When working on demanding refractory shotcrete and pump cast projects, contractors require equipment that delivers consistent performance, reliable material flow, and easy maintenance. The MX-10 Mixer/Pump combines a high torque hydraulic mixer with a swing out hopper concrete pump, creating a powerful solution designed for heavy-duty industrial applications. Since 1996, the MX-10 has been trusted worldwide for monolithic refractory installations where durability and productivity are essential.
Engineered for High-Performance Refractory Work
The MX-10 is a 3-inch ultra-high-pressure swing tube mixer/pump specifically designed to handle dense refractory materials. Its advanced pumping system and efficient mixing capabilities allow operators to achieve consistent output of up to 10 tons per hour, making it ideal for large-scale industrial construction and maintenance projects.
Whether pumping refractory concrete for furnaces, kilns, boilers, or industrial processing facilities, the MX-10 delivers dependable results even under the toughest conditions.
High Torque Hydraulic Mixer for Superior Mixing Performance
A key feature of the MX-10 is its high torque hydraulic mixer, designed to produce uniform refractory mixes quickly and efficiently. The 2200 lb. hydraulic pan mixer completes mixing cycles in approximately 1.5 to 2 minutes, helping crews maximize productivity while maintaining consistent material quality.
Benefits of the High Torque Hydraulic Mixer
High-torque hydraulic drive for efficient mixing
2200 lb. mixing capacity for large batches
Fast 1.5–2 minute mix times
Uniform blending of dense refractory materials
Increased production with reduced labor
Reliable performance on demanding job sites
The hydraulic mixing system ensures every batch is thoroughly blended before entering the pumping system, reducing waste and improving installation quality.
Swing Out Hopper Concrete Pump for Easy Maintenance
The MX-10 also features a durable swing out hopper concrete pump that simplifies daily cleaning and servicing. The swing-out receiving hopper provides direct access to the swing tube section, allowing operators to perform maintenance quickly and efficiently.
Advantages of the Swing Out Hopper Concrete Pump
Quick access to the lower hopper for cleaning
Reduced maintenance downtime
Hydraulic agitator keeps material flowing smoothly
Forklift tubing allows convenient flat-pack removal
Simplified inspection of critical pump components
This user-friendly design minimizes service interruptions and helps contractors maintain peak equipment performance throughout every project.
Powerful Pumping Capability
Built around a 3-inch by 24-inch ultra-high-pressure swing tube pump, the MX-10 delivers 2200 PSI pump pressure for challenging refractory shotcrete and pump cast applications.
Its pumping system can transport dense refractory materials more than 300 feet vertically, making it suitable for large industrial installations where long-distance material placement is required.
Designed for Maximum Productivity
The MX-10 includes numerous features that improve efficiency and reduce operating costs:
2200 PSI piston face pressure
2200 lb. capacity hydraulic pan mixer
Swing-out receiving hopper
Hydraulic agitator
Fill Rite water meter
20-gallon dousing bucket for rapid water introduction
Reliable solid-state electronics
CE Certification
Together, these features allow contractors to complete projects faster while maintaining consistent material quality.
Flexible Power Options
The MX-10 is available with multiple power configurations to meet various job site requirements:
John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
Dual 40 HP electric motors
These options provide flexibility for both outdoor and indoor refractory installations.
Available Optional Equipment
Contractors can customize the MX-10 with several optional upgrades, including:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire
Pendant or wireless remote controls
Skid-mounted configuration with forklift tubing
These accessories improve convenience, simplify maintenance, and enhance operator productivity.
MX-10 Technical Specifications
Specification Details
Pump 3" × 24" Ultra High Pressure Swing Tube
Pump Pressure 2200 PSI
Mixer 2200 lb. Capacity High Torque Hydraulic Pan Mixer
Output 0–12 Cubic Yards Per Hour
Discharge 3 inches
Hopper 2,500 lb. Swing Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Crane Pickup Central Four-Point Pickup
Trailer Dual 6,000 lb. Capacity Axles with Electric Brakes
Dimensions 204" × 88" × 117"
Weight 9,000 lbs.
Why Choose the MX-10 Mixer/Pump?
The MX-10 has earned its reputation by delivering dependable performance on some of the industry's most demanding refractory projects. Its combination of a high torque hydraulic mixer and swing out hopper concrete pump provides contractors with the productivity, durability, and ease of maintenance needed to complete jobs efficiently.
Key Benefits
High-capacity hydraulic mixing
Ultra-high-pressure pumping performance
Easy-access swing-out hopper design
Fast cleaning and maintenance
Heavy-duty industrial construction
Proven reliability since 1996
Excellent return on investment
Worldwide service and support
MX-10 Mixer/Pump: High Torque Hydraulic Mixer with a Swing Out Hopper Concrete Pump for Refractory Applications
