The combination of the 2,500 lb. hopper, hydraulic agitator, and high-pressure piston system makes the X-10 suitable for professional pumping environments.
Easy Cleaning and Maintenance
The X-10 is designed to make routine maintenance more convenient.
The swing-out receiving hopper provides quick access to the swing tube section. This allows operators to perform cleaning, inspection, and routine service more easily.
The hydraulic agitator supports material movement, while the forklift tubing provides additional equipment-handling flexibility.
These features are designed to help contractors reduce unnecessary downtime and keep the pump ready for continued operation.
Designed for Fast Return on Investment
The X-10 combines production capacity with high-pressure pumping performance and service-friendly features.
With output up to 12 cubic yards per hour and 2,200 PSI piston face pressure, the pump is designed to support demanding refractory and shotcrete work.
The 2,500 lb. hopper capacity and hydraulic agitation help support efficient material feeding, while the swing-out design makes cleaning and maintenance more accessible.
Why Choose the X-10 2500 lb Hopper Concrete Pump?
The X-10 2500 lb hopper concrete pump provides a combination of high-pressure performance, large receiving capacity, and convenient maintenance access.
Its 2,500 lb. swing-out receiving hopper, hydraulic agitator, 2,200 PSI piston face pressure, 12 cubic yards per hour maximum output, solid-state electronics, and forklift tubing make it a versatile solution for demanding pumping applications.
For contractors looking for a high-pressure piston pump with a substantial hopper capacity and user-friendly maintenance design, the X-10 is engineered to provide dependable performance.
Quote Now or Download the Brochure
Looking for a reliable 2500 lb hopper concrete pump for refractory, shotcrete, or industrial pumping?
The X-10 piston pump combines ultra-high-pressure performance with a 2,500 lb. swing-out receiving hopper, hydraulic agitation, flexible power options, and convenient maintenance access.
Quote Now to discuss your application and equipment requirements or Download the Brochure for more information about the X-10.
