Modern construction projects require reliable equipment that can handle both material mixing and long-distance pumping with consistent performance. A Concrete Pump with Mixer combines two essential functions into one powerful system, helping contractors improve productivity, reduce labor requirements, and maintain quality material placement.
The HBS-1500 Ball Seat Pump from Blastcrete is a versatile pump and mixer solution designed for demanding gypsum flooring, concrete pumping, and industrial construction applications. With its integrated hydraulic mixer, high-pressure pumping system, and durable design, the HBS-1500 provides contractors with a dependable solution for efficient material processing and delivery.
Advanced Pump and Mixer Equipment for Construction Applications
The HBS-1500 is engineered as complete Pump and Mixer Equipment, combining a hydraulic spiral mixer and hydraulic ball seat pump into one machine. This integrated design allows operators to mix materials and pump them directly to the application area without requiring separate equipment.
The machine is specifically designed for mixing and pumping gypsum flooring materials over extreme distances. Its 4-inch hydraulic ball seat pump delivers up to 1000 PSI line pressure and can consistently pump gypsum materials beyond 600 feet at a production rate of approximately 130 bags per hour.
HBS-1500 Ball Seat Pump Technology
The HBS-1500 Ball Seat Pump features an innovative ball seat pumping system designed to reduce maintenance requirements and improve operational reliability.
Key advantages include:
4-inch hydraulic ball seat pump design
Up to 1000 PSI pumping pressure capability
Long-distance material pumping performance
Reduced wear compared with traditional pumping systems
Easy cleaning and servicing
The ball seat design helps lower operating costs by reducing wear on critical pumping components, making the HBS-1500 a cost-effective choice for professional contractors.
Integrated Concrete Pump with Mixer Design
The HBS-1500 combines mixing and pumping functions into a single, efficient unit. This design improves workflow by allowing materials to be mixed, transferred, and pumped without additional handling equipment.
The system includes:
12 cubic foot hydraulic spiral mixer
30-second mixing cycle
Hydraulic mixer dump function
26 cubic foot receiving hopper
Hydraulic conveying agitator
The receiving hopper and pump manifold can be unclamped from the pumping tubes, allowing quick access for cleaning the ball-seat manifold and material lines.
Features of the HBS-1500 Pump and Mixer Equipment
Powerful Hydraulic Ball Seat Pump
The 4-inch hydraulic ball seat pump provides excellent pressure performance for gypsum materials and concrete mixes.
High-Capacity Mixing System
The hydraulic spiral mixer ensures consistent material blending while supporting continuous production.
Large Receiving Hopper
The 26 cubic foot receiving hopper with hydraulic agitator improves material flow and helps maintain smooth pumping operation.
Heavy-Duty Construction
The HBS-1500 is built with a heavy-duty tubular frame designed for demanding construction environments.
Mobile Dual Axle Trailer Design
The dual axle trailer with two braking axles provides stability and easy transportation between job sites.
Low Maintenance Operation
The machine features low-cost wear parts and a simplified pumping design to help reduce downtime and maintenance expenses.
Technical Specifications
HBS-1500 Specifications
Length: 234 inches
Width: 92 inches
Height (Water Tank): 93 inches
Height (Mixer Dump Position): 95 inches
Mixer Charging Height: 57 inches
Weight: 8,350 lbs.
Output: 0–15 cubic yards per hour
Mixer Capacity: 12 cubic feet
Receiving Hopper Capacity: 26 cubic feet
Pump Type: 4-inch Hydraulic Ball Seat Pump
Power Options
The HBS-1500 is powered by:
70 HP Kubota water-cooled diesel engine
Additional configurations are available to meet different project requirements.
Available Options
The HBS-1500 can be customized with:
2000 PSI hydraulic pressure washer
Spare tire
Electric power option
Skid mount configuration
Custom paint options
Applications of the HBS-1500 Ball Seat Pump
Gypsum Flooring Projects
The HBS-1500 is ideal for:
Gypsum floor underlayment installation
Commercial flooring applications
Large-area floor leveling projects
Industrial flooring systems
Concrete Pumping Applications
The machine can also handle:
Concrete mixes with aggregate up to 1/2 inch
Concrete repair work
Construction material placement
Specialty pumping applications
Industrial Construction
The HBS-1500 supports:
Large-scale construction projects
Infrastructure applications
Heavy-duty material pumping
Professional contractor operations
Benefits of Using the HBS-1500 Concrete Pump with Mixer
Choosing the HBS-1500 provides contractors with:
Combined mixing and pumping capability
High-pressure material delivery
Long-distance pumping performance
Faster job completion
Reduced equipment requirements
Easy maintenance and cleaning
Versatile material handling capabilities
