Choosing the right continuous mixer pump for mining projects is essential for efficient concrete mixing and material delivery in challenging underground environments. The Blastcrete MineMate is a specialized, low-profile concrete mixing and pumping system designed for underground mine seals, grouting, and shotcrete applications where ready-mix concrete is not a practical option.
Combining the X-10 ultra-high-pressure swing tube piston pump with a high-shear continuous mixer, the MineMate provides an integrated solution for preparing and pumping concrete materials directly at the job site. With a specified pumping pressure of 2,200 PSI, an output capacity of up to 12 cubic yards per hour, and the ability to pump suitable materials over distances exceeding 500 feet, the MineMate is engineered to support demanding mining and underground construction operations.
Request a Quote or Download the MineMate Brochure to Explore Its Features, Specifications, and Available Options.
What Is the Blastcrete MineMate Continuous Mixer Pump?
The Blastcrete MineMate is a concrete mixing and pumping machine developed for underground mining and construction applications. It combines continuous mixing technology with a high-pressure piston pump, helping operators prepare and deliver suitable concrete materials when ready-mix delivery is unavailable or unsuitable.
The system features a 3-inch × 24-inch ultra-high-pressure swing tube piston pump and a high-shear continuous mixer. An integrated material screw conveyor with a bin indicator charges material into the mixer, helping simplify material handling and support efficient operation.
Designed for restricted underground environments, the MineMate can operate within a 6-foot ceiling. Its compact, low-profile configuration makes it suitable for mine sealing, underground grouting, and shotcrete applications that require specialized equipment for confined spaces.
Key Features of the MineMate Continuous Mixer Pump
1. High-Pressure Swing Tube Piston Pump
The MineMate incorporates a 3-inch × 24-inch ultra-high-pressure swing tube piston pump designed for demanding concrete pumping applications.
With a specified pumping pressure of 2,200 PSI, the pump supports the delivery of compatible concrete and grout materials through underground pumping lines. This capability is useful for mining projects where materials must reach difficult-to-access work areas.
2. High-Shear Continuous Mixer
The integrated high-shear continuous mixer combines material preparation with pumping in one machine. This configuration supports on-site mixing and delivery for underground mine seals, grouting, and shotcrete applications.
For mining contractors working in remote or confined locations, having mixing and pumping functions in one system can help simplify equipment setup and material handling.
3. Compact Design for Underground Mining
Underground mining environments frequently have limited headroom and restricted equipment access. The MineMate is designed to operate within a 6-foot ceiling, helping make it suitable for low-clearance working areas.
Its low-profile configuration supports the use of concrete mixing and pumping equipment in locations where larger machines may be impractical.
4. Integrated Material Screw Conveyor
The MineMate features a material screw conveyor with a bin indicator to charge the continuous mixer. This arrangement helps streamline material feeding and reduce manual handling requirements.
By combining material charging, mixing, and pumping, the MineMate supports an integrated workflow for underground construction and mining operations.
5. Pumping Distance Exceeding 500 Feet
Delivering concrete and grout to underground work areas can be challenging when the placement point is far from the equipment. The MineMate can pump suitable materials over distances exceeding 500 feet, depending on material properties, pipeline configuration, elevation, and operating conditions.
This capability offers flexibility for mine sealing, underground grouting, and compatible shotcrete applications.
6. Flexible Electric and Diesel Power Options
The Blastcrete MineMate offers two power configurations to accommodate different job-site requirements:
50 HP electric motor: Supplied with a starter and disconnect.
66 HP Kubota V3600 diesel engine: Water-cooled diesel power option.
These choices allow operators to select a configuration suited to their available power infrastructure and operating environment.
Applications of a Continuous Mixer Pump for Mining Projects
Underground Mine Sealing
Mine sealing projects require suitable concrete materials to be delivered and placed according to project-specific engineering requirements. The MineMate is designed to mix and pump materials for underground mine seals, providing an integrated solution when ready-mix concrete is not available.
Underground Grouting
Grouting is used in various mining and underground construction activities. The MineMate combines continuous mixing with high-pressure pumping to support the preparation and delivery of suitable grout materials to confined or difficult-to-reach locations.
Underground Shotcrete Applications
Shotcrete is commonly used in underground construction and ground-support projects. The MineMate is designed for underground shotcrete applications requiring on-site mixing and pumping. Material compatibility and the required placement method should be confirmed for each project.
Concrete Placement in Restricted Areas
Underground projects often involve limited working space, low ceilings, and challenging material transportation
