Rotor Type Shotcrete Machine for Industrial Applications
A rotor type shotcrete machine is widely used in construction and refractory industries for precise, continuous, and efficient material application. The Genuine Piccola (AA 020) from Blastcrete is a proven solution designed for dry gunning and shotcrete operations in demanding industrial environments.
With an output capacity of 0 to 6 tons per hour, this machine is ideal for furnace lining, kiln maintenance, cement plants, steel mills, and other heavy-duty industrial applications requiring reliable refractory spraying performance.
Efficient Rotor Type Design for Consistent Performance
The Genuine Piccola uses a heavy-duty gearbox that rotates the rotor section, ensuring smooth and controlled material flow. This rotor-based system provides accurate dosing and consistent spraying quality, making it highly efficient for refractory and concrete applications.
Its simple and rugged design reduces downtime and ensures long service life, making it a cost-effective solution for contractors and industrial maintenance teams.
Key Features
Simple Piccola single-point clamping system
Precise material output control through rotor mechanism
Heavy-duty gearbox for reliable operation
Recommended by major refractory material manufacturers
Forklift pickup for easy handling and transport
Durable industrial-grade construction
Low maintenance and operating costs
Power Options
The Genuine Piccola rotor type shotcrete machine offers flexible power configurations:
5 HP Electric Motor (240V or 480V, 3-Phase)
16 AM Gast Air Motor
13 HP Honda Gasoline Engine
These options allow operation in indoor plants, outdoor sites, and remote industrial environments.
Optional Equipment
To enhance flexibility and performance, the machine can be equipped with:
Skid-mounted frame with forklift pickup
12-hole round half rotor
12-hole round full rotor
9-hole round full rotor
12-hole sector full rotor
Hydrostatic pre-dampener
Water booster pump
These configurations allow optimization for different refractory materials and project requirements.
Technical Specifications
Specification Details
Output Capacity 0–6 tons per hour
Air Requirement 250–600 CFM (depending on power option)
Outlet Connection 1.5-inch connection cup
Maximum Aggregate Size 3/4 inch
Mounting Solid rubber tires
Estimated Wear Pad Life Approximately 200 tons
Dimensions 50 in × 34 in × 52 in
Weight 1,250 lbs
Applications
The Genuine Piccola rotor type shotcrete machine is suitable for a wide range of applications, including:
Refractory gunning and installation
Furnace lining repair and maintenance
Kiln lining projects
Cement plant maintenance
Steel mill refractory applications
Foundry operations
Petrochemical facilities
Power generation plants
Industrial concrete repair projects
Its rotor-based system ensures consistent output, reduced rebound, and high-quality application results.
Benefits of the Genuine Piccola
Reliable rotor-based shotcrete performance
Heavy-duty construction for industrial use
Low maintenance requirements
Flexible power options for various job sites
Easy transportation with forklift pickup
Cost-effective long-term operation
Trusted performance in refractory applications
Rotor Type Shotcrete Machine Genuine Piccola AA 020
