HBS-1500 Ball Seat Pump – Compact and Powerful Concrete Pumping Solution
The HBS-1500 Ball Seat Pump is a versatile mixer and pumping system designed for contractors who require reliable small concrete pump machine performance without compromising power and efficiency. Built for professional concrete placement applications, the HBS-1500 combines advanced hydraulic pumping technology, durable construction, and easy maintenance features to support demanding construction projects.
This high-performance system is designed for pumping gypsum flooring materials over long distances while also handling concrete mixes with aggregate sizes up to 1/2 inch. The HBS-1500 provides contractors with dependable concrete placement equipment for flooring, repair, and construction applications.
Reliable Small Concrete Pump Machine for Construction Projects
Modern construction projects require equipment that can deliver consistent material placement while remaining easy to operate and transport. The HBS-1500 offers an efficient solution with its hydraulic ball seat pump and integrated mixing system.
The machine is capable of producing up to 1000 PSI line pressure and can pump gypsum materials beyond 600 feet, making it suitable for both small-scale and large-scale applications.
Ideal applications include:
Concrete placement projects
Gypsum flooring installation
Commercial flooring applications
Industrial construction work
Concrete repair operations
Self-leveling material pumping
Advanced HBS-1500 Ball Seat Pump Technology
The HBS-1500 features a 4-inch hydraulic ball seat pump designed to improve reliability and reduce maintenance costs. The innovative ball seat design allows easier cleaning of the pump manifold and material pumping tubes, helping contractors minimize downtime.
Key Advantages:
1000 PSI pumping pressure capability
Long-distance material pumping
Reduced maintenance requirements
Smooth and consistent material flow
Easy cleaning and service access
Features of HBS-1500 Ball Seat Pump
Hydraulic Pump Performance
4-inch hydraulic ball seat pump
High-pressure pumping capability
Designed for gypsum and concrete materials
Efficient Mixer System
12 cubic foot hydraulic spiral mixer
30-second mixing cycle
Hydraulic dump system for improved productivity
Large Receiving Hopper
26 cubic foot receiving hopper capacity
Hydraulic conveying agitator
Quick-release pump manifold design
Durable Construction
Dual axle trailer with two braking axles
Heavy-duty tubular frame
Four manual leveling jacks for stability
HBS-1500 Specifications
Specification Details
Length 234 inches
Width 92 inches
Height (Water Tank) 93 inches
Height (Mixer Dump Position) 95 inches
Mixer Charging Height 57 inches
Weight 8,350 lbs.
Output Capacity 0–15 cubic yards per hour
Mixer Capacity 12 cubic feet
Receiving Hopper Capacity 26 cubic feet
Pump Type 4-inch Hydraulic Ball Seat Pump
Power Options
The HBS-1500 operates with:
70 HP Kubota water-cooled diesel engine
Available options:
Electric power configuration
Skid mount setup
Custom paint finish
Benefits of Professional Concrete Placement Equipment
Choosing dependable concrete placement equipment helps contractors improve project efficiency, reduce labor requirements, and achieve consistent results. The HBS-1500 provides:
Compact and efficient pumping operation
High production capability
Reliable hydraulic performance
Lower maintenance requirements
Versatile material handling
Applications of Small Concrete Pump Machine
The HBS-1500 Ball Seat Pump is suitable for:
Concrete placement equipment requirements
Flooring contractor applications
Gypsum underlayment projects
Commercial construction sites
Industrial flooring installations
Concrete repair and restoration
Optional Equipment
Available options include:
2000 PSI hydraulic pressure washer
Spare tire package
Electric power option
Skid mount configuration
Custom paint options
Small Concrete Pump Machine for Efficient Concrete Placement Equipment Applications
