Refractory Construction Equipment: 2200 LB Pan Mixer for Refractory Castable Applications

Introduction to the 2200 LB Pan Mixer

The 2200 LB Pan Mixer is a professional-grade mixer for refractory castable designed to provide consistent and efficient mixing performance for demanding industrial applications. Built as reliable refractory construction equipment, this hydraulic pan mixer is engineered for preparing up to 1 metric ton of refractory castable materials with excellent uniformity.

Featuring a heavy-duty planetary gearbox and hydrostatic drive system, the mixer delivers dependable performance for refractory installation projects, furnace repairs, kiln maintenance, and industrial construction applications.

High-Performance Mixer for Refractory Castable

A properly mixed refractory material is essential for achieving strength, durability, and long service life in high-temperature environments. The 2200 LB Pan Mixer provides controlled mixing action to produce consistent refractory castable batches.

The heavy-duty planetary gearbox enables efficient mixing cycles with typical mix times of 1.5 to 2 minutes, helping contractors complete refractory installation work faster while maintaining material quality.

Key Features of the 2200 LB Pan Mixer
Large Capacity Hydraulic Mixing System

The mixer is designed with a 2200-pound hydraulic pan mixing capacity, making it suitable for large-scale refractory and industrial applications. Its robust design supports continuous operation in demanding environments.

Bottom Discharge System

The hydraulic bottom discharge feature allows smooth and efficient material removal after mixing. This design improves productivity and simplifies handling during refractory installation projects.

Precise Water Addition Control

The integrated Fill-Rite water meter and 20-gallon dousing tank provide accurate water measurement, helping operators maintain the correct material consistency for different refractory castables.

Heavy-Duty Operator Platform

The 15 sq. ft. operator platform includes:

Guard rails for improved safety
Ladder access
Forward, stop, and reverse mixer controls
Bottom slide door open/close controls
Manual hydraulic mixer tilt controls for cleaning
Easy Transportation and Setup

Built-in forklift pickup points make transportation and positioning easier on industrial job sites. Telescoping adjustable legs provide additional installation flexibility.

Power Configuration

The 2200 LB Pan Mixer is powered by:

40 HP electric motor with starter and disconnect

This configuration provides reliable operation for industrial facilities and controlled construction environments.

Optional Equipment

Available options include:

Hydraulic discharge chute
Separately mounted power supply
Hydraulic leg adjustment system
2,000 PSI hydraulic pressure washer
Three-position height discharge adjustment
Technical Specifications
Specification Details
Mixer Capacity 2200 lbs.
Application Refractory castable mixing
Mixing Time 1.5–2 minutes
Drive System Hydrostatic drive with planetary gearbox
Weight 4,500 lbs.
Length 120 inches
Width 72 inches
Height (Down Position) 82 inches
Height (Raised Position) 103 inches
Material Discharge Height (Down Position) 52 inches
Material Discharge Height (Raised Position) 72 inches
Applications of the 2200 LB Pan Mixer

This refractory construction equipment is designed for industries requiring reliable castable preparation, including:

Furnace lining installation
Kiln repair projects
Steel plant refractory maintenance
Cement plant repairs
Industrial furnace construction
Heat-resistant concrete applications
Monolithic refractory installations
Why Choose the 2200 LB Pan Mixer?

The 2200 LB Pan Mixer combines high capacity, precise mixing control, and durable construction to meet the needs of professional refractory contractors and industrial users. As an efficient mixer for refractory castable, it helps improve productivity while delivering consistent material quality for demanding high-temperature applications.

With its hydraulic operation, accurate water management system, and heavy-duty design, this mixer is a dependable choice for modern refractory construction projects.
