Successful refractory installations require equipment that can handle extreme temperatures, dense materials, and demanding operating conditions. The MX-10 Mixer/Pump is engineered to deliver reliable performance for these challenging applications by combining powerful mixing technology with ultra-high-pressure pumping capability.
Designed as advanced monolithic refractory installation equipment, the MX-10 has been the industry standard for refractory shotcrete and pump cast applications since 1996. Its powerful 2200 PSI piston concrete pump system provides the pressure and consistency needed for large-scale industrial refractory projects.
High-Performance 2200 PSI Piston Concrete Pump Technology
The MX-10 features a rugged 2200 PSI piston concrete pump system designed for pumping dense refractory materials with exceptional reliability. The ultra-high-pressure 3-inch swing tube pump delivers consistent material flow even in demanding applications where long-distance pumping and high pressure are required.
Advantages of the 2200 PSI Pump System
2200 PSI piston face pressure
Designed for refractory pump cast and shotcrete applications
Handles dense and abrasive materials
Pumps refractory materials over 300 feet vertically
Provides consistent material placement
Built for continuous industrial operation
This powerful pumping technology allows contractors to complete complex refractory installations with improved efficiency and reliability.
MX-10 as Complete Monolithic Refractory Installation Equipment
The MX-10 is specifically designed as professional monolithic refractory installation equipment for industries requiring durable and precise refractory lining applications.
Common applications include:
Steel furnaces
Cement kilns
Industrial boilers
Power plants
Petrochemical facilities
Foundries
High-temperature processing equipment
By combining mixing and pumping into one integrated machine, the MX-10 simplifies job site operations and improves installation productivity.
High-Torque Hydraulic Pan Mixer Performance
The MX-10 includes a 2200 lb. capacity high-torque hydraulic pan mixer designed to prepare consistent refractory mixes quickly. With a mixing cycle of approximately 1.5 to 2 minutes, contractors can maintain efficient production throughout demanding projects.
Hydraulic Mixer Features
2200 lb. mixing capacity
High-torque hydraulic drive
Fast batch preparation
Uniform material blending
Improved pumping consistency
Reduced installation delays
The advanced mixer design ensures materials achieve the correct consistency before entering the high-pressure pumping system.
Designed for Maximum Productivity
The MX-10 Mixer/Pump can consistently deliver up to 10 tons of material per hour, making it suitable for large industrial refractory projects requiring dependable output.
Its integrated system combines:
High-capacity hydraulic mixing
Ultra-high-pressure pumping
Efficient material handling
Easy maintenance access
Flexible power configurations
This combination helps contractors improve productivity while maintaining installation quality.
Easy Maintenance with Swing-Out Hopper Design
Maintenance efficiency is a key advantage of the MX-10. The swing-out receiving hopper provides quick access to the lower hopper and swing tube section, allowing operators to perform cleaning and servicing with minimal downtime.
Maintenance-Friendly Features
2,500 lb. swing-out receiving hopper
Hydraulic agitator for continuous material movement
Forklift tubing for easy flat-pack removal
Fill Rite water meter
20-gallon dousing bucket for fast water introduction
Reliable solid-state electronics
CE Certification
These features help extend equipment uptime and simplify daily operation.
Flexible Power Options
The MX-10 is available with multiple power configurations to meet different job site requirements:
John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
Dual 40 HP electric motors
These options provide flexibility for both remote construction locations and industrial facilities with electrical power availability.
Optional Equipment
Contractors can customize the MX-10 with additional accessories, including:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire mounted
Pendant remote control
Wireless remote control
Skid-mounted configuration with forklift tubing
These options improve convenience, maintenance efficiency, and operational control.
MX-10 Mixer/Pump Specifications
Specification Details
Pump 3" × 24" Ultra High Pressure Swing Tube
Pump Pressure 2200 PSI
Mixer 2200 lb. Capacity Hydraulic Pan Mixer
Output 0–12 Cubic Yards Per Hour
Discharge 3 inches
Hopper 2,500 lb. Capacity Swing-Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Crane Pickup Central Four-Point Pickup (No Spreader Bar Needed)
Electrical Solid State Valve Control
Trailer Dual 6,000 lb. Capacity Axles with Electric Braking and Lights
Dimensions 204" × 88" × 117"
Weight 9,000 lbs.
Why Choose the MX-10 Mixer/Pump?
The MX-10 provides contractors with a complete solution for demanding refractory applications. Its combination of a 2200 PSI piston concrete pump and advanced monolithic refractory installation equipment capabilities makes it a dependable choice for industrial projects worldwide.
Key Benefits
Proven industry performance since 1996
Ultra-high-pressure pumping capability
High-capacity hydraulic mixing system
Reliable performance with dense refractory materials
Easy cleaning and maintenance
Multiple power options
Optional remote control operation
Heavy-duty industrial construction
Excellent return on investment
MX-10 Mixer/Pump: Advanced 2200 PSI Piston Concrete Pump for Monolithic Refractory Installation Equipment
