High-Performance Ultra High Pressure Pumping System for Demanding Construction and Refractory Work
The X-10 Piston Pump is a powerful heavy duty hydraulic concrete pump engineered for extreme industrial applications such as shotcrete, refractory installation, and high-pressure concrete placement. Designed for durability, efficiency, and continuous operation, the X-10 delivers exceptional performance in mining, tunneling, cement plants, steel industries, and large-scale infrastructure projects.
With an output capacity of up to 12 cubic yards per hour and a robust 2200 PSI piston pressure system, this machine is built to handle the toughest hydraulic concrete pumping demands.
X-10 Heavy Duty Hydraulic Concrete Pump Overview
The X-10 is a next-generation heavy duty hydraulic concrete pump designed with a high-strength hydraulic drive system that ensures smooth, consistent material flow under extreme pressure conditions. Its swing tube piston technology provides stable pumping performance even with dense and abrasive materials.
This makes it an ideal solution for contractors who require reliable high-pressure pumping for continuous industrial operations.
Key Features of the X-10 Piston Pump
Heavy duty hydraulic concrete pump design for extreme industrial use
2200 PSI piston face pressure for long-distance and high-density pumping
Ultra high pressure swing tube system for smooth material delivery
Swing-out receiving hopper design for fast cleaning and maintenance access
Heavy-duty hopper agitator for consistent mixing of materials
Forklift-compatible lower hopper tubing for easy handling and transport
Solid state electronic control system for reliable operation
CE certified industrial construction for global compliance standards
These features make the X-10 one of the most reliable systems in the heavy duty hydraulic concrete pump category.
Power Options
The X-10 piston pump is available with flexible power configurations:
Kubota V3600 66 HP water-cooled diesel engine
40 HP industrial electric motor
These options allow the system to operate efficiently in both remote construction sites and fixed industrial plants.
Optional Equipment
To enhance performance and operational efficiency, the X-10 can be equipped with:
2,000 PSI hydraulic pressure washer for cleaning
Vogel automatic lubrication system for reduced maintenance
Spare tire mounting for mobility support
Pendant or wireless remote control system
Skid-mounted configuration with forklift tubing
These upgrades improve productivity and usability in all heavy duty hydraulic concrete pump applications.
Technical Specifications of X-10 Piston Pump
Pump Type: 3 inch x 24 inch ultra high pressure swing tube piston pump
Maximum Pressure: 2200 PSI
Output Capacity: 0–12 cubic yards per hour
Discharge Size: 3 inch
Hopper Capacity: 2,500 lb swing-out receiving hopper with hydraulic agitator
Operating Platform: 22 sq. ft.
Control System: Solid state variable electronic control
Trailer: Single 6,000 lb axle with electric braking and lighting system
Dimensions: 156" x 76" x 80"
Weight: 4,500 lbs
Applications of the Heavy Duty Hydraulic Concrete Pump
Shotcrete & Refractory Applications
Ideal for furnace lining, kiln repair, tunnel support, and high-temperature refractory installation requiring high-pressure delivery.
Industrial Construction & Maintenance
Used in steel plants, cement factories, and power plants for structural repair and heavy-duty concrete placement.
Mining & Underground Projects
Perfect for tunnel construction, rock stabilization, and underground shotcrete applications in extreme environments.
Advantages of the X-10 Heavy Duty Hydraulic Pump
High-pressure hydraulic performance for industrial applications
Reliable 2200 PSI pumping power
Reduced downtime with easy maintenance design
Strong and durable construction for harsh environments
Efficient operation for continuous industrial use
These advantages make it a leading solution in the heavy duty hydraulic concrete pump category.
X-10 Piston Pump Heavy Duty Hydraulic Concrete Pump for Industrial Applications
