Powerful Refractory Castable Pump for High-Density Material Applications
Industrial refractory projects require equipment that can handle heavy-duty castable materials while maintaining consistent mixing and pumping performance. The MX-10 Mixer / Pump is designed as a high-performance refractory castable pump for dense refractory shotcrete, pump cast installations, and demanding monolithic refractory applications.
Featuring an ultra high-pressure 3-inch swing tube piston pump and a high-torque hydraulic pan mixer, the MX-10 provides reliable material processing for challenging environments. Since 1996, this machine has been widely used for refractory installation projects where durability, efficiency, and precise material placement are essential.
MX-10 Dense Refractory Shotcrete Pump Performance
The MX-10 is engineered to pump dense refractory materials with exceptional pressure and consistency. Its 2200 PSI piston face pressure provides the power needed for rugged refractory pump cast and shotcrete applications.
The integrated 2200 lb. capacity high-torque pan mixer ensures uniform mixing of refractory castables with a quick 1.5 to 2 minute mixing cycle. The system can consistently deliver up to 10 tons per hour and pump refractory materials more than 300 feet vertically, making it suitable for large-scale industrial repair and construction projects.
Features of MX-10 Mixer / Pump
Designed for dense refractory shotcrete and pump cast applications
3-inch x 24-inch ultra high-pressure swing tube piston pump
2200 PSI piston face pressure for demanding refractory materials
2200 lb. hydraulic pan mixer capacity
Fast 1.5 to 2 minute mixing cycle
Swing-out receiving hopper for easy cleaning and maintenance
Forklift tubing mounted lower hopper for quick flat-pack removal
Fill Rite water meter for controlled water measurement
20-gauge dousing bucket for fast water introduction
Reliable solid-state electronics
CE certification
Power Options
The MX-10 Mixer / Pump is available with several power configurations:
John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
Dual 40 HP electric motors
Optional Equipment
Available options for increased flexibility and productivity include:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire mounted option
Pendant or wireless remote control
Skid-mounted configuration with forklift tubing
MX-10 Technical Specifications
Specification Details
Pump 3" x 24" Ultra High Pressure Swing Tube
Pump Pressure 2200 PSI
Mixer 2200 lb. Capacity Hydraulic Pan Mixer
Output 0-12 Cubic Yards Per Hour
Discharge 3"
Hopper 2,500 lb. Capacity Swing-Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Crane Pickup Central Four Point Pickup – No Spreader Bar Needed
Electrical System Solid State Valve Control
Trailer Dual 6,000 lb. Capacity Axles with Electric Braking and Lights
Dimensions 204" x 88" x 117"
Weight 9,000 lbs.
Improve Refractory Installation Efficiency with MX-10 Technology
The MX-10 Mixer / Pump delivers the strength and reliability required for demanding refractory applications. Its combination of high-pressure pumping, powerful mixing capability, and rugged construction makes it an ideal choice for contractors working with dense refractory materials.
